GENERAL DESCRIPTION
Inertia principal axes system is incorporated into the engine mount system.
- Longitudinal Installation type of cylindrical liquid-filled engine front mounting bracket is used for reduction of the idle vibration improvement of ride feeling.
- For transaxle mounting body side bracket, liquid-filled mount is used to improve ride feeling by optimizing insulator.
- Upper installation of roll stopper bracket reduces engine rolling, and increase of insulator bore also reduce idle vibration.
Scheme 315
Scheme 316
Scheme 317
REMOVAL AND INSTALLATION
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 318
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 319
>> A << TRANSAXLE MOUNTING STOPPER INSTALLATION
Install the transaxle mounting stopper so that its arrow points
Scheme 320
INSPECTION
- Check the transaxle mounting insulator for cracks, separation or deformation.
| CAUTION | *:Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 321
>> A << ENGINE FRONT ROLL STOPPER BRACKET INSTALLATION
Install the engine front roll stopper bracket so that its hole points towards the front side of the vehicle.
Scheme 322
>> B << ENGINE FRONT MOUNTING CUSHION STOPPER INSTALLATION
Install the engine front mounting cushion stopper as shown.
Scheme 323
Scheme 324
<< A >> LOWER ARM ASSEMBLY REMOVAL
Lift the transaxle with a transmission jack, and then withdraw the front mounting bolts on the left lower arm assembly.
Scheme 325
<< B >> SELF LOCKING NUTS (TIE ROAD END AND KNUCKLE CONNECTION) REMOVAL
| CAUTION | Do not remove the nut from ball joint. Loosen it and use special tool MB991897 to avoid possible damage to ball joint threads. Hang special tool MB991897 with a cord to prevent it from falling. |
Scheme 326
Scheme 327
- Install special tool MB991897 as shown in the figure.
- Turn the bolt and knob as necessary to make the jaws of special tool MB991897 parallel, tighten the bolt by hand and confirm that the jaws are still parallel. NOTE: When adjusting the jaws in parallel, make sure the knob is in the position shown in the figure.
- Tighten the bolt with a wrench to disconnect the tie rod end.
<< C >> STABILIZER BAR, POWER STEERING GEAR AND LINKAGE AND FRONT AXLE NO.1 CROSSEMBER ASSEMBLY REMOVAL
Support the front axle number 1 crossmember with a transmission jack, and then remove the crossmember mounting nuts and bolts.
Scheme 328
>> A << STABILIZER BAR INSTALLATION
Align the identification color on the left side of the stabilizer bar with the right end of the bushing.
Scheme 329
>> B << SELF-LOCKING NUTS INSTALLATION
Tighten the self-locking bolt until its protruding length meets the standard value.
Standard value (A): 22 +/- 1.5 mm (0.87 +/- .05 inch)
Scheme 330
- Check the front axle number 1 crossmember for cracks or damage
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION | |
|---|---|---|
| Cross member | ||
| Engine rear roll stopper bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) | |
| Engine rear roll stopper bracket nut | 52 ± 7 N.m (39 ± 5 ft-lb) | |
| Front axle No.1 crossmember bolt | 49 ± 10 N.m (37 ± 7 ft-lb) | |
| Front axle No.1 crossmember nut | 167 ± 9 N.m (123 ± 7 ft-lb) | |
| Lower arm assembly bolt | M14 x 97 | 186 ± 10 N.m (138 ± 7 ft-lb) |
| M14 x 120 | 167 ± 9 N.m (123 ± 7 ft-lb) | |
| Lower arm assembly nut | 108 ± 10 N.m (80 ± 7 ft-lb) | |
| Power steering gear and linkage bolt | 70 ± 10 N.m (52 ± 7 ft-lb) | |
| Power steering gear and linkage clamp bolt | 70 ± 10 N.m (52 ± 7 ft-lb) | |
| Pressure hose bolt (bolt, eye) | 57 ± 7 N.m (42 ± 5 ft-lb) | |
| Pressure hose bolt (bolt, washer assembled) | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Return pipe clamp bolt | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Return pipe nut | 15 ± 3 N.m (11 ± 2 ft-lb) | |
| Stabilizer bracket bolt | 21 ± 4 N.m (16 ± 2 ft-lb) | |
| Steering shaft assembly bolt | 18 ± 2 N.m (13 ± 2 ft-lb) | |
| Tie rod end nut | 25 ± 5 N.m (19 ± 3 ft-lb) | |
| Engine mounting | ||
| Engine front mounting bracket bolt | 44 ± 10 N.m (33 ± 7 ft-lb) | |
| Engine front mounting bracket nut | 67 ± 7 N.m (50 ± 5 ft-lb) | |
| Grounding cable bolt | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Engine roll stopper and centermember | ||
| Centermember bolt | 69 ± 10 N.m (51 ± 7 ft-lb) | |
| Engine front roll stopper bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) | |
| Engine front roll stopper bracket nut | 52 ± 7 N.m (39 ± 5 ft-lb) | |
| Engine rear roll stopper bracket bolt | 45 ± 5 N.m (34 ± 3 ft-lb) | |
| Engine rear roll stopper bracket nut | 52 ± 7 N.m (39 ± 5 ft-lb) | |
| Transaxle case rear roll stopper bracket bolt | 70 ± 10 N.m (52 ± 7 ft-lb) | |
| Transaxle mounting | ||
| Transaxle mounting body side bracket nut | 47 ± 7 N.m (35 ± 5 ft-lb) | |
| Transaxle mounting stopper nut | 82 ± 7 N.m (61 ± 5 ft-lb) | |
Fastener Tightening Specifications
Scheme 331
