MAINTENANCE, REPAIR AND SERVICING EXPLANATIONS
This manual provides explanations, etc. concerning procedures for the inspection, maintenance, repair and servicing of the subject model. Unless otherwise specified, each service procedure covers all models. Procedures covering specific models are identified by the model codes, or similar designation (engine type, transaxle type, etc.). A description of these designations is covered in this manual under "VEHICLE IDENTIFICATION".
LUBRICATION AND MAINTENANCE
Maintenance and lubrication service recommendations have been compiled to provide maximum protection for the vehicle owner's investment against all reasonable types of driving conditions. Since these conditions vary with the individual vehicle owner's driving habits, the area in which the vehicle is operated and the type of driving to which the vehicle is subjected, it is necessary to prescribe lubrication and maintenance service on a time frequency as well as mileage interval basis.
Oils, lubricants and greases are classified and graded according to standards recommended by the Society of Automotive Engineers (SAE), the American Petroleum Institute (API) and the National Lubricating Grease Institute (NLGI).
MAINTENANCE SCHEDULES
Information for service maintenance is provided in the "SCHEDULED MAINTENANCE TABLE." Three schedules are provided; one for "Required Maintenance." one for "General Maintenance" and one for "Severe Usage Service".
The item numbers in "SCHEDULED MAINTENANCE TABLE" correspond to the article numbers in "MAINTENANCE SERVICE".
SCHEDULED MAINTENANCE SERVICE FOR EMISSION CONTROL AND PROPER VEHICLE PERFORMANCE
Inspection and service should be performed any time if a malfunction is observed or suspected.
| No | Emission control system maintenance | Service intervals | Kilometers in thousands | 24 | 48 | 72 | 96 | 120 | 144 | 168 | 192 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mileage in thousands | 15 | 30 | 45 | 60 | 75 | 90 | 105 | 120 | |||
| Months | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | |||
| 1 | Fuel system (tank, pipe line and connection, and fuel tank filler tube cap) | Check for leaks | X | X | |||||||
| 2 | Fuel hoses | Check condition | X* 1 | X | X | X | |||||
| 3 | Air cleaner element | Replace | X | X | X | X | |||||
| 4 | Evaporative emission control system (except evaporative emission canister) | Check for leaks and clogging | X | X | |||||||
| 5 | Spark plugs | Iridium-tipped type | Replace | Every 84 months or every 168,000 km (105,000 miles | |||||||
| 6 | Intake and exhaust valve clearance | Inspect and adjust | X | X | |||||||
| 7 | Drive belts (for the generator and power steering oil pump) | Check condition | X | X | X | X | |||||
| 8 | Exhaust system (connection portion of muffler, muffler pipes and converter heat shields) | Check and service | X* 1 | X | X | X | |||||
| NOTE: * 1 : This maintenance is recommended but is not required to maintain the emissions warranty. | |||||||||||
| NOTE |
|---|
| * 1 : This maintenance is recommended but is not required to maintain the emissions warranty. |
SCHEDULED MAINTENANCE CHART
GENERAL MAINTENANCE SERVICE FOR PROPER VEHICLE PERFORMANCE
| No. | General maintenance | Service intervals | Kilometers in thousands | 24 | 48 | 72 | 96 | 120 | 144 | 168 | 192 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mileage in thousands | 15 | 30 | 45 | 60 | 75 | 90 | 105 | 120 | |||
| Months | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | |||
| 9 | Engine oil | Change | Every 6 months or every 12,000 km (7,500 miles) | ||||||||
| 10 | Engine oil filter | Replace | Every 6 months or every 12,000 km (7,500 miles) | ||||||||
| 11 | Transaxle oil < M/T> | Check oil level and condition | X | X | X | X | |||||
| 13 | Engine coolant | Change | X at first | X | X | ||||||
| 14 | Coolant hoses (radiator hose, heater hose) | Inspect | X | X | X | X | |||||
| 15 | Disc brake pads, rotors | Inspect for wear | Every 12 months or every 24,000 km (15,000 miles) | ||||||||
| 16 | Rear drum brake linings and rear wheel cylinders (except vehicles with disc brakes) for all wheels | Inspect for wear and leaks | X | X | X | X | |||||
| 17 | Brake hoses | Check for deterioration or leaks | Every 12 months or every 24,000 km (15,000 miles | ||||||||
| 18 | Ball joint and steering linkage seals | Inspect for grease leaks and damage | X | X | X | X | |||||
| 19 | Drive shaft boots | Inspect for grease leaks and damage | Every 12 months or every 24,000 km (15,000 miles) | ||||||||
| 20 | Suspension system | Inspect for looseness and damage | X | X | X | X | |||||
| 21 | Tires | Rotate | Every 12,000 km (7,500 miles) | ||||||||
| 22 | Air filter | Replace | Every 18 months or every 24,000 km (15,000 miles) | ||||||||
GENERAL MAINTENANCE SERVICE FOR PROPER VEHICLE PERFORMANCE
SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS
Maintenance should be carried out according to the following table
| NO. | Maintenance item | Service intervals | Kilometers in thousands | 24 | 48 | 72 | 96 | 120 | 144 | 168 | 192 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mileage in thousands | 15 | 30 | 45 | 60 | 75 | 90 | 105 | 120 | |||
| Months | 12 | 24 | 36 | 48 | 60 | 72 | 84 | 96 | |||
| 3 | Air cleaner element | Replace | Every 12 months or every 24,000 km (15,000 miles) | ||||||||
| 9 | Engine oil | Change | Every 3 months or every 6,000 km (3,750 miles) | ||||||||
| 10 | Engine oil filter | Replace | Every 3 months or every 6,000 km (3,750 miles) | ||||||||
| 11 | Transaxle oil < M/T> | Change oil | X | X | X | X | |||||
| 12 | Transmission fluid < CVT> | Change fluid | X check | X | X check | X | X check | X | X check | X | |
| 15 | Disc brake pads, rotors | Inspect for wear | Every 6 months or every 12,000 km (7,500 miles) | ||||||||
| 16 | Rear drum brake linings and rear wheel cylinders (except vehicles with disc brakes) for all wheels | Inspect for wear and leaks | Every 12 months or every 24,000 km (15,000 miles) | ||||||||
| 20 | Suspension system | Inspect for looseness and damage | Every 6 months or every 12,000 km (7,500 miles) | ||||||||
| 22 | Air filter | Inspect for clogging | Every 3 months or every 6,000 km (3,570 miles) | ||||||||
| Replace | Every 6 months or every 12,000 km (7,500 miles) | ||||||||||
SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS CHART
Severe usage conditions
- Driving on dusty, rough, muddy or salt-spread roads
- Towing or police, taxi or commercial operation
- Extensive idling and/or low speed operation
- Repeated short-trip operation at freezing temperatures (engine not thoroughly warmed up)
- Extended use of brakes while driving
- Driving in sandy areas
- More than 50% operation in heavy city traffic during hot weather above 32°C (90°F)
Transmission fluid check
| CAUTION | Replace the transmission fluid whenever the transaxle is replaced with a new one or the vehicle is driven in harsh conditions. |
Scheme 116
Scheme 117
- Drive the vehicle until the transmission fluid is warmed up to the normal operating temperature 70 - 80°C (158 - 176°F). NOTE: Use M.U.T.-III. to measure the transmission fluid temperature. NOTE: When a certain amount of time is required to warm up the transmission fluid to the normal operating temperature 70 - 80°C (158 - 176°F), check the oil level referring to the characteristics chart.
- Park the vehicle on a level surface.
- Move the selector lever to every position to fill the torque converter and the hydraulic circuit with the transmission fluid, and then move the selector lever to "P" or "N" range.
- Wipe clean the area around the dipstick, and then remove the dipstick to check the condition of the transmission fluid. NOTE: If the transmission fluid smells burnt or is excessively deteriorated or dirty, the transmission fluid is contaminated with particles of the metal bushings and friction material. In these cases, the transaxle must be overhauled.
- Check that the transmission fluid level is within the "HOT" area on the dipstick. If the fluid level is low, add the transmission fluid to the "HOT" level. Transmission fluid: DIA QUEEN CVTF-J1 NOTE: When the transmission fluid level is low, the oil pump sucks air together with the transmission fluid, and produces air bubbles in the hydraulic circuit. The air bubbles in the hydraulic circuit decreases the hydraulic pressure, causing the delayed shift or slippage of the belt, clutch, and brake. When the transmission fluid level is too high, the fluid is stirred by the gear and foams up, and the problems similar to those when the transmission fluid level is low will occur. In either case, air bubbles cause the overheat and oxidation of the transmission fluid, which prevents normal operation of the valve, clutch, and brake. Beside, when the transmission fluid is foamy, it flows out of the transaxle vent hole. This may be taken as the fluid leakage by mistake.
- Insert the dipstick securely.
Scheme 118
- Remove the drain plug on the bottom of the transaxle case to drain the transmission fluid. Draining amount: Approximately 6.0 dm 3 (6.3 qt)
- Install the drain plug with a new gasket to the transaxle case, and tighten it to the specified torque. Tightening torque: 34 ± 2 N.m (25 ± 2 ft-lb) CAUTION: If the transaxle case becomes full before filling 6.0 dm 3 (6.3 qt) of transmission fluid, stop filling the transmission fluid.
- Fill in the new transmission fluid through the filler tube. Filling amount: Approximately 6.0 dm 3 (6.3 qt) Transmission fluid: DIA QUEEN CVTF-J1
- Start up the engine and let it idle for 1 to 2 minutes.
- Move the selector lever to every position, and then move it to the "P" or "N" range.
- Stop the engine and perform the above steps 1 to 5 again.
- Stop the engine, and discharge a small amount of transmission fluid to check for fouling. If fouling is found, repeat steps 1 to 5 until clean transmission fluid comes out.
- Drive the vehicle until the transmission fluid is warmed up to the normal operating temperature 70 - 80°C (158 - 176°F), and check the transmission fluid level. It must be within the "HOT" area on the dipstick. NOTE: The "COLD" level is for reference only. Use the "HOT" level as the criteria. NOTE: Use M.U.T.-III. to measure the transmission fluid temperature. NOTE: When a certain amount of time is required to warm up the transmission fluid to the normal operating temperature 70 - 80°C (158 - 176°F), check the fluid level referring to the characteristics chart.
- Adjust the transmission fluid level to the specified level. Refill the transmission fluid when the fluid level is low, and drain the transmission fluid through the drain plug when the fluid level is high.
- Securely insert the dipstick into the filler tube.
- TCM records the deterioration level of the transmission fluid. After replacing the transmission fluid with new one, use M.U.T.-III to reset the deterioration level recorded in TCM.
