GENERAL DESCRIPTION
Inertia principal axes system is incorporated into the engine mount system.
- The liquid-filled mount system have been adopted for engine mounting and transaxle mounting to improve ride feeling by optimizing the insulator.
- Installation of roll stopper in the upper area has reduced engine rolling. Furthermore, enlargement of insulator diameter has reduced idle vibration.
Scheme 1099
Scheme 1100
Scheme 1101
REMOVAL AND INSTALLATION
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 1102
>> A << ENGINE FRONT MOUNTING CUSHION STOPPER INSTALLATION
Arrow marks on the engine front mounting cushion stopper should face the shown direction.
Note. Disregard F and R stamped as a shared part.
Scheme 1103
INSPECTION
- Check the engine front mounting insulator for cracks, separation or deformation.
- Check the engine front mounting cushion stopper for deformation.
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 1104
>> A << TRANSAXLE MOUNTING STOPPER INSTALLATION
Install the transaxle mounting stopper so that its arrow points upward.
Scheme 1105
- Check the transaxle mounting insulator for cracks, separation or deformation.
- Check the transaxle mounting stopper for deformation.
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 1106
>> A << ENGINE FRONT ROLL STOPPER BRACKET INSTALLATION
Install the front roll stopper so that its hole points towards the front side of the vehicle.
Scheme 1107
Check the engine roll stopper insulators for cracks, separation or deformation.
| CAUTION | Before removing the steering wheel and air bag module assembly, always refer to DRIVER-SIDE AIR BAG MODULE & CLOCKSPRING . Also, set the front wheels so that they are facing straight forward, and remove the ignition key. If you fail to do this, the SRS clock spring will be damaged, causing the SRS air bag to be inoperative and serious injury. * 1 : Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. * 2 : Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in the unladen condition. If the vehicle is equipped with the Brembo™ disc brake, during maintenance, take care not to contact the parts or tools to the caliper because the paint of caliper will be scratched. |
Scheme 1108
Scheme 1109
Required Special Tool
- MB991897: Ball Joint Remover
<< A >> LOWER ARM ASSEMBLY REMOVAL
Lift the transaxle with a transmission jack, and then withdraw the front mounting bolt on the left lower arm assembly.
Scheme 1110
<< B >> TIE ROD END AND KNUCKLE DISCONNECTION
| CAUTION | Do not remove the nut from ball joint. Loosen it and use special tool MB991897 to avoid possible damage to ball joint threads. Hang special tool MB991897 with cord to prevent it from falling. |
Scheme 1111
Scheme 1112
- Install the special tool MB991897 (Scheme 1111)
- Turn the bolt and knob as necessary to make the jaws of special tool MB991897 parallel, tighten the bolt by hand and confirm that the jaws are still parallel. NOTE: When adjusting the jaws in parallel, make sure the knob is in the position shown in the figure.
- Tighten the bolt with a wrench to disconnect the tie rod end.
<< C >> FRONT AXLE NO. 1 CROSSMEMBER ASSEMBLY REMOVAL
Retain the crossmember with a transmission jack, and then remove the crossmember mounting bolt.
Scheme 1113
>> A << STABILIZER BAR INSTALLATION
Align the identification color on the left side of the stabilizer bar with the right end of the bushing.
Scheme 1114
- Check the front axle No. 1 crossmember for cracks or damage.
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Crossmember | |
| Engine rear roll stopper rod bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) |
| Engine rear roll stopper rod nut | 52 ± 7 N.m (39 ± 5 ft-lb) |
| Front axle No. 1 crossmember bolt | 49 ± 10 N.m (37 ± 7 ft-lb) |
| Front axle No. 1 crossmember nut | 167 ± 9 N.m (123 ± 7 ft-lb) |
| Lower arm and front axle No. 1 crossmember connecting bolt front | 186 ± 10 N.m (138 ± 7 ft-lb) |
| Lower arm and front axle No. 1 crossmember connecting bolt rear | 167 ± 9 N.m (123 ± 7 ft-lb) |
| Lower arm and knuckle connecting nut | 108 ± 10 N.m (80 ± 7 ft-lb) |
| Pressure hose eye bolt | 57 ± 7 N.m (42 ± 5 ft-lb) |
| Pressure hose bolt | 12 ± 2 N.m (102 ± 22 in-lb) |
| Return hose and return pipe bolt | 12 ± 2 N.m (102 ± 22 in-lb) |
| Return hose and return pipe nut | 15 ± 3 N.m (11 ± 2 ft-lb) |
| Stabilizer bar bracket bolt | 21 ± 4 N.m (16 ± 2 ft-lb) |
| Stabilizer link nut | 39 ± 5 N.m (29 ± 3 ft-lb) |
| Steering gear and linkage bolt | 70 ± 10 N.m (52 ± 7 ft-lb) |
| Steering shaft assembly and gear box connecting bolt | 18 ± 2 N.m (13 ± 2 ft-lb) |
| Tie rod end and knuckle connecting nut | 25 ± 4 N.m (19 ± 3 ft-lb) |
| Engine mounting | |
| Engine front mounting bracket nut | 67 ± 7 N.m (50 ± 5 ft-lb) |
| Engine mounting nut | 98 ± 10 N.m (73± 7 ft-lb) |
| Power steering oil pressure hose bolt | 12 ± 2 N.m (102 ± 22 in-lb) |
| Engine roll stopper, centermember | |
| Engine front roll stopper bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) |
| Engine front roll stopper bracket nut | 52 ± 7 N.m (39 ± 5 ft-lb) |
| Engine rear roll stopper rod bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) |
| Engine rear roll stopper rod nut | 52 ± 7 N.m (39 ± 5 ft-lb) |
| Front axle crossmember bar bolt | 49 ± 10 N.m (37 ± 7 ft-lb) |
| Front suspension centermember bolt | 69 ± 10 N.m (51 ± 7 ft-lb) |
| Transaxle case front roll stopper bracket bolt | 70 ± 10 N.m (52 ± 7 ft-lb) |
| Transaxle case rear roll stopper bracket bolt | 70 ± 10 N.m (52 ± 7 ft-lb) |
| Transaxle mounting | |
| Transaxle mounting body side bracket nut | 47 ± 7 N.m (35 ± 5 ft-lb) |
| Transaxle mounting nut | 82 ± 7 N.m (61 ± 5 ft-lb) |
Identifying Fastener Tightening Specifications
