<< A >> WINDSHIELD WIPER LINK/WINDSHIELD WIPER MOTOR REMOVAL
Disengage the harness grommet as shown in the illustration before removing the wiper link and motor.
Scheme 44
>> A << WINDSHIELD WIPER BLADE INSTALLATION
| CAUTION | Ensure that the backings are bent in the direction indicated, and then install the backings to the wiper blade rubber. |
Scheme 45
Scheme 46
Install the wiper arm and blade at the position specified above.
>> A << GROMMET INSTALLATION
Install the grommet so that the arrow points backward.
Scheme 47
>> B << REAR WIPER BLADE INSTALLATION
| CAUTION | Ensure that the backings are bent in the direction indicated, and then install the backings to the wiper blade rubber. |
Scheme 48
>> C << REAR WIPER ARM INSTALLATION
Install the wiper arm and blade assembly so that it is positioned on the ceramic end line.
Scheme 49
<< A >> MIRROR REMOVAL
| CAUTION | The claws of the mirror are prone to breakage when working in cold temperatures. Always warm up the mirror claws and their periphery to 20°C (60°F) or higher before handling. |
Slant the mirror upward with your hands. Then insert a flat-tipped screwdriver wrapped with protective tape between the pivot plate and mirror through the notch from behind the mirror. Now pry off the mirror claws and remove mirror. see scheme 65
Scheme 50
<< B >> DOOR MIRROR ASSEMBLY REMOVAL
| CAUTION | When loosening or tightening the door mirror assembly mounting bolts, use a magnetic wrench to prevent bolts from dropping into the door panel cavity. |
