SPECIAL TOOLS

SPECIAL TOOLS SPECIFICATION Tool Tool number and name Supersession Application MB990767 Front hub and flange yoke holder MB990767-01 Fixing of the hub MB991618 Hub bolt remover General service tool Removal of the hub bolt MB991897 or MB992011 Ball joint remover MB991113-01, MB990635-01 or General service tool Ball joint disconnection NOTE: Steering linkage puller (MB990635 or MB991113)is also used to disconnect knuckle and tie rod end ball joint. MB990241 Axle shaft puller MB990242 Puller shaft MB990244 Puller bar MB990241-01 or General service tool Removal of the driveshaft Removal of hub assembly MB991354 Puller body General service tool MB991721 Slide hammer - Removal of the output shaft MB991017 MB990998 MB991000 A, B: Front hub remover and installer C: Spacer MB990998-01 Provisional holding of the wheel bearing Measurement of hub starting torque Measurement of wheel bearing end play NOTE: MB991000, which belongs to MB990998, should be used as a spacer. MB990685 Torque wrench General service tool Measurement of hub starting torque MB990326 Preload socket General service tool MB991561 Boot band crimping tool MB991561 EBJ boot (resin boot) band installation

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. Remove the front caliper assembly and front disk brake, and retain the front caliper assembly with a wire and the like to prevent from falling (Refer to «FRONT AXLE HUB ASSEMBLY»(ref-289401-S05460653272008063000000) ).
2. Set a dial gauge as shown in the figure. Move the hub in the axial direction and measure the end play. Limit: 0.05 mm (0.002 inch)
3. After checking, install the front brake disk and the front caliper assembly (Refer to «FRONT AXLE HUB ASSEMBLY»(ref-289401-S05460653272008063000000) ).
