COMPONENT LOCATION
For fuses and fusible link locations, refer to illustrations below.
Scheme 1
Scheme 2
| NAME | SYMBOL | NAME | SYMBOL |
|---|---|---|---|
| Fusible link Nos. 33 to 37 (Connected directly to battery positive terminal) | A | Fusible link Nos. 1 and No. 20 (ETACS-ECU) | C |
| Fuse Nos. 1 to 23 and No. 30 to 32 (Engine compartment relay box) | B | Fuse Nos. 2 to 19 (ETACS-ECU) | C |
| Fusible link Nos. 24 to 29 (Engine compartment relay box) | B | Fusible link No. 21 (Passengers compartment relay box) | C |
| IOD or storage connector | B | Fuse Nos. 22 to 25 (Passengers compartment relay box) | C |
