Rear Combination Light - Lancer Evolution Mitsubishi Lancer Evolution X

Exterior Lights 18 illustrations ~3801 words

Scheme 67

Scheme 67: GENERAL INFORMATION
Scheme 67: GENERAL INFORMATION
  1. The rear combination light assembly are integrated with the stop/taillight, rear turn-signal light and rear side-marker light.
  2. The taillight assembly are integrated with the taillight and back-up light.

SPECIAL TOOLS

SPECIAL TOOLS REFERENCE CHART Tool Tool number and name Supersession Application MB990784 Ornament remover General service tool Removal of trunk lid trim, rear combination light assembly, taillight assembly MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 M.U.T.-III sub-assembly Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: M.U.T.-III main harness A (MB991910) should be used. M.U.T.-III main harness B and C should not be used for this vehicle. DTC, data list and actuator test check. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Check harness LED harness LED harness adapter Probe General service tool (jumper) Continuity check and voltage measurement at harness wire or connector For checking connector pin contact pressure For checking power supply circuit For checking power supply circuit For connecting a locally sourced tester MB992006 Extra fine probe - Continuity check and voltage measurement at harness wire or connector

Scheme 68

Scheme 68: SPECIAL TOOLS
Scheme 68: SPECIAL TOOLS

Scheme 69

Scheme 69
Scheme 69

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

  1. MB991824: Vehicle Communication Interface (V.C.I.)
  2. MB991827: M.U.T.-III USB Cable
  3. MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 70

Scheme 70
Scheme 70
  1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
  2. Start up the personal computer.
  3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
  4. Connect special tool MB991910 to special tool MB991824.
  5. Connect special tool MB991910 to the data link connector.
  6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
  7. Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

  1. MB991824: Vehicle Communication Interface (V.C.I.)
  2. MB991827: M.U.T.-III USB Cable
  3. MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "System select" from the start-up screen.
  4. Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
  5. Select "ETACS" from "System List", and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
  6. Select "Diagnostic Trouble Code." to read the DTC.
  7. If a DTC is set, it is shown.
  8. Choose "Erase DTCs" to erase the DTC.

DIAGNOSTIC TROUBLE CODE CHART

CAUTIONOn troubleshooting, if the ignition switch is turned ON while disconnecting connector(s), diagnostic trouble code(s) associated with other system may be set. On completion, confirm all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Diagnostic trouble code No.Diagnostic item
B16A0Taillight (RH) circuit open (Open circuit in taillight (RH) or position light (RH))
B16A7Taillight (RH) circuit short (Short circuit in taillight (RH) or position light (RH))
B16A1Taillight (LH) circuit open (Open circuit in taillight (LH), position light (LH), or license plate light)
B16A8Taillight (LH) circuit short (Short circuit in taillight (LH), position light (LH), or license plate light)

DIAGNOSTIC TROUBLE CODE CHART

Scheme 71

Scheme 71: DTC B16A0: Taillight (RH) circuit open (Open circuit in rear side marker light (RH), taillight (RH)
Scheme 71: DTC B16A0: Taillight (RH) circuit open (Open circuit in rear side marker light (RH), taillight (RH)

TROUBLE JUDGMENT

When an open circuit is detected in the rear side marker light, taillight or position light circuit, the ETACS-ECU sets DTC B16A0. If a short circuit is detected, DTC B16A7 is set.

TECHNICAL DESCRIPTION (COMMENT)

The problem detection of rear side marker light, taillight or position light is made based on the digital feed back signal (input signal to ETACS-ECU) which operates the rear side marker light, taillight or position light. When the ignition switch is "ON", the ETACS-ECU determines the rear side marker light, taillight or position light circuit state from the load placed on the line. After 100 ms has elapsed since the start of the check, the ETACS-ECU performs a sampling with each 10 ms. If an abnormality is detected, it increases the counter by 2, and when no abnormality is detected, it decreases the counter by 1. Once the counter reaches "10", the ETACS-ECU sets the DTC B16A0 if the load is detected on the line, and sets the DTC B16A7 if no load is detected.

TROUBLESHOOTING HINTS

  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. Malfunction of bulbs
  3. Malfunction of the ETACS-ECU

DIAGNOSIS

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74
  1. STEP 1. Bulb check. Check the bulb(s) of the light that does not illuminate. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the bulb(s) of the light that does not illuminate.
  2. STEP 2. Check headlight assembly (RH) connector A-57, rear combination light (RH) connector F-06 and rear side marker light (RH) connector F-07 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight assembly (RH) connector A-57, rear combination light (RH) connector F-06 and rear side marker light (RH) connector F-07 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  3. STEP 3. Resistance measurement at headlight assembly (RH) connector A-57, rear combination light (RH) connector F-06 and rear side marker light (RH) connector F-07. Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector of light which does not illuminate and the body ground. Measure the resistance between headlight assembly (RH) connector A-57 (terminal 6) and the body ground. Measure the resistance between rear combination light (RH) connector F-06 (terminal 1) and the body ground. Measure the resistance between rear side marker light (RH) connector F-07 (terminal 1) and the body ground. OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Check the wiring harness between headlight assembly connector, rear combination light connector or tail light connector and the body ground. Check the ground line for open circuit. Check the wiring harness between headlight assembly (RH) connector A-57 (terminal 6) and the body ground. Check the wiring harness between rear combination light (RH) connector F-06 (terminal 1) and the body ground. Check the wiring harness between rear side marker light (RH) connector F-07 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-27 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-27 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector or tail light connector and the body ground in good condition? YES: Go to Step 7 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  5. STEP 5. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connectors C-304 and C-311 in good condition? YES: Go to Step 6. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  6. STEP 6. Check wiring harness between headlight assembly connector, rear combination light connector and rear side marker light connector and ETACS-ECU connector. Check the power supply line for open circuit or short circuit. Check the wiring harness between headlight assembly (RH) connector A-57 (terminal 4) and ETACS-ECU connector C-304 (terminal 7). Check the wiring harness between rear combination light (RH) connector F-06 (terminal 3) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connectors D-11 and joint connector C-43 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 or joint connector C-43 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Check the wiring harness between rear side marker light (RH) connector F-07 (terminal 2) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connectors D-17 and F-27 and joint connector C-43 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-17 or F-27 or joint connector C-43 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector or rear side marker light connector and ETACS-ECU connector in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  7. STEP 7. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-lights/#rear-combination-light-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

Scheme 75

Scheme 75: DTC B16A1: Taillight (LH) circuit open (Open circuit in rear side marker light (LH), taillight (LH),
Scheme 75: DTC B16A1: Taillight (LH) circuit open (Open circuit in rear side marker light (LH), taillight (LH),

When an open circuit is detected in the taillight, position light or license plate light circuit, the ETACS-ECU sets DTC B16A1. If a short circuit is detected, DTC B16A8 is set.

The problem detection of rear side marker light, taillight, position light or license plate light is made based on the digital feed back signal (input signal to ETACS-ECU) which operates the rear side marker light, taillight, position light or license plate light. When the ignition switch is "ON", the ETACS-ECU determines the rear side marker light, taillight, position light or license plate light circuit state from the load placed on the line. After 100 ms has elapsed since the start of the check, the ETACS-ECU performs a sampling with each 10 ms. If an abnormality is detected, it increases the counter by 2, and when no abnormality is detected, it decreases the counter by 1. Once the counter reaches "10", the ETACS-ECU sets the DTC B16A1 if the load is detected on the line, and sets the DTC B16A8 if no load is detected.

  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. Malfunction of bulbs
  3. Malfunction of the ETACS-ECU

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80
  1. STEP 1. Bulb check. Check the bulb(s) of the light that does not illuminate. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the bulb(s) of the light that does not illuminate.
  2. STEP 2. Check headlight assembly (LH) connector A-40, rear combination light (LH) connector F-25, rear side marker light (LH) connector F-24, license plate light connector F-18 (LH) and F-15 (RH) for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight assembly (LH) connector A-40, rear combination light (LH) connector F-25, rear side marker light (LH) connector F-24, license plate light connector F-18 (LH) and F-15 (RH) in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  3. STEP 3. Resistance measurement at headlight assembly (LH) connector A-40, rear combination light (LH) connector F-25, rear side marker light (LH) connector F-24, license plate light connector F-18 (LH) and F-15 (RH). Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector of light which does not illuminate and the body ground. Measure the resistance between headlight assembly (LH) connector A-40 (terminal 6) and the body ground. Measure the resistance between rear combination light (LH) connector F-25 (terminal 1) and the body ground. Measure the resistance between rear side marker light (LH) connector F-24 (terminal 1) and the body ground. Measure the resistance between license plate light (LH) connector F-18 (terminal 1) and the body ground. Measure the resistance between license plate light (RH) connector F-15 (terminal 1) and the body ground. OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Check the wiring harness between headlight assembly connector, rear combination light connector, tail light connector or license plate light and the body ground. Check the ground line for open circuit. Check the wiring harness between headlight assembly (LH) connector A-40 (terminal 6) and the body ground. Check the wiring harness between rear combination light (LH) connector F-25 (terminal 1) and the body ground. Check the wiring harness between rear side marker light (LH) connector F-24 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-27 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-27 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Check the wiring harness between license plate light (LH) connector F-18 (terminal 1) and the body ground. Check the wiring harness between license plate light (RH) connector F-15 (terminal 1) and the body ground. Q: Is the wiring harness between headlight assembly connector, rear combination light connector, tail light connector or license plate light and the body ground in good condition? YES: Go to Step 7 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  5. STEP 5. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connectors C-304 and C-311 in good condition? YES: Go to Step 6. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  6. STEP 6. Check wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light and ETACS-ECU connector. Check the power supply line for open circuit or short circuit. Check the wiring harness between headlight assembly (LH) connector A-40 (terminal 4) and ETACS-ECU connector C-304 (terminal 3). Check the wiring harness between rear combination light (LH) connector F-25 (terminal 3) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-17 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-17 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Check the wiring harness between rear side marker light (LH) connector F-24 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-17 and F-27 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-17 or F-27 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Check the wiring harness between license plate light (LH) connector F-18 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-17 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-17 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Check the wiring harness between license plate light (RH) connector F-15 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-17 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-17 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light and ETACS-ECU connector in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  7. STEP 7. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-lights/#rear-combination-light-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

TROUBLE SYMPTOM CHART

Inspection Procedure No.Trouble symptomReference
1None of taillights illuminates.INSPECTION PROCEDURE 1: NONE OF TAILLIGHTS ILLUMINATES.
2One of the taillights does not illuminate.INSPECTION PROCEDURE 2: ONE OF THE TAILLIGHTS DOES NOT ILLUMINATE.

TROUBLE SYMPTOM CHART

Inspection Procedure 1: None of taillights illuminates

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If none of taillights illuminates, the taillight switch input circuit or ETACS-ECU may have a problem.

  1. Malfunction of column switch
  2. Malfunction of the ETACS-ECU
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. License plate light operation check Check that the license plate light illuminates normally. Q: Does license plate light work normally? YES: Go to Step 2. NO: Replace the ETACS-ECU.
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-lights/#rear-combination-light-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check data list. Use the ETACS-ECU data list to check the signals related to the taillight illumination. Turn the ignition switch to the "ACC" position. Turn the taillight switch to the "ON" position. ITEM REFERENCE CHART Item No. Item name Normal conditions Item 218 Taillight ON Q: Does scan tool MB991958 display the items "Taillight" as normal condition? YES: Go to Step 4. NO: Troubleshoot the ETACS-ECU (Refer to «TROUBLE SYMPTOM CHART FOR INPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-lancer-evolution__trouble-symptom-chart-for-input-signal) ).
  4. STEP 4. Retest the system Check that the taillight illuminates normally. Q: Does the taillight work normally? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Scheme 81

Scheme 81: Inspection Procedure 2: One of the taillights does not illuminate
Scheme 81: Inspection Procedure 2: One of the taillights does not illuminate

If one of the taillights does not Illuminate, the wiring harness, connector(s), or rear combination light unit may have a problem, or the fuse may be burned out.

  1. Malfunction of rear combination light unit
  2. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 82

Scheme 82
Scheme 82
  1. STEP 1. Check rear combination light connector F-25 (LH) or F-06 (RH) for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is rear combination light connector F-25 (RH) or F-06 (LH) in good condition? YES: Go to Step 2. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  2. STEP 2. Resistance measurement at rear combination light connector F-25 (LH) or F-06 (RH). Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector of light which does not illuminate and body ground. Measure the resistance between rear combination light (LH) connector F-25 (terminal 1) and body ground. Measure the resistance between rear combination light (RH) connector F-06 (terminal 1) and body ground. OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 4 . NO: Go to Step 3.
  3. STEP 3. Check the wiring harness between rear combination light connectors F-25 (LH) (terminal 1) or F-06 (RH) (terminal 1) and ground. Check the ground wires for open circuit. Q: Is the wiring harness between rear combination light connectors F-25 (LH) (terminal 1) or F-06 (RH) (terminal 1) and ground in good condition? YES: Go to Step 6 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  4. STEP 4. Check ETACS-ECU connectors C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connectors C-311 in good condition? YES: Go to Step 5. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) .
  5. STEP 5. Check the wiring harness between rear combination light connector and ETACS-ECU connector. Check the power supply line for open circuit. Check the wiring harness between rear combination light (LH) connector F-25 (terminal 3) and ETACS-ECU connector C-311 (terminal 10). Check the wiring harness between rear combination light (RH) connector F-06 (terminal 3) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check joint connector C-43 and intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector C-43 or intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-lancer-evolution) . Q: Is the wiring harness between rear combination light connector and ETACS-ECU connector in good condition? YES: Go to Step 6. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
  6. STEP 6. Retest the system. Check that the taillight illuminates normally. Q: Does the taillight work normally? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the defective rear combination light unit.

Scheme 83

Scheme 83: REAR COMBINATION LIGHT REMOVAL AND INSTALLATION
Scheme 83: REAR COMBINATION LIGHT REMOVAL AND INSTALLATION

Scheme 84

Scheme 84: TAILLIGHT REMOVAL AND INSTALLATION
Scheme 84: TAILLIGHT REMOVAL AND INSTALLATION
