HOW TO READ CIRCUIT DIAGRAMS
The circuit of each system from the fuse (or fusible link) to ground is shown. The power supply is shown at the top and the ground at the bottom to facilitate understanding of how the current flows. Some variations are included in one circuit diagram. Accordingly, some diagrams may not be applicable for individual vehicles. The circuit diagrams show the state when switches are operated.
Scheme 553
Scheme 554
CONNECTOR/GROUNDING INDICATIONS
Scheme 555
CONNECTOR/GROUNDING MARKINGS REFERENCE CHART Item No. Connector/Grounding Symbol Contents Connector and terminal marking 1 The male and female terminals are indicated as shown. The connector with male terminal(s) is called as male connector and indicated by two connector contour lines, while the connector with female terminal(s) is called as female connector and indicated by single connector contour line. Connector symbol marking 2 The symbol indicates the connector is viewed as shown. At a device connection, the connector symbol on the device side is shown. For an intermediate connector, the male connector symbol is shown. For spare connectors and check connectors, no device is connected, and so the harness-side connector symbol is shown for these connectors. However, a data link connector is exceptional. Connector connection marking 3 Connection between a device and the harness is either by direct insertion in the device (direct connection type) or by connection with a harness connector furnished on the device side (harness connection type). The two types are indicated as illustrated. 4 5 Ground marking 6 Grounding is either by body ground, device ground or control unit interior ground. These are indicated as illustrated. 7 8
Scheme 556
Scheme 557
Scheme 558
Scheme 559
Scheme 560
Scheme 561
Scheme 562
Scheme 563
Scheme 564
Scheme 565
Scheme 566
Scheme 567
Scheme 568
Scheme 569
SYMBOLS (EXCEPT CONNECTOR AND GROUNDING)
Devices appearing in circuit diagrams are indicated by the following symbols.
Scheme 570
WIRE COLOR CODES
Wire colors are identified by the following color codes.
| Code | Wire color |
|---|---|
| B | Black |
| BR | Brown |
| G | Green |
| GR | Gray |
| L | Blue |
| LG | Light green |
| O | Orange |
| P | Pink |
| PU | Purple |
| R | Red |
| SB | Sky blue |
| SI | Silver |
| V | Violet |
| W | White |
| Y | Yellow |
WIRE COLOR CODES REFERENCE CHART
If a cable has two colors, the first of the two color code characters indicates the basic color (color of the cable coating) and the second indicates the marking (tracer) color.
| No. | Meaning |
|---|---|
| 1 | Flexible wire |
| Twisted wire | |
| 2 | Wire size (mm 2 ) (1) |
| 3 | Basic color (color of the cable coating) |
| 4 | Marking color |
| (1) No code indicates 0.5 mm 2 (0.0008 in 2 ). Cable color code in parentheses indicates 0.3 mm 2 (0.0005 in 2 ). | |
| (1) | No code indicates 0.5 mm 2 (0.0008 in 2 ). Cable color code in parentheses indicates 0.3 mm 2 (0.0005 in 2 ). |
WIRE TYPE, WIRE SIZE, BASIC COLOR, AND MARKING COLOR CHART
Scheme 571
Scheme 572
Scheme 573
Scheme 574
Scheme 575
JOINT CONNECTOR
Note. IN THE ACTUAL VEHICLES, SOME OF THE J/C TERMINALS IN THE SAME BUS ARE USED, SO IN SOME CASES, THE TERMINAL ARRANGEMENT INDICATED ON THE CIRCUIT DIAGRAMS DOES NOT AGREE WITH THE ONES IN THE ACTUAL VEHICLES. AS FOR J/C (CAN1, 2, 3, 4), REFER TO CONTROLLER AREA NETWORK (CAN) or CONTROLLER AREA NETWORK (CAN) . IN ADDITION, ON J/C (CAN1, 2, 3, 4), THE TERMINAL NUMBERS INDICATED ON THE CIRCUIT DIAGRAMS SHOULD ALWAYS AGREE WITH THE TERMINAL ARRANGEMENT IN THE ACTUAL VEHICLES.
Scheme 576
ENGINE COMPARTMENT
| No. | Power supply circuit | Name | Rated capacity (A) | Housing color | Load circuit |
|---|---|---|---|---|---|
| 1 | Fusible link No. 36 | Fuse | 15 | Blue | Fog light and fog light relay |
| 2 | 7.5 | Brown | Engine control module | ||
| 3 | 20 | Yellow | Primary pulley speed sensor , secondary pulley speed sensor , shift lever , transaxle assembly and transaxle control module | ||
| 4 | 10 | Red | Horn and horn relay | ||
| 5 | 7.5 | Brown | Generator | ||
| 6 | 20 | Yellow | |||
| 7 | 10 | Red | A/C compressor assembly and A/C compressor clutch relay | ||
| 8 | 15 | Blue | Engine control module | ||
| 9 | 20 | Yellow | |||
| 10 | |||||
| 11 | |||||
| 12 | |||||
| 13 | 10 | Red | Headlight assembly (LH/RH) and daytime running light relay | ||
| 14 | Headlight relay (High) | 10 | Red | Headlight assembly (LH) | |
| 15 | 10 | Red | Headlight assembly (RH) | ||
| 16 | Headlight relay (Low) | 20 | Yellow | Headlight assembly (LH) | |
| 17 | 20 | Yellow | Headlight assembly (RH) | ||
| 18 | 10 | Red | Headlight assembly (LH), headlight assembly (RH) and headlight leveling switch | ||
| 19 | 10 | Red | Headlight assembly (RH) | ||
| 20 | MFI relay | ||||
| 21 | 10 | Red | No. 1 to 4 ignition coil and capacitor | ||
| 22 | 20 | Yellow | Engine control module, engine oil control valve, evaporative emission purge solenoid, evaporative emission ventilation solenoid, exhaust gas recirculation valve, No. 1 to 4 injector, mass airflow sensor, heated oxygen sensor, linear air-fuel ratio sensor, throttle actuator control motor relay, turbocharger wastegate solenoid and vehicle speed sensor | ||
| 23 | 15 (1) 20 (2) | Blue (1) Yellow (2) | Fuel pump circuit resistor , No. 1 fuel pump relay and fuel pump module | ||
| 24 | Fusible link No. 36 | Fusible link | 30 | Pink | Starter |
| 25 | |||||
| 26 | 40 | Green | ASC-ECU | ||
| 27 | 30 | Pink | ASC-ECU | ||
| 28 | 30 | Pink | Condenser fan motor, condenser fan relay and fan control relay | ||
| 29 | 40 | Green | Radiator fan motor and radiator fan relay | ||
| 30 | Fuse | 30 | Green | Fuse No. 7 to 9 in passenger compartment | |
| 31 | 30 | Green | Audio amplifier | ||
| 32 | MFI relay | ||||
| 33 | Battery/Generator | Fusible link | 120 (1) 140 (2) | Fusible link No. 37/Fusible link No. 34 to 36 | |
| 34 | Battery/Fusible link No. 33 | 80 | Fuse No. 2, 4, 5, 10 to 12, 14, 15, 17, 18, 25 in passenger compartment, ETACS-ECU, ETACS-ECU (ACC relay 3) and fusible link No. 20 in passenger compartment | ||
| 35 | 80 | Electric power steering-ECU and electric pump | |||
| 36 | 120 | Fuse No. 1 to 8, 13 to 19, 21 to 23, 30, 31 in engine compartment, fusible link No. 24, 26 to 29 in engine compartment, headlight relay (High), headlight relay (Low) and MFI relay | |||
| 37 | Fusible link No. 33/Generator | 80 | Fusible link No. 1 and 21, Fuse No. 3, 6, 13, 16, 19 in passenger compartment and ETACS-ECU (ACC relay 2, blower relay) | ||
| (1) Non-turbo (2) Turbo | |||||
| (1) | Non-turbo |
| (2) | Turbo |
FUSIBLE LINK AND FUSE REFERENCE CHART (ENGINE COMPARTMENT)
Scheme 577
Scheme 578
Scheme 579
PASSENGER COMPARTMENT
| No. | Power supply circuit | Name | Rated capacity (A) | Housing color | Load circuit |
|---|---|---|---|---|---|
| 1 | Fusible link No. 37 | Fusible link | 30 | Pink | Blower motor |
| 2 | Fusible link No. 34 | Fuse | 15 | Blue | ETACS-ECU, high-mounted stoplight, rear combination light, shift lever and shift switch assembly |
| 3 | Fusible link No. 37 | 10 | Red | ||
| 4 | ETACS-ECU (ACC relay 3) | 30 | Green | ETACS-ECU (rear washer relay, windshield washer relay, windshield wiper automatic stop relay, windshield wiper speed switching relay), windshield washer motor and windshield wiper motor | |
| 5 | Fusible link No. 34 | 10 | Red | Data link connector | |
| 6 | Fusible link No. 37 | 20 | Yellow | ETACS-ECU (door lock relay, driver's door unlock relay, liftgate unlock relay, passenger's door unlock relay, trunk lid unlock relay), front door lock actuator, liftgate lock actuator and rear door lock actuator | |
| 7 | Fusible link No. 30 | 15 | Blue | CAN box unit, center panel unit, hands free module, multivision display, radio/CD player, satellite radio tuner, spare connector (for hands-free interface unit) and spare connector (for satellite radio) | |
| 8 | 7.5 | Brown | A/C-ECU, AWC-ECU, column switch, combination meter, ETACS-ECU, ETACS-ECU (power window relay), key reminder switch, KOS-ECU, lighting control sensor and wireless control module | ||
| 9 | 15 | Blue | Center panel unit, combination meter and key reminder switch | ||
| 10 | Fusible link No. 34 | 15 | Blue | ETACS-ECU | |
| 11 | ETACS-ECU (ACC relay 3) | 15 | Blue | ETACS-ECU (rear wiper relay) and rear wiper motor | |
| 12 | ETACS-ECU (IG1 relay) | 7.5 | Brown | A/C control panel, A/C-ECU, ASC-ECU, AWC-ECU, CVT control relay, ABS-ECU, center panel unit, column switch, combination meter, electric power steering-ECU, heated seat relay, KOS-ECU, rear window defogger relay, shift lever , shift switch assembly , SRS-ECU, steering wheel sensor , sunroof motor assembly, transaxle assembly and wireless control module | |
| 13 | ETACS-ECU (ACC relay 2) | 15 | Blue | Accessory socket (front floor console) and cigarette lighter (front floor console) | |
| 14 | Fusible link No. 34 | 10 | Red | Engine control module, ETACS-ECU and ETACS-ECU (fuel pump relay , IG1 relay, No. 2 fuel pump relay , power window relay) | |
| 15 | 20 | Yellow | Sunroof motor assembly | ||
| 16 | ETACS-ECU (ACC relay 2) | 10 | Red | CAN box unit, door mirror assembly, multivision display, radio/CD player and shift lever | |
| 17 | Fusible link No. 34 | 10 | Red | ASC-ECU, AWC-ECU and occupant classification-ECU | |
| 18 | ETACS-ECU (IG1 relay) | 7.5 | Brown | Backup light , ETACS-ECU, multivision display, spare connector (for navigation unit) transaxle control module , shift lever and SRS-ECU | |
| 19 | Fusible link No. 37 | 15 | Blue | Accessory socket (rear floor console) | |
| 20 | Fusible link No. 34 | Fusible link | 30 | Pink | Front power window motor (RH), power window main switch and rear power window motor |
| 21 | Fusible link No. 37 | 30 | Pink | Fuse No. 22 in passenger compartment and rear window defogger | |
| 22 | Rear window defogger relay | Fuse | 7.5 | Brown | Door mirror assembly |
| 23 | Fusible link No. 34 | ||||
| 24 | |||||
| 25 | 30 | Green | Heated seat assembly and heated seat switch |
FUSIBLE LINK AND FUSE REFERENCE CHART (PASSENGER COMPARTMENT)
Scheme 580
Scheme 581
CENTRALIZED RELAY
| Connector No. | Name |
|---|---|
| A-11X | Fog light relay |
| A-12X | Horn relay |
| A-13X | A/C compressor clutch relay |
| A-14X | |
| A-15X | CVT control relay |
| A-16X | No connection |
| A-17X | Headlight relay (High) |
| A-18X | Throttle actuator control motor relay |
| A-19X | |
| A-20X | Daytime running light relay |
| A-21X | Injector relay |
| A-22X | Electric pump relay |
| A-23X | Condenser fan relay |
| A-24X | Starter relay |
| A-25X | Headlight relay (Low) |
| A-26X | Radiator fan relay |
| A-27X | |
| A-28X | Fan control relay |
| A-29X | |
| A-30X | MFI relay |
| A-56X | No. 1 fuel pump relay |
| A-57X | Radiator fan relay |
| A-58X | Condenser fan relay |
| A-59X | Fan control relay |
CENTRALIZED RELAY REFERENCE CHART
Scheme 582
Scheme 583
Scheme 584
Scheme 585
Scheme 586
Scheme 587
Scheme 588
Scheme 589
Scheme 590
Scheme 591
Scheme 592
Scheme 593
Scheme 594
Scheme 595
Scheme 596
Scheme 597
Scheme 598
Scheme 599
Scheme 600
Scheme 601
Scheme 602
Scheme 603
Scheme 604
Scheme 605
Scheme 606
Scheme 607
Scheme 608
Scheme 609
Scheme 610
Scheme 611
Scheme 612
Scheme 613
Scheme 614
Scheme 615
Scheme 616
Scheme 617
Scheme 618
Scheme 619
Scheme 620
Scheme 621
Scheme 622
Scheme 623
Scheme 624
Scheme 625
Scheme 626
Scheme 627
Scheme 628
Scheme 629
Scheme 630
Scheme 631
Scheme 632
Scheme 633
Scheme 634
Scheme 635
Scheme 636
Scheme 637
Scheme 638
Scheme 639
Scheme 640
Scheme 641
Scheme 642
Scheme 643
Scheme 644
Scheme 645
Scheme 646
Scheme 647
Scheme 648
Scheme 649
Scheme 650
Scheme 651
Scheme 652
Scheme 653
Scheme 654
Scheme 655
Scheme 656
Scheme 657
Scheme 658
Scheme 659
Scheme 660
Scheme 661
Scheme 662
Scheme 663
Scheme 664
Scheme 665
Scheme 666
Scheme 667
Scheme 668
Scheme 669
Scheme 670
Scheme 671
Scheme 672
Scheme 673
Scheme 674
Scheme 675
Scheme 676
Scheme 677
Scheme 678
Scheme 679
Scheme 680
Scheme 681
Scheme 682
Scheme 683
Scheme 684
Scheme 685
Scheme 686
Scheme 687
Scheme 688
Scheme 689
Scheme 690
Scheme 691
Scheme 692
Scheme 693
Scheme 694
Scheme 695
Scheme 696
Scheme 697
Scheme 698
Scheme 699
Scheme 700
Scheme 701
Scheme 702
Scheme 703
Scheme 704
Scheme 705
Scheme 706
Scheme 707
Scheme 708
Scheme 709
Scheme 710
Scheme 711
Scheme 712
Scheme 713
Scheme 714
Scheme 715
Scheme 716
Scheme 717
Scheme 718
Scheme 719
Scheme 720
Scheme 721
Scheme 722
Scheme 723
Scheme 724
Scheme 725
Scheme 726
Scheme 727
Scheme 728
Scheme 729
Scheme 730
Scheme 731
Scheme 732
Scheme 733
Scheme 734
Scheme 735
Scheme 736
Scheme 737
Scheme 738
Scheme 739
Scheme 740
Scheme 741
Scheme 742
Scheme 743
Scheme 744
Scheme 745
Scheme 746
Scheme 747
Scheme 748
Scheme 749
Scheme 750
Scheme 751
Scheme 752
Scheme 753
Scheme 754
Scheme 755
Scheme 756
Scheme 757
Scheme 758
Scheme 759
Scheme 760
Scheme 761
Scheme 762
Scheme 763
Scheme 764
Scheme 765
Scheme 766
Scheme 767
Scheme 768
Scheme 769
Scheme 770
Scheme 771
Scheme 772
Scheme 773
Scheme 774
Scheme 775
Scheme 776
Scheme 777
Scheme 778
Scheme 779
Scheme 780
Scheme 781
Scheme 782
Scheme 783
Scheme 784
Scheme 785
Scheme 786
Scheme 787
Scheme 788
Scheme 789
Scheme 790
Scheme 791
Scheme 792
Scheme 793
Scheme 794
Scheme 795
Scheme 796
Scheme 797
Scheme 798
Scheme 799
Scheme 800
Scheme 801
Scheme 802
Scheme 803
Scheme 804
Scheme 805
Scheme 806
Scheme 807
Scheme 808
Scheme 809
Scheme 810
Scheme 811
Scheme 812
Scheme 813
Scheme 814
Scheme 815
Scheme 816
Scheme 817
Scheme 818
Scheme 819
Scheme 820
Scheme 821
Scheme 822
Scheme 823
Scheme 824
Scheme 825
Scheme 826
Scheme 827
Scheme 828
Scheme 829
Scheme 830
Scheme 831
Scheme 832
Scheme 833
Scheme 834
Scheme 835
Scheme 836
Scheme 837
Scheme 838
Scheme 839
Scheme 840
Scheme 841
Scheme 842
Scheme 843
Scheme 844
Scheme 845
Scheme 846
Scheme 847
Scheme 848
Scheme 849
Scheme 850
Scheme 851
Scheme 852
Scheme 853
Scheme 854
Scheme 855
Scheme 856
Scheme 857
Scheme 858
Scheme 859
Scheme 860
Scheme 861
Scheme 862
Scheme 863
Scheme 864
Scheme 865
Scheme 866
Scheme 867
Scheme 868
Scheme 869
Scheme 870
Scheme 871
Scheme 872
Scheme 873
Scheme 874
Scheme 875
Scheme 876
Scheme 877
Scheme 878
Scheme 879
Scheme 880
Scheme 881
Scheme 882
Scheme 883
Scheme 884
Scheme 885
Scheme 886
Scheme 887
Scheme 888
Scheme 889
Scheme 890
Scheme 891
Scheme 892
Scheme 893
Scheme 894
Scheme 895
Scheme 896
Scheme 897
Scheme 898
Scheme 899
Scheme 900
Scheme 901
Scheme 902
Scheme 903
Scheme 904
Scheme 905
Scheme 906
Scheme 907
Scheme 908
Scheme 909
Scheme 910
Scheme 911
Scheme 912
Scheme 913
Scheme 914
Scheme 915
Scheme 916
Scheme 917
Scheme 918
Scheme 919
Scheme 920
Scheme 921
Scheme 922
Scheme 923
Scheme 924
Scheme 925
Scheme 926
Scheme 927
Scheme 928
Scheme 929
Scheme 930
Scheme 931
Scheme 932
Scheme 933
Scheme 934
Scheme 935
Scheme 936
Scheme 937
Scheme 938
Scheme 939
Scheme 940
Scheme 941
Scheme 942
Scheme 943
Scheme 944
Scheme 945
Scheme 946
Scheme 947
Scheme 948
Scheme 949
Scheme 950
Scheme 951
Scheme 952
Scheme 953
Scheme 954
Scheme 955
Scheme 956
Scheme 957
Scheme 958
Scheme 959
Scheme 960
Scheme 961
Scheme 962
Scheme 963
Scheme 964
Scheme 965
Scheme 966
Scheme 967
Scheme 968
Scheme 969
Scheme 970
Scheme 971
Scheme 972
Scheme 973
Scheme 974
Scheme 975
Scheme 976
Scheme 977
Scheme 978
Scheme 979
Scheme 980
Scheme 981
Scheme 982
Scheme 983
Scheme 984
Scheme 985
Scheme 986
Scheme 987
Scheme 988
Scheme 989
Scheme 990
Scheme 991
Scheme 992
Scheme 993
Scheme 994
Scheme 995
Scheme 996
Scheme 997
Scheme 998
Scheme 999
Scheme 1000
Scheme 1001
Scheme 1002
Scheme 1003
Scheme 1004
Scheme 1005
Scheme 1006
Scheme 1007
Scheme 1008
Scheme 1009
Scheme 1010
Scheme 1011
Scheme 1012
Scheme 1013
Scheme 1014
Scheme 1015
Scheme 1016
Scheme 1017
Scheme 1018
Scheme 1019
Scheme 1020
Scheme 1021
Scheme 1022
Scheme 1023
Scheme 1024
Scheme 1025
Scheme 1026
Scheme 1027
Scheme 1028
Scheme 1029
Scheme 1030
Scheme 1031
Scheme 1032
Scheme 1033
Scheme 1034
Scheme 1035
Scheme 1036
Scheme 1037
Scheme 1038
Scheme 1039
Scheme 1040
Scheme 1041
Scheme 1042
Scheme 1043
Scheme 1044
Scheme 1045
Scheme 1046
Scheme 1047
Scheme 1048
Scheme 1049
Scheme 1050
Scheme 1051
Scheme 1052
Scheme 1053
Scheme 1054
Scheme 1055
Scheme 1056
Scheme 1057
Scheme 1058
Scheme 1059
Scheme 1060
Scheme 1061
Scheme 1062
Scheme 1063
Scheme 1064
Scheme 1065
Scheme 1066
Scheme 1067
Scheme 1068
Scheme 1069
Scheme 1070
Scheme 1071
Scheme 1072
Scheme 1073
Scheme 1074
Scheme 1075
Scheme 1076
Scheme 1077
Scheme 1078
Scheme 1079
Scheme 1080
Scheme 1081
Scheme 1082
Scheme 1083
Scheme 1084
Scheme 1085
Scheme 1086
Scheme 1087
Scheme 1088
Scheme 1089
Scheme 1090
See also:
• CONTROLLER AREA NETWORK (CAN)
