IGNITION COIL CHECK

Check by the following procedure, and replace the coil if there is a malfunction.

SECONDARY COIL RESISTANCE CHECK

Measure the resistance between the high-voltage terminals of the ignition coil.

1. Standard value: 8.5 - 11.5 kohms

Scheme 30

PRIMARY COIL AND IGNITION POWER TRANSISTOR CONTINUITY CHECK

Note. An analog-type ohmmeter should be used.

Note. Connect the negative probe of the ohmmeter to terminal 1.

Scheme 31

Scheme 32

1. Connect and disconnect 1.5 V battery between terminals 2 and 3, and observe the ohmmeter whether there is continuity or not.
2. If results do not agree with the table below, replace the primary coil and ignition power transistor assembly.

SPARK PLUG CABLE RESISTANCE CHECK

Measure the resistance of the all spark plug leads.

Scheme 33

1. Check the cap and coating for cracks.
2. Measure the resistance. Limit: 19 kohms
3. If resistance is greater than 19 kohms, replace the cable.

Scheme 34

1. Check that the plug is not burned, that the insulator plug is not damaged, and that the seizure state is good.
2. If cleaning is required due to carbon deposits, etc., clean using a plug cleaner or wire brush, etc.
3. Check the plug gap using a plug gap gauge, and adjust if not within the standard value. Standard value: 1.0 - 1.1 mm (0.039 - 0.043 inch)

CAMSHAFT POSITION SENSOR CHECK

Refer to DIAGNOSTIC TROUBLE CODE DEFINITIONS .

CRANK ANGLE SENSOR CHECK

Refer to DIAGNOSTIC TROUBLE CODE DEFINITIONS .

MEASUREMENT METHOD

1. Clamp the spark plug cable (Number 1 or 3) with the secondary pickup. NOTE: Because of the two-cylinder simultaneous ignition system, the waves for two cylinders in each group appear during wave observation. However, wave observation is carried out for the cylinder (Number 1 or 3) with the spark plug cable which has been clamped by the secondary pickup. NOTE: Identification of which cylinder wave pattern is displayed can be difficult, but the wave pattern of the cylinder which is clamped by the secondary pickup will be stable, so this can be used as a reference.
2. Clamp the spark plug cable (Number 1 or 3) with the trigger pickup. NOTE: Clamp the same spark plug cable as the one which has been clamped by the secondary pickup.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Wave characteristics Spark line is high and short.
2. Cause of problem Spark plug gap is too large.

Scheme 40

1. Wave characteristics Spark line is low and long, and is sloping. Also, the second half of the spark line is distorted. This could be a result of misfiring.
2. Cause of problem Spark plug gap is too small.

Scheme 41

1. Wave characteristics Spark line is low and long, and is sloping. However, there is almost no spark line distortion.
2. Cause of problem Spark plug gap is fouled.

Scheme 42

1. Wave characteristics Spark line is high and short. Difficult to distinguish between this and abnormal wave pattern example 1.
2. Cause of problem Spark plug cable is not properly connected. (Causing a dual ignition)

Scheme 43

1. Wave characteristics No waves in wave damping section
2. Cause of problem Short in ignition coil.

Scheme 44

Scheme 45

Scheme 46
