ENGINE COMPARTMENT
For fuses and fusible link locations, refer to illustrations in COMPONENT LOCATION .
For engine compartment fuse locations, refer to illustrations below.
Scheme 8
* Facing to front of engine compartment.
Scheme 9
Scheme 10
| No. | POWER SUPPLY CIRCUIT | FUSE TYPE | RATED CAPACITY | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Fusible link No.36 | Fuse | 15A | Blue | Fog light and fog light relay |
| 2 | 7.5A | Brown | Engine control module | ||
| 3 | 20A | Yellow | Shift lever (TC-SST) and transaxle assembly (TC-SST) | ||
| 4 | 10A | Red | Horn (Low, High) and horn relay | ||
| 5 | 7.5A | Browm | Generator | ||
| 6 | |||||
| 7 | 10A | Red | A/C compressor assembly and A/C compressor clutch relay | ||
| 8 | 15A | Blue | Engine control module | ||
| 9 | 20A | Yellow | Theft-alarm horn and theft-alarm horn relay | ||
| 10 | |||||
| 11 | |||||
| 12 | |||||
| 13 | 10A | Red | Daytime running light relay and headlight assembly (LH, RH) | ||
| 14 | Headlight relay (High) | Fuse | 10A | Red | Headlight assembly (High: LH) |
| 15 | 10A | Red | Headlight assembly (High: RH) | ||
| 16 | Headlight relay (Low) | Fuse | 20A | Yellow | Headlight assembly LH (Discharge type) |
| 17 | 20A | Yellow | Headlight assembly RH(Discharge type) | ||
| 18 | 10A | Red | Headlight assembly (LH, RH) and headlight leveling switch | ||
| 19 | 10A | Red | Headlight assembly RH (Halogen type) | ||
| 20 | MFI Relay | Fuse | |||
| 21 | 10A | Red | Ignition coil No.1 to 4 | ||
| 22 | 20A | Yellow | Engine control module, evaporative emission purge solenoid, exhaust oil feeder control valve, heated oxygen sensor (Front, rear), injector Nos.1 to 4, intake oil feeder control valve, mass airflow sensor, throttle actuator control motor relay and turbocharger wastegate solenoid No.1 and 2 | ||
| 23 | 20A | Yellow | Fuel pump module, fuel pump relay 1 and fuel pump circuit resistor | ||
| 24 | Fusible link No.36 | Fusible link | 30A | Pink | Starter |
| 25 | |||||
| 26 | 40A | Green | ABS-ECU | ||
| 27 | 30A | Pink | ABS-ECU | ||
| 28 | 30A | Pink | Condenser fan motor, condenser fan relay and fan control relay | ||
| 29 | 40A | Green | Radiator fan motor and radiator fan relay | ||
| 30 | Fuse | 30A | Green | Fuse No.7 to 9 in passenger compartment | |
| 31 | 30A | Green | Audio amplifier | ||
| 32 | MFI relay | ||||
| 33 | Battery/Generator | Fusible Link | 140A | Fusible link No.37/ Fusible link No.34 to 36 | |
| 34 | Battery/Fusible link No.33 | 80A | ACC relay 3 in ETACS-ECU, fuse No.2, 4, 5, 10, 11, 12, 14, 15, 17, 18, 25 and fusible link No.20 in passenger compartment and ETACS-ECU | ||
| 35 | 80A | Electric pump | |||
| 36 | 120A | Fuse No.1 to 5, 7 to 9, 13 to 23, 30, 31 and fusible link No.24, 26 to 29 in engine compartment, MFI relay and headlight relay (High, Low) | |||
| 37 | Fusible link No.33/ Generator | 80A | ACC relay 2 in ETACS-ECU, fusible link No.1 and 21, Fuse No. 3, 6, 13, 16 in passenger compartment, ETACS-ECU and blower relay |
IDENTIFYING FUSES (ENGINE COMPARTMENT)
Spare fuses are located on the fuse box cover.
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
The fuse box does not contain spare 7.5A 10A and 15A fuses. If a fuse of one of these capacities blows, replace it temporarily by borrowing a fuse of correct rating from
- 7.5A: Door mirror heater
- 10A: Dome light (Engine Compartment)
- 15A: Cigarette lighter (Power outlet)
Replace the borrowed fuse as soon as possible.
PASSENGER COMPARTMENT
For fuse location and values, refer to illustrations below.
Scheme 11
Scheme 12
| NO. | POWER SUPPLY CIRCUIT | FUSE TYPE | RATED CAPACITY | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Fusible link No.37 | Fusible link | 30A | Pink | Blower motor |
| 2 | Fusible link No.34 | Fuse | 15A | Blue | ETACS-ECU, high-mounted stoplight (LH, RH), rear shift lever (TS-SST) |
| 3 | Fusible link No.37 | 10A | Red | ||
| 4 | ETACS-ECU (ACC relay 3) | 30A | Green | Windshield wiper automatic stop relay, windshield wiper motor and windshield wiper speed switching relay in ETACS-ECU, washer motor and windshield washer relay | |
| 5 | Fusible link No.34 | 10A | Red | Data link connector | |
| 6 | Fusible link No.37 | 20A | Yellow | Door lock relay, drivers door unlock relay, passengers door unlock relay and trunk lid open relay in ETACS-ECU, front door lock actuator (LH, RH), rear door lock actuator (LH, RH) and trunk lid latch | |
| 7 | Fusible link No.30 | 15A | Blue | CAN box unit, center panel unit, hands free module, multivision display, radio/CD player, satellite radio tuner and spare connector (for navigation unit) | |
| 8 | 7.5A | Brown | Power window relay in ETACS-ECU, A/C-ECU, column switch, combination meter, ETACS-ECU, key reminder switch (Vehicles with KOS), KOS-ECU, lighting control sensor, S-AWC-ECU and wireless control module | ||
| 9 | 15A | Blue | Center panel unit, combination meter and key reminder switch | ||
| 10 | Fusible link No.34 | 15A | Blue | ETACS-ECU | |
| 11 | ETACS-ECU (ACC relay 3) | Fuse | |||
| 12 | ETACS-ECU (IG1 relay) | 7.5 | Brown | A/C-ECU, A/C control panel, center panel unit, column switch, combination meter, heated seat relay, KOS-ECU, rear window defogger relay, receiver antenna module , S-AWC-ECU, shift lever (TC-SST), SRS-ECU, steering wheel sensor, sunroof motor assembly, transaxle assembly (TC-SST) and wireless control module (Vehicles without KOS) | |
| 13 | ETACS-ECU (ACC relay 2) | 15A | Blue | Accessory socket and cigarette lighter | |
| 14 | Fusible link No.34 | 10A | Red | Fuel pump relay 2, IG1 relay, power window relay in ETACS-ECU, ETACS-ECU, engine control module and injector relay | |
| 15 | 20A | Yellow | Sunroof motor assembly | ||
| 16 | ETACS-ECU (ACC relay 2) | 10A | Red | CAN box unit, multivision display, radio/CD player, door mirror assembly (LH, RH) and shift lever (TS-SST) | |
| 17 | Fusible link No.34 | 10A | Red | ASC-ECU, front seat assembly (LH) and S-AWC-ECU | |
| 18 | ETACS-ECU (IG1 relay) | 7.5A | Brown | Backup light (LH, RH), ETACS-ECU, multivision display, shift lever , spare connector (for navigation unit) and SRS-ECU | |
| 19 | Fusible link No.37 | 15A | Blue | ||
| 20 | Fusible link No.34 | Fusible link | 30A | Pink | Front power window sub switch, power window main switch and rear power window motor (LH, RH) |
| 21 | Fusible link No.37 | 30A | Pink | Rear window defogger | |
| 22 | Fuse | ||||
| 23 | Fusible link No.34 | ||||
| 24 | |||||
| 25 | 30A | Green | Heated seat assembly (LH, RH) and heated seat switch |
IDENTIFYING FUSES (PASSENGER COMPARTMENT)
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
