GENERAL SPECIFICATIONS
| Item | Specification | ||
|---|---|---|---|
| Front wheel bearing | Type | Unit bearing (double-row angular contact ball bearing) | |
| Front driveshaft | Joint type | Outer | High efficiency compact Birfield joint |
| Inner | High efficiency compact tripod joint | ||
GENERAL SPECIFICATIONS
SERVICE SPECIFICATIONS
| Item | Standard value | Limit | |
|---|---|---|---|
| Wheel bearing end play mm (in) | 0.05 (0.002) | ||
| Wheel bearing rotation starting torque N.m(in-lb) | 1.4 (12.39) | ||
| Setting of ETJ boot length mm (in) | 80 ± 3 (3.14 ± 0.12) | ||
| Opening dimension of the special tool (MB991561) mm (in) | When the EBJ boot band (small) is crimped | 2.9 (0.11) | |
| When the EBJ boot band (large) is crimped | 3.2 (0.13) | ||
| Crimped width of the EBJ boot band mm (in) | 2.4 - 2.8 (0.10 - 0.11) | ||
GENERAL SPECIFICATIONS
WHEEL BEARING ROTATION STARTING TORQUE AND END PLAY CHECK
Required Special Tools
- MB990998: Front Hub Remover and Installer
- MB991000: Spacer
- MB990326: Preload Socket
- MB990685: Torque Wrench
Scheme 73
Scheme 74
Scheme 75
- Tighten special tools MB990998 and MB991000 to the specified torque. Tightening torque: 144 - 176 N.m (107 - 129 ft-lb)
- Hold the front wheel hub assembly in a vice with a wooden block.
- Rotate the hub in order to seat the bearing.
- Measure the wheel bearing rotation starting torque by using special tools MB990326 and MB990685. Limit: 1.4 N.m (12.39 in-lb)
- If the rotation starting torque is not within the limit range, replace the front wheel hub assembly. If there is any signs of binding or tight spots when the wheel bearing turns, also replace it.
- Measure to determine whether the wheel bearing end play is within the specified limit or not. Limit: 0.05 mm (0.002 inch)
- If the play is not within the limit range while the nut is tightened to 144 - 176 N.m (107 - 129 ft-lb), replace the front wheel hub assembly.
