Manual Transaxle Overhaul - Except Evolution: Overview Mitsubishi Lancer IX

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Required Special Tools

1. MB990927: Installer Adapter
2. MB990935: Installer Adapter
3. MB990938: Handle

Scheme 221

Scheme 222

Scheme 223

1. Drive a screwdriver into the center of the sealing cap.
2. Bend the screwdriver back to remove the sealing cap.

Scheme 224

1. Remove all sixteen bolts securing the transaxle case to the clutch housing.
2. Use snap ring pliers to expand the indicated snap ring. The snap ring will release the grooved ball bearing, and the output shaft assembly will fall under its own weight. CAUTION: Do not use a scraper or chisel to remove the transaxle case.
3. Remove the transaxle case from the clutch housing by gently prying on opposite sides at the same time.

Scheme 225

Scheme 226

1. Shift the 3rd-4th speed shift fork and 5th speed-reverse shift fork in the direction shown.
2. Pull up on the 3rd-4th speed shift rail and 5th speed-reverse shift rail and take them out of the hole in the clutch housing.
3. Slide the 3rd-4th speed shift rail and 5th speed-reverse shift rail in the direction shown and remove them together with the shift forks.
