Oem Splice Locations - Except Lancer Evolution — Mitsubishi Lancer Evolution X (2007-2016)

HOW TO READ SPLICE LOCATIONS

"Splice locations" describes splice points of each wiring harness on an actual vehicle. Some variations are included in one splice location. Accordingly, some locations may not be applicable for individual vehicles.

Scheme 541

Scheme 541: HOW TO READ SPLICE LOCATIONS

INDEX

This index shows the illustrations in this article where the splice locations are shown.

Splice location NO.	Refer to	Splice location NO.	Refer to	Splice location NO.	Refer to	Splice location NO.	Refer to
S001	ENGINE COMPARTMENT < NON-TURBO > (1)	S002	ENGINE COMPARTMENT < NON-TURBO > (1)	S003	ENGINE COMPARTMENT < NON-TURBO >	S004	ENGINE COMPARTMENT < NON-TURBO >
S001	ENGINE COMPARTMENT < TURBO > (2)	S002	ENGINE COMPARTMENT < TURBO > (2)	S003	ENGINE COMPARTMENT < NON-TURBO >	S004	ENGINE COMPARTMENT < NON-TURBO >
S006	ENGINE COMPARTMENT < NON-TURBO >	S007	ENGINE COMPARTMENT < NON-TURBO >	S008	ENGINE COMPARTMENT < NON-TURBO > (1)	S009	ENGINE COMPARTMENT < NON-TURBO > (1)
S006	ENGINE COMPARTMENT < NON-TURBO >	S007	ENGINE COMPARTMENT < NON-TURBO >	S008	ENGINE COMPARTMENT < TURBO > (2)	S009	ENGINE COMPARTMENT < TURBO > (2)
S010	ENGINE COMPARTMENT < TURBO >	S011	ENGINE COMPARTMENT < TURBO >	S012	ENGINE COMPARTMENT < TURBO >	S013	ENGINE COMPARTMENT < TURBO >
S014	ENGINE COMPARTMENT < TURBO >	S015	ENGINE COMPARTMENT < TURBO >	S016	ENGINE COMPARTMENT < TURBO >	S017	ENGINE COMPARTMENT < TURBO >
S018	ENGINE COMPARTMENT < TURBO >	S019	ENGINE AND TRANSAXLE < TURBO >	S020	ENGINE AND TRANSAXLE < TURBO >	S021	ENGINE AND TRANSAXLE < TURBO >
S022	ENGINE AND TRANSAXLE < TURBO >	S025	ENGINE AND TRANSAXLE < TURBO >	S027	ENGINE AND TRANSAXLE < TURBO >	S028	ENGINE AND TRANSAXLE < TURBO >
S030	ENGINE AND TRANSAXLE < TURBO >	S031	ENGINE AND TRANSAXLE < TURBO >	S032	ENGINE AND TRANSAXLE < TURBO >	S033	ENGINE AND TRANSAXLE < TURBO >
S039	ENGINE AND TRANSAXLE < TURBO >	S040	ENGINE AND TRANSAXLE < TURBO >	S041	ENGINE AND TRANSAXLE < TURBO >	S042	ENGINE AND TRANSAXLE < TURBO >
S043	ENGINE AND TRANSAXLE < TURBO >	S044	ENGINE AND TRANSAXLE < TURBO >	S045	ENGINE AND TRANSAXLE < TURBO >	S046	ENGINE AND TRANSAXLE < TURBO >
S047	ENGINE AND TRANSAXLE < TURBO >	S048	ENGINE AND TRANSAXLE < TURBO >	S049	STEERING COLUMN (3)	S050	STEERING COLUMN (3)
S047	ENGINE AND TRANSAXLE < TURBO >	S048	ENGINE AND TRANSAXLE < TURBO >	S049	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S050	FLOOR AND ROOF < LANCER SPORTBACK > (4)
S051	STEERING COLUMN (3)	S052	STEERING COLUMN (3)	S053	STEERING COLUMN (3)	S055	FLOOR AND ROOF < LANCER SPORTBACK >
S051	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S052	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S053	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S055	FLOOR AND ROOF < LANCER SPORTBACK >
S056	FLOOR AND ROOF < LANCER SPORTBACK >	S057	FLOOR AND ROOF < LANCER SPORTBACK >	S058	FLOOR AND ROOF < LANCER SPORTBACK >	S059	FLOOR AND ROOF < LANCER SPORTBACK >
S060	LUGGAGE COMPARTMENT < LANCER > (3)	S061	LUGGAGE COMPARTMENT < LANCER > (3)	S062	LUGGAGE COMPARTMENT < LANCER > (3)	S063	LUGGAGE COMPARTMENT < LANCER > (3)
S060	LUGGAGE COMPARTMENT < LANCER > (4)	S061	LUGGAGE COMPARTMENT < LANCER > (4)	S062	LUGGAGE COMPARTMENT < LANCER > (4)	S063	LUGGAGE COMPARTMENT < LANCER > (4)
S064	LUGGAGE COMPARTMENT < LANCER > (3)	S065	LUGGAGE COMPARTMENT < LANCER > (3)	S066	LUGGAGE COMPARTMENT < LANCER > (3)	S067	ENGINE AND TRANSAXLE < TURBO >
S064	LUGGAGE COMPARTMENT < LANCER > (4)	S065	LUGGAGE COMPARTMENT < LANCER > (4)	S066	LUGGAGE COMPARTMENT < LANCER > (4)	S067	ENGINE AND TRANSAXLE < TURBO >
S068	ENGINE COMPARTMENT < TURBO >	S069	ENGINE COMPARTMENT < TURBO >	S070	ENGINE COMPARTMENT < TURBO >	S071	ENGINE COMPARTMENT < NON-TURBO > (1) ENGINE COMPARTMENT < TURBO > (2)
S072	ENGINE AND TRANSAXLE < TURBO >	S073	ENGINE AND TRANSAXLE < TURBO >	S074	ENGINE AND TRANSAXLE < TURBO >	S075	ENGINE AND TRANSAXLE < TURBO >
S076	ENGINE AND TRANSAXLE < TURBO >	S077	ENGINE COMPARTMENT < NON-TURBO >	S078	ENGINE AND TRANSAXLE < TURBO >	S079	ENGINE AND TRANSAXLE < TURBO >
S080	ENGINE AND TRANSAXLE < TURBO >	S081	ENGINE AND TRANSAXLE < TURBO >	S082	ENGINE AND TRANSAXLE < TURBO >	S083	ENGINE AND TRANSAXLE < TURBO >
S084	ENGINE AND TRANSAXLE < TURBO >	S085	STEERING COLUMN (3) FLOOR AND ROOF < LANCER SPORTBACK > (4)	S088	ENGINE AND TRANSAXLE < TURBO >	S089	ENGINE AND TRANSAXLE < TURBO >
S090	ENGINE AND TRANSAXLE < TURBO >	S091	ENGINE AND TRANSAXLE < TURBO >	S092	STEERING COLUMN (3) FLOOR AND ROOF < LANCER SPORTBACK > (4)	S093	STEERING COLUMN
S094	STEERING COLUMN	S095	LUGGAGE COMPARTMENT < LANCER >	S096	FLOOR AND ROOF < LANCER SPORTBACK >	S102	ENGINE AND TRANSAXLE < TURBO >
S103	ENGINE COMPARTMENT < NON-TURBO >	S104	ENGINE COMPARTMENT < TURBO >	S105	ENGINE AND TRANSAXLE < TURBO >	S106	STEERING COLUMN (3) FLOOR AND ROOF < LANCER SPORTBACK > (4)
S107	ENGINE COMPARTMENT < NON-TURBO > (1) ENGINE COMPARTMENT < TURBO > (2)	S108	ENGINE COMPARTMENT < TURBO >	S109	ENGINE AND TRANSAXLE < TURBO >	S110	ENGINE AND TRANSAXLE < TURBO >
S111	ENGINE AND TRANSAXLE < TURBO >	S112	ENGINE AND TRANSAXLE < TURBO >	S113	STEERING COLUMN (3)	S114	STEERING COLUMN (3)
S111	ENGINE AND TRANSAXLE < TURBO >	S112	ENGINE AND TRANSAXLE < TURBO >	S113	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S114	FLOOR AND ROOF < LANCER SPORTBACK > (4)
S115	STEERING COLUMN (3)	S116	ENGINE AND TRANSAXLE < TURBO >	S117	STEERING COLUMN (3)	S118	ENGINE AND TRANSAXLE < TURBO >
S115	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S116	ENGINE AND TRANSAXLE < TURBO >	S117	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S118	ENGINE AND TRANSAXLE < TURBO >
S119	STEERING COLUMN (3)	S120	STEERING COLUMN (3)	S121	ENGINE AND TRANSAXLE < TURBO >	S122	ENGINE AND TRANSAXLE < TURBO >
S119	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S120	FLOOR AND ROOF < LANCER SPORTBACK > (4)	S121	ENGINE AND TRANSAXLE < TURBO >	S122	ENGINE AND TRANSAXLE < TURBO >
S123	ENGINE AND TRANSAXLE < TURBO >	S124	ENGINE AND TRANSAXLE < TURBO >	S125	ENGINE AND TRANSAXLE < TURBO >	S126	ENGINE AND TRANSAXLE < TURBO >
S127	ENGINE AND TRANSAXLE < TURBO >	S128	ENGINE AND TRANSAXLE < TURBO >	S129	ENGINE AND TRANSAXLE < TURBO >	S130	STEERING COLUMN (3) FLOOR AND ROOF < LANCER SPORTBACK > (4)
S131	ENGINE AND TRANSAXLE < TURBO >
(1) NON-TURBO (2) TURBO (3) LANCER (4) LANCER SPORTBACK
