Column Switch - Except Lancer Evolution Mitsubishi Lancer Evolution X

Steering Column Switches 9 illustrations ~1133 words

GENERAL INFORMATION

Column switch has a function to ensure the driver's safety during frontal collision of vehicle.

Scheme 4

Scheme 4: Function
Scheme 4: Function

If the column switch is moved to the front of the vehicle and hit on the instrument panel or meter bezel by the frontal collision of vehicle, the steering wheel is moved to the front of the vehicle because the right and left levers fall down, ensuring the driver's safety. In addition, the column switch secures the rigidity that the levers do not fall down by the normal operation, however, it cannot be reused after the deformation.

SPECIAL TOOLS

SPECIAL TOOLS Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 M.U.T.-III sub-assembly Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: M.U.T.-III main harness A (MB991910) should be used. M.U.T.-III main harness B and C should not be used for this vehicle. Diagnostic code and service data check. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Check harness LED harness LED harness adapter Probe General service tool (jumper) Continuity check and voltage measurement at harness wire or connector For checking connector pin contact pressure For checking power supply circuit For checking power supply circuit For connecting a locally sourced tester MB992006 Extra fine probe - Continuity check and voltage measurement at harness wire or connector

Scheme 5

Scheme 5: SPECIAL TOOLS
Scheme 5: SPECIAL TOOLS

Scheme 6

Scheme 6
Scheme 6

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 7

Scheme 7
Scheme 7
  1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
  2. Start up the personal computer.
  3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
  4. Connect special tool MB991910 to special tool MB991824.
  5. Connect special tool MB991910 to the data link connector.
  6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
  7. Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "System select" from the start-up screen.
  4. Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
  5. Select "ETACS" from "System List", and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
  6. Select "Diagnostic Trouble Code." to read the DTC.
  7. If a DTC is set, it is shown.
  8. Choose "Erase DTCs" to erase the DTC.

DIAGNOSTIC TROUBLE CODE TABLE

Note. The ETACS-ECU sets a diagnostic trouble code.

DTC No.Diagnostic item
B2350Malfunction of lighting switch
B2351Malfunction of the wiper/washer switch

DIAGNOSTIC TROUBLE CODE TABLE

TROUBLE JUDGMENT

The ETACS-ECU receives the signals related to lighting and wiper/washer from the column switch. If the fail information data is included in the signal from column switch, DTC B2350 (Lighting switch) or B2351 (Wiper/washer switch) is stored.

TECHNICAL DESCRIPTION (COMMENT)

The column switch or the ETACS-ECU may have a problem.

TROUBLESHOOTING HINTS

  1. Malfunction of lighting switch (integrated with the column-ECU)
  2. Malfunction of wiper/washer switch
  3. The ETACS-ECU may be defective

DIAGNOSIS

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. Check again if the DTC is set to the ETACS-ECU. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/steering-column-switches/#column-switch-except-lancer-evolution__how-to-connect-the-scan-tool) ". Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if the DTC B2350 or B2351 is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? DTC B2351 is set.: Go to Step 2. DTC B2350 is set.: Go to Step 3 . No DTC is set.: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  2. STEP 2. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. Check again if the DTC is set to the ETACS-ECU. Replace the wiper/washer switch. Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. Check again if the DTC is set to the ETACS-ECU. Replace the lighting switch (integrated with the column-ECU). Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

Scheme 8

Scheme 8: LIGHTING SWITCH AND WIPER/WASHER SWITCH
Scheme 8: LIGHTING SWITCH AND WIPER/WASHER SWITCH

Scheme 9

Scheme 9: COLUMN SWITCH BODY
Scheme 9: COLUMN SWITCH BODY

WIPER/WASHER SWITCH CONTINUITY CHECK

Switch positionTester connectionSpecified condition
OFFOpen circuit
Windshield intermittent wiper interval adjusting knob6 - 3Operating the adjusting knob changes the resistance.
Windshield washer switch6 - 7Continuity exists (2 ohms or less)
Windshield wiper switchHi6 - 8Continuity exists (2 ohms or less)
Lo6 - 9Continuity exists (2 ohms or less)
Int6 - 10Continuity exists (2 ohms or less)
Mist6 - 11Continuity exists (2 ohms or less)

WIPER/WASHER SWITCH CONTINUITY TABLE (VEHICLES WITHOUT LIGHTING CONTROL SENSOR)

Scheme 10

Scheme 10
Scheme 10
Switch positionTester connectionSpecified condition
OFFOpen circuit
Windshield rain sensitive wiper function adjusting knob6 - 3Operating the adjusting knob changes the resistance.
Windshield washer switch6 - 7Continuity exists (2 ohms or less)
Windshield wiper switchHi6 - 8Continuity exists (2 ohms or less)
Lo6 - 9Continuity exists (2 ohms or less)
Auto6 - 10Continuity exists (2 ohms or less)
Mist6 - 11Continuity exists (2 ohms or less)

WIPER/WASHER SWITCH CONTINUITY TABLE (VEHICLES WITH LIGHTING CONTROL SENSOR)

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12: COLUMN SWITCH (SWITCH BODY PART) CONTINUITY CHECK
Scheme 12: COLUMN SWITCH (SWITCH BODY PART) CONTINUITY CHECK
  1. Remove the lighting switch and wiper/washer switch.
  2. Check that the continuity is present for the same terminal numbers of the column switch body connectors that remain on the steering column. COLUMN SWITCH CONTINUITY CHECK Column switch body Terminal number Normal condition Lighting switch side connector Wiper/washer switch side connector 3 - 3 6 - 6 7 - 7 8 - 8 9 - 9 10 - 10 11 - 11 Continuity exists (2 ohms or less)
