Power/heated Mirrors - Except Evolution: Other Mitsubishi Lancer IX

REMOTE CONTROLLED MIRROR

The mirror on the door mirror moves up/down and left/right by operating the remote controlled door mirror switch when the ignition switch is in the "ON" or "ACC" position.

Step 1: Check The Defogger

1. Ignition switch: ON
2. Defogger switch: ON

Does the defogger work normally?

1. YES Go to step «2»(ref-169853-S16753705482004121600000) .
2. NO Malfunction of the defogger. See «DEFOGGERS»(ref-158784-S05853738082003102100000) .

Step 3: Check The Remote Controlled Mirror (RH) Connector E-20 And Junction Block Connector C-214 For Loose, Corroded Or Damaged Terminals, Or Terminals Pushed Back In The Connector

Are the remote controlled mirror (RH) connector E-20 and junction block connector C-214 in good condition? (Scheme 12)

1. YES Go to step «4»(ref-169853-S10810385002004121600000) .
2. NO Repair or replace the damaged component(s). Check if the door mirror heater function (heated door mirrors) works normally.

Scheme 12

Step 2: Check The Heated Door Mirror (LH)

The resistance value between door mirror (LH) connector terminals No. 1 and 4 should meet the standard value with the ambient temperature at a steady 25°C (77°F). Standard value: 5.9 - 7.8 ohms. (Scheme 13)

Is the heater function (heated door mirror) of the door mirror normal?

1. YES Go to step «3»(ref-169853-S41885149102004121600000) .
2. NO Replace the door mirror (LH). Check to see that the heater function (heated door mirror) of the door mirror (LH) is operating normally.

Scheme 13

Step 3: Check The Ground Circuit To The Door Mirror (LH)

Test at remote controlled mirror (LH) connector E-19.

1. Disconnect remote controlled mirror (LH) connector E-19 and measure the resistance available at the wiring harness side of the connector.
2. Measure the resistance value between terminal No. 4 and ground. (Scheme 14) The resistance should be 2 ohms or less.

Is the measured resistance 2 ohms or less?

1. YES Go to step «6»(ref-169853-S16173131162004121600000) .
2. NO Go to step «4»(ref-169853-S27857273302004121600000) .

Scheme 14

Step 4: Check The Remote Controlled Mirror (LH) Connector E-19 For Loose, Corroded Or Damaged Terminals, Or Terminals Pushed Back In The Connector

Is the remote controlled mirror (LH) connector E-19 in good condition?

1. YES Go to step «5»(ref-169853-S37883128322004121600000) .
2. NO Repair or replace the damaged component(s). Check to see that the heater function (heated door mirror) of the door mirror (LH) operates normally.

Step 6: Check The Remote Controlled Mirror (LH) Connector E-19 For Loose, Corroded Or Damaged Terminals, Or Terminals Pushed Back In The Connector

Is the remote controlled mirror (LH) connector E-19 in good condition?

1. YES Go to step «7»(ref-169853-S42549833512004121600000) .
2. NO Repair or replace the damaged component(s). Check to see that the heater function (heated door mirror) of the door mirror (LH) operates normally.

Step 8: Check The Heated Door Mirror (RH)

The resistance value between door mirror (RH) connector terminals No. 1 and 4 should meet the standard value with the ambient temperature at a steady 25°C (77°F). Standard value: 5.9 - 7.8 ohms.

Is the heater function (heated door mirror) of the door mirror normal?

1. YES Go to step «9»(ref-169853-S30257275722004121600000) .
2. NO Replace the door mirror (RH). Check to see that the heater function (heated door mirror) of the door mirror (RH) operates normally.

Step 9: Check The Ground Circuit To The Door Mirror (RH)

Test at the remote controlled mirror (RH) connector E-20.

1. Disconnect the remote controlled mirror (RH) connector E- 20 and measure the resistance available at the wiring harness side of the connector.
2. Measure the resistance value between terminal No. 4 and ground. (Scheme 15) The resistance should equal 2 ohms or less.

Is the measured resistance 2 ohms or less?

1. YES No action is necessary and testing is complete.
2. NO Go to step «12»(ref-169853-S07531416362004121600000) .

Scheme 15

Step 10: Check The Remote Controlled Mirror (RH) Connector E-20 For Loose, Corroded Or Damaged Terminals, Or Terminals Pushed Back In The Connector

Is the remote controlled mirror (RH) connector E-20 in good condition?

1. YES Go to step «11»(ref-169853-S41093488422004121600000) .
2. NO Repair or replace the damaged component(s). Check to see that the heater function (heated door mirror) of the door mirror (RH) operates normally.

Step 12: Check The Remote Controlled Mirror (RH) Connector E-20 For Loose, Corroded Or Damaged Terminals, Or Terminals Pushed Back In The Connector

Is the remote controlled mirror (RH) connector E-20 in good condition?

1. YES Go to step «13»(ref-169853-S05322039772004121600000) .
2. NO Repair or replace the damaged component(s). Check to see that the heater function (heated door mirror) of the door mirror (RH) operates normally.

HEATED DOOR MIRROR CHECK

The resistance value between door mirror connector terminals No. 1 and 4 should meet the standard value with the ambient temperature at a steady 25°C (77°F). Standard value: 5.9 - 7.8 ohms.
