Door Mirror - Except Lancer Evolution Mitsubishi Lancer Evolution X

Mirrors 14 illustrations ~2234 words

Remote Controlled Mirror Operation

  1. The mirror on the door mirror moves up/down and left/right by operating the remote controlled door mirror switch when the ignition switch is at the "ON" or "ACC" position.

Heated Door Mirror Operation

  1. The rear window defogger relay switch is activated (ON) by turning on the A/C-ECU built-in rear window defogger switch when the ignition switch is in the "ON" position. When the rear window defogger relay is turned ON, power is supplied to the rear window defogger, and the heater of the door mirror (heated door mirror) starts operation. The rear window defogger comes with a timer function and will automatically turn OFF the switch approximately 20 minutes after the rear window defogger switch is turned ON. The heated door mirror operations are also terminated along with the rear window defogger, at this time.

TROUBLESHOOTING STRATEGY

Diagnosis should be carried out by the following procedures.

  1. Gather the information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find the malfunction by the following SYMPTOM CHART.
  4. Verify the malfunction is eliminated.

SYMPTOM CHART

SYMPTOMINSPECTION PROCEDUREREFERENCE
None of the heated door mirrors operate1INSPECTION PROCEDURE 1: NONE OF THE HEATED DOOR MIRRORS OPERATE
The right or left heated door mirror does not operate2INSPECTION PROCEDURE 2: THE RIGHT OR LEFT HEATED DOOR MIRROR DOES NOT OPERATE

SYMPTOM CHART

Scheme 1

Scheme 1: INSPECTION PROCEDURE 1: None of the Heated Door Mirrors Operate
Scheme 1: INSPECTION PROCEDURE 1: None of the Heated Door Mirrors Operate

CIRCUIT OPERATION

If both of the door mirror heaters do not operate normally it may be due to a malfunction in the rear window defogger system.

TROUBLESHOOTING HINTS

  1. Malfunction of the rear window defogger system
  2. The wiring harness or connectors may have loose, corroded or damaged terminals, or terminals pushed back in the connector.

DIAGNOSIS

Required Special Tools

  1. MB991223: Test Harness Set
  1. STEP 1. Check the rear window defogger. Check that the rear window defogger works normally as follows. Turn the ignition switch to the "ON" position. Push the rear window defogger switch to operate the defogger. Q: Does the defogger work normally? YES: Go to Step 2. NO: Because of malfunction of the rear window defogger, carry out the troubleshooting (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#heating-air-conditioning-and-ventilation-except-lancer-evolution__diagnostic-trouble-code-chart) .
  2. STEP 2. Check the door mirror (RH) connector E-03 and rear window defogger relay connector C-306 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is the door mirror (RH) connector E-03 and rear window defogger relay connector C-306 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check if the door mirrors works normally.
  3. STEP 3. Check the wiring harness between the door mirror (RH) connector E-03 (terminal 5) and rear window defogger relay connector C-306 (terminal 3). NOTE: Also check intermediate connector C-115 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-115 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (RH) connector E-03 (terminal 5) and rear window defogger relay connector C-306 (terminal 3) in good condition? YES: Go to step 4. NO: Repair the wiring harness as necessary. Check if all heated door mirrors work normally.
  4. STEP 4. Check door mirror (LH) connector E-01. Q: Is the door mirror (LH) connector E-01 in good condition? YES: Go to Step 5. NO: Repair or replace the damaged component(s). Check if all heated door mirrors work normally.
  5. STEP 5. Check the wiring harness between door mirror (LH) connector E-01 (terminal 5) and rear window defogger relay connector C-306 (terminal 3). NOTE: Also check intermediate connector C-126 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-126 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (LH) connector E-01 (terminal 5) and rear window defogger relay connector C-306 (terminal 3) in good condition? YES: The procedure is complete. NO: Repair the wiring harness as necessary. Check if the all heated door mirrors work normally.

If either of the heated door mirror do not operate normally, it may be due to malfunctions in the heated door mirror circuit or door mirror.

  1. Malfunction of the heated door mirror circuit
  2. Malfunction of the door mirror
  3. The wiring harness or connectors may have loose, corroded or damaged terminals, or terminals pushed back in the connector.

Required Special Tools

  1. MB991223: Test Harness Set

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. STEP 1. Verify the operation of each heated door mirror. Q: Which door mirror does not heat? Door mirror (LH): Go to Step 2. Door mirror (RH): Go to Step 9 .
  2. STEP 2. Check door mirror (LH) connector E-01 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is door mirror (LH) connector E-01 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . And then check to see that the heater function of the door mirror (LH) operates normally.
  3. STEP 3. Check the heater of the door mirror (LH). CAUTION: When relocating the car between locations of extremely different temperatures (warm and cold), leave the car in a location for a while to adapt to the temperature prior to checking it. Check to see that the resistance between terminal 1 and 5 of the door mirror (LH) connector E-01. The resistance should be 8.4 ± 1.2 ohms at 25°C (77°F). Q: Is the resistance normal? YES: Go to Step 4. NO: Replace the door mirror (LH). And then check to see that the heater function of the door mirror (LH) is operating normally.
  4. STEP 4. Check the ground circuit between door mirror (LH) connector E-01 and ground for open circuit. Measure the resistance at door mirror (LH) connector E-01. Disconnect door mirror (LH) connector E-01 and check at the wiring harness side connector. Measure the resistance value between terminal 1 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 6 . NO: Go to Step 5.
  5. STEP 5. Check the wiring harness between door mirror (LH) connector E-01 (terminal 1) and ground. NOTE: Also check intermediate connector C-125 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-125 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (LH) connector E-01 (terminal 1) and ground in good condition? YES: No action is necessary and testing is complete. NO: The wiring harness may be damaged. Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (LH) operates normally.
  6. STEP 6. Measure the voltage at door mirror assembly (LH) connector E-01 Turn the ignition switch to the ON position. Turn on the rear window defogger switch. Disconnect the connector, and measure at the wiring harness side. Measure voltage between E-01 door mirror assembly (LH) connector terminal No. 5 and body ground. OK: Battery positive voltage Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Go to Step 7.
  7. STEP 7. Check rear window defogger relay connector C-306 for loose, corroded or damaged terminal, or terminals pushed back in the connector. Q: Is rear window defogger relay connector C-306 in good condition? YES: Go to Step 8. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . And then check to see that the heater function of the door mirror (LH) operates normally.
  8. STEP 8. Check the wiring harness between door mirror (LH) connector E-01 (terminal 5) and rear window defogger relay connector C-306 (terminal 3). NOTE: Also check intermediate connector C-126 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-126 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (LH) connector E-01 (terminal 5) and rear window defogger relay connector C-306 (terminal 3) in good condition? YES: No action is necessary and testing is complete. NO: Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (LH) operates normally.
  9. STEP 9. Check the door mirror (RH) connector E-03 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is the door mirror (RH) connector E-03 in good condition? YES: Go to Step 10. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . And then check to see that the heater function of the door mirror (RH) operates normally.
  10. STEP 10. Check the heater function of the door mirror (RH). CAUTION: When relocating the car between locations of extremely different temperatures (warm and cold), leave the car in a location for a while to adapt to the temperature prior to checking it. Check to see that the resistance between terminal 1 and 5 of the door mirror (RH) connector E-03. The resistance should be 8.4 ± 1.2 ohms at 25°C (77°F). Q: Is the resistance normal? YES: Go to Step 11. NO: Replace the door mirror (RH). And then check to see that the heater function of the door mirror (RH) operates normally.
  11. STEP 11. Check the ground circuit between door mirror (RH) connector E-03 and ground for open circuit. Measure the resistance at door mirror (RH) connector E-03. Disconnect door mirror (RH) connector E-03, and check at the wiring harness side connector. Measure the resistance value between terminal 1 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 13 . NO: Go to Step 12.
  12. STEP 12. Check the wiring harness between door mirror (RH) connector E-03 (terminal 1) and ground. NOTE: Also check intermediate connector C-114 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-114 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (RH) connector E-03 (terminal 1) and ground in good condition? YES: No action is necessary and testing is complete. NO: The wiring harness may be damaged. Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (RH) operates normally.
  13. STEP 13. Measure the voltage at door mirror assembly (RH) connector E-03 Turn the ignition switch to the ON position. Turn on the rear window defogger switch. Disconnect the connector, and measure at the wiring harness side. Measure voltage between E-03 door mirror assembly (RH) connector terminal No. 5 and body ground. OK: Battery positive voltage Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Go to Step 14.
  14. STEP 14. Check rear window defogger relay connector C-306 for loose, corroded or damaged terminal, or terminals pushed back in the connector. Q: Is rear window defogger relay connector C-306 in good condition? YES: Go to Step 15. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . And then check to see that the heater function of the door mirror (RH) operates normally.
  15. STEP 15. Check the wiring harness between door mirror (RH) connector E-03 (terminal 5) and rear window defogger relay connector C-306 (terminal 3). NOTE: Also check intermediate connector C-115 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-115 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between door mirror (RH) connector E-03 (terminal 5) and rear window defogger relay connector C-306 (terminal 3) in good condition? YES: No action is necessary and testing is complete. NO: Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (RH) operates normally.

Scheme 8

Scheme 8: REMOVAL AND INSTALLATION
Scheme 8: REMOVAL AND INSTALLATION

Scheme 9

Scheme 9
Scheme 9

<< A >> MIRROR REMOVAL

CAUTIONThe tab of the mirror is prone to breakage when working in cold temperatures. Always use a hair drier or the like to warm up the mirror tab and its periphery to 20°C (68°F) or higher prior to works. When the mirror is heated too quickly from its cold state, it may be broken.

Scheme 10

Scheme 10
Scheme 10
  1. Slant the mirror upward with your hands. Then insert a flat-tipped screwdriver wrapped with protective tape between the pivot plate and mirror through the cut-out from behind the mirror. Now pry off the mirror tab and release the lower side of the mirror as shown in the illustration.
  2. Release the upper side of the mirror from the tab as shown in illustration while pulling out the mirror.
  3. Disconnect the connectors of the heated mirror.

<< B >> DOOR MIRROR OUTER COVER REMOVAL

Remove the door mirror outer cover by disengaging the claws in the numerical order of the illustration from the mirror body side.

Scheme 11

Scheme 11: << B >> DOOR MIRROR OUTER COVER REMOVAL
Scheme 11: << B >> DOOR MIRROR OUTER COVER REMOVAL

>> A << DOOR MIRROR OUTER COVER INSTALLATION

CAUTIONTap the claw positions securely to confirm that they are engaged securely.

Install the door mirror outer cover by engaging the claws in the numerical order of the illustration.

Scheme 12

Scheme 12
Scheme 12

REMOTE CONTROLLED MIRROR OPERATION CHECK

Check that the mirror moves as described in the table when each terminal is connected to the battery.

Scheme 13

Scheme 13: REMOTE CONTROLLED MIRROR OPERATION CHECK
Scheme 13: REMOTE CONTROLLED MIRROR OPERATION CHECK
BATTERY CONNECTIONDIRECTION OPERATION
Connect terminal 8 to the negative battery terminal. Connect terminal 6 to the positive battery terminal.Up
Connect terminal 8 to the positive battery terminal. Connect terminal 6 to the negative battery terminal.Down
Connect terminal 8 to the negative battery terminal. Connect terminal 7 to the positive battery terminal.Right
Connect terminal 8 to the positive battery terminal. Connect terminal 7 to the negative battery terminal.Left

BATTERY CONNECTION

Scheme 14

Scheme 14: DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK
Scheme 14: DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK
SWITCH POSITIONTESTER CONNECTIONSPECIFIED CONDITION
OFF9 - 2, 9 - 3, 9 - 6, 9 - 10, 9 - 11, 1 - 2,1 - 3, 1 - 6, 1 - 10, 1 - 11Open circuit
Left sideOFF9 - 6, 9 - 10, 9 - 11, 1 - 6, 1 - 10, 1 - 11Open circuit
Up1 - 6, 9 - 11Continuity (Less than 2 ohms)
Down1 - 11, 6 - 9
Right1 - 6, 9 - 10
Left1 - 10, 6 - 9
Right sideOFF9 - 2, 9 - 3, 9 - 6, 1 - 2, 1 - 3, 1 - 6Open circuit
Up1 - 6, 3 - 9Continuity (Less than 2 ohms)
Down1 - 3, 6 - 9
Right1 - 6, 2 - 9
Left1 - 2, 6 - 9

TESTER CONNECTION

HEATED DOOR MIRROR CHECK

CAUTIONWhen relocating the car between locations with extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it.

Check that the resistance value between the connector terminals is at the standard value.

Standard value: 8.4 ± 1.2 ohms at 25°C (77°F)
