Power/heated Mirrors - Except Evolution: Wiring Mitsubishi Lancer IX

Mirrors 2 illustrations ~684 words

Step 4: Check The Wiring Harness Between The Remote Controlled Mirror (RH) Connector E-20 (Terminal No. 1) And Junction Block Connector C-214 (Terminal No. 3)

Note. Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the damaged component(s).

Are the wiring harness between the remote controlled mirror (RH) connector E-20 (terminal No. 1) and the junction block connector C-214 (terminal No. 3) in good condition?

  1. YES No action is necessary and testing is complete.
  2. NO The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check if the door mirrors heater function (heated door mirror) works normally.

Scheme 10

Scheme 10: Circuit Diagram & Connector Identification

Step 5: Check The Wiring Harness Between The Remote Controlled Mirror (LH) Connector E-19 (Terminal 4) And Ground

Note. Also check intermediate connector C-17 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-17 is damaged, repair or replace the damaged component(s).

Are the wiring harness between the remote controlled mirror (LH) connector E-19 (terminal 4) and ground in good condition?

  1. YES No action is necessary and testing is complete.
  2. NO The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check to see that the heater function (heated door mirror) of the door mirror (LH) operates normally.

STEP 7. Check the wiring harness between the remote controlled mirror (LH) connector E-19 (terminal 1) and junction block connector C-214 (terminal 3).

Note. Also check intermediate connector C-17 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-17 is damaged, repair or replace the damaged component(s).

Are the wiring harness between the remote controlled mirror (LH) connector E-19 (terminal No. 1) and junction block connector C-214 (terminal No. 3) in good condition?

  1. YES No action is necessary and testing is complete.
  2. NO The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check to see that the heater function (heated door mirror) of the door mirror (LH) operates normally.

Step 11: Check The Wiring Harness Between The Remote Controlled Mirror (RH) Connector E-20 (Terminal No. 4) And Ground

Note. Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the damaged component(s).

Are the wiring harness between the remote controlled mirror (RH) connector E-20 (terminal No. 4) and ground in good condition?

  1. YES No action is necessary and testing is complete.
  2. NO The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check to see that the heater function (heated door mirror) of the door mirror (RH) operates normally.

Step 13: Check The Wiring Harness Between The Remote Controlled Mirror (RH) Connector E-20 (Terminal No. 1) And Junction Block Connector C-214 (Terminal No. 3)

Note. Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the damaged component(s).

Is the wiring harness between the remote controlled mirror (RH) connector E-20 (terminal No. 1) and junction block connector C-214 (terminal No. 3) in good condition?

  1. YES No action is necessary and testing is complete.
  2. NO The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check to see that the heater function (heated door mirror) of the door mirror (RH) operates normally.

Scheme 11

Scheme 11: DOOR MIRROR

WIRING DIAGRAMS

For power mirror circuits, see POWER MIRRORS . For defogger circuits, see DEFOGGERS .
