SERVICE SPECIFICATIONS
| Item | Specification | |
|---|---|---|
| 75D23L | ||
| Voltage V | 12 | |
| Capacity (5-hour rate) Ah | 52 | |
| Electrolytic fluid specific gravity [fully charged state at 20°C (68°F)] | 1.220 - 1.290 | |
| Battery current sensor resistance (ohms) | Current sensor resistance value | Between terminal No. 1 - 3: 3 - 10 k |
| Between terminal No. 1 - 4: less than 0.5 k | ||
| Between terminal No. 3 - 4: 3 - 10 k | ||
| Temperature sensor resistance value | 4.5 - 7.2 k (when 0°C) | |
| 1.6 - 2.5 k (when 25°C) | ||
| 0.96 - 1.40 k (when 40°C) | ||
SERVICE SPECIFICATIONS
BATTERY CHECK
| WARNING | Battery posts, terminals and related accessories contain lead and lead compounds. WASH HANDS AFTER HANDLING. |
BATTERY VISUAL INSPECTION (1)
The battery contains a visual test indicator which gives a blue signal when an adequate charge level exists, and a white signal when charging is required.
BATTERY VISUAL INSPECTION (2)
Make sure the ignition switch is in "LOCK" (OFF) position and all battery fed accessories are OFF.
Scheme 42
- Disconnect the negative cable from battery before disconnecting the positive cable. WARNING: Care should be taken in the event battery case is cracked or leaking to protect hands from the electrolyte. A suitable pair of rubber gloves (not the household type) should be worn when removing battery by hand.
- Remove the battery from the vehicle.
- Inspect the battery carrier for damage caused by loss of acid from battery. If acid damage is present, it is necessary to clean area with a solution of clean warm water and baking soda. Scrub area with a stiff bristle brush. Wipe clean with a cloth moistened with ammonia or baking soda in water.
- Clean the battery, especially the top, with the same solutions as described in step 3 .
- Inspect the battery case and cover for cracks. If cracks are present, battery must be replaced.
- Clean the battery post with a suitable battery post cleaning tool.
- Clean the inside surfaces of the terminal clamps with a suitable battery terminal cleaning tool. Replace damaged or frayed cables and broken terminal clamps.
- Install the battery in the vehicle.
- Connect the positive and negative cables to the battery in the order of mention.
- Tighten the clamp nut securely.
BATTERY CHARGING
| WARNING | When batteries are being charged, an explosive gas forms beneath the cover of each cell. Do not smoke near batteries on charge or which have recently been charged. Do not break live circuits at the terminals of the batteries on charge. A spark will occur where the live circuit is broken. Keep all open flames away from the battery. |
Battery electrolyte temperature may temporarily be allowed to rise to 55°C (131°F). Increase of electrolyte temperature above 55°C (131°F) is harmful to the battery, causing deformation of battery cell, decrease in life of battery, etc.
CHARGE RATE
Recommended rate and time for fully discharged condition (flat discharged) is shown in table below. When the specific gravity of electrolyte keeps 1.22 to 1.29 for more than one hour, charging should be stopped.
Charge Rate Chart
| Item | Charging time |
|---|---|
| 75D23L | |
| Slow charging | 5 amps 11 hours |
| 10 amps 6 hours | |
| Fast charging | 20 amps 3 hours |
| 30 amps 2 hours |
CHARGE RATE CHART
BATTERY TESTING PROCEDURE
- STEP 1. Check the battery cables. Remove the negative cable, then the positive cable. Check for dirty or corroded connections. Q: Are the battery cables dirty or have corroded connections? YES: Clean the battery cables. Then go to Step 2. NO: Go to Step 2.
- STEP 2. Check the battery post. Check for loose battery post. Q: Are the battery posts faulty? YES: Replace the battery. Then go to Step 4 . NO: Go to Step 3.
- STEP 3. Check the battery case. Remove the hold-downs. Check for broken/cracked case. Q: Is the battery case faulty? YES: Replace the battery. Then go to Step 4. NO: Go to Step 4.
- STEP 4. Check the open circuit voltage. Turn headlights on for 15 seconds. Turn headlights off for two minutes to allow battery positive voltage to stabilize. Disconnect the battery cables. Read open circuit voltage. Q: Is open circuit voltage 12.4 volts or more? YES: Go to Step 6 . NO: Go to Step 5.
- STEP 5. Battery charging Charge the battery. (See «CHARGE RATE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#battery-except-lancer-evolution__charge-rate-chart) ) Q: Is open circuit voltage 12.4 volts or more? YES: Go to Step 6. NO: Replace the battery.
- STEP 6. Check the load test. Connect a load tester to the battery. Load the battery at the recommended discharge rate (See «LOAD TEST RATE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#battery-except-lancer-evolution__load-test-rate-chart) ) for 15 seconds. Read voltage after 15 seconds, then remove load. Compare the measured value with the minimum voltage. (See «LOAD TEST CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#battery-except-lancer-evolution__load-test-chart) .) Q: Is the voltage higher than minimum voltage? YES: The battery is normal. NO: Replace the battery.
LOAD TEST RATE CHART
| Application | Load test | Cranking ratio [-18°C (0°F)] | Reserve capacity |
|---|---|---|---|
| 75D23L | 260 amps | 520 amps | 118 minutes |
LOAD TEST RATE CHART
LOAD TEST CHART
| Temperature °C (°F) | 21 (70) AND ABOVE | 16 (60) | 10 (50) | 4 (40) | 1 (30) | 7 (20) | 12 (10) | 18 (0) |
|---|---|---|---|---|---|---|---|---|
| Minimum voltage | 9.6 | 9.5 | 9.4 | 9.3 | 9.1 | 8.9 | 8.7 | 8.5 |
LOAD TEST CHART
BATTERY REMOVAL AND INSTALLATION
| CAUTION | When the battery current sensor and the engine control module are replaced, make the battery current sensor learn the neutral point by using the scan tool. (Refer to BATTERY CURRENT SENSOR CALIBRATION < NON-TURBO > .) |
Scheme 43
Scheme 44
CURRENT SENSOR RESISTANCE VALUE
Use the circuit tester to measure the resistance value between battery current sensor connector terminals.
Standard value
| Terminal No. (positive terminal - negative terminal) | Resistance (kohms) |
|---|---|
| 1 - 3 | 3 - 10 |
| 1 - 4 | Less than 0.5 |
| 3 - 4 | 3 - 10 |
BATTERY CURRENT SENSOR RESISTANCE CHECK
Scheme 45
TEMPERATURE SENSOR RESISTANCE VALUE
Using the circuit tester, measure the resistance value between the battery current sensor connector terminal No. 2 and No. 3.
Standard value
| Temperature (°C) | Resistance (kohms) |
|---|---|
| 0 | 4.5 - 7.2 |
| 25 | 1.6 - 2.5 |
| 40 | 0.96 - 1.40 |
BATTERY TEMPERATURE SENSOR RESISTANCE CHECK
