WINDSHIELD INTERMITTENT WIPER INTERVAL CHECK
Required Special Tools
- MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: MUT-III USB Cable MB991910: MUT-III Main Harness A
If the windshield intermittent wiper interval control is operated, and/or vehicle speed changes, the wiper interval should change.
| CAUTION | To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. |
Scheme 67
- Connect scan tool MB991958 to the data link connector.
- Turn the ignition switch to the "ON" position.
- Operate scan tool MB991958 according to the procedure below to display "Simulated Vehicle Speed Output." Select "SYSTEM SELECT." Select "SWS." Select "Simulated Vehicle Speed Output."
- Holding the windshield intermittent wiper interval control, input the simulated vehicle speed with scan tool MB991958 and check that the wiper interval changes as the vehicle speed changes.
- If not, carry out the troubleshooting. Refer to «SYMPTOM CHART»(ref-308263-S16536086792009020200000) .
WINDSHIELD WIPER MOTOR CHECK
Remove the windshield wiper motor and inspect it at the harness connector.
WINDSHIELD WIPER SWITCH CHECK
Check continuity between the switch terminals.
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION |
|---|---|---|
| OFF | 23-32, 23-31, 23-30, 23-21 | Open circuit |
| Windshield mist wiper switch | 23-32 | Less than 2 ohms |
| Windshield intermittent wiper switch | 23-31 | |
| Windshield low-speed wiper switch | 23-30 | |
| Windshield high-speed wiper switch | 21-23 |
WINDSHIELD WIPER SWITCH POSITION
Scheme 68
Check that the resistance varies between 0 and 1 kohms when the windshield intermittent interval is turned from FAST to SLOW by after measuring resistance between connector terminals 27 and 28 at the column switch.
Scheme 69
Scheme 70
Note. For removal and installation of the wiper and washer switch, refer to SYMPTOM CHART .
Scheme 71
- Remove the washer tank assembly with the washer hose attached. Then fill the washer tank with water.
- Check to see that the water is vigorously sprayed when connecting the positive battery terminal to terminal number 2 and terminal number 1 to ground.
WINDSHIELD WASHER SWITCH CHECK
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION |
|---|---|---|
| OFF | 22-23 | Open circuit |
| Windshield washer switch ON | 22-23 | Less than 2 ohms |
WINDSHIELD WASHER SWITCH SPECIFIED CONDITION
Scheme 72
REAR WIPER MOTOR CHECK
Inspect the rear wiper motor by removing the harness connector with the motor attached to the vehicle.
REAR WIPER AND WASHER SWITCH CHECK
Check continuity between the switch terminals.
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION |
|---|---|---|
| OFF | 25-26, 25-29 | Open circuit |
| Rear wiper switch | 25-26 | Less than 2 ohms |
| Rear washer switch | 25-29 | Less than 2 ohms |
REAR WIPER AND WASHER SWITCH POSITION
Scheme 73
Scheme 74
Scheme 75
- Installation position. Attach each mark to the position shown in the illustration.
- Installation procedure Use 3M(tm) AAD Part number 8906 or equivalent to clean the mark installation surfaces on the body. CAUTION: When attaching the marks, the ambient temperature should be 20-38°C (60-100°F) and the air should be completely free of dust. If the ambient temperature is lower than 20°C (60°F), the marks and the places on the vehicle body where the marks are to be attached should be heated to 20-38°C (60-100°F). Peel off the protection sheet on the back of the marks to affix it in position.
DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION | |
|---|---|---|---|
| OFF | 9-2, 9-3, 9-6, 9-10, 9-11, 1-2,1-3, 1-6, 1-10, 1-11 | Open circuit | |
| Left side | OFF | 9-6, 9-10, 9-11, 1-6, 1-10, 1-11 | Open circuit |
| Up | 1-6, 9-11 | Less than 2 ohms | |
| Down | 1-11, 6-9 | ||
| Right | 1-6, 9-10 | ||
| Left | 1-10, 6-9 | ||
| Right side | OFF | 9-2, 9-3, 9-6, 1-2, 1-3, 1-6 | Open circuit |
| Up | 1-6, 3-9 | Less than 2 ohms | |
| Down | 1-3, 6-9 | ||
| Right | 1-6, 2-9 | ||
| Left | 1-2, 6-9 | ||
DOOR MIRROR CONTROL SWITCH POSITION
Scheme 76
HEATED DOOR MIRROR CHECK
| CAUTION | When relocating the car between locations with extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. |
Check to see that the resistance shown in the graph is almost satisfied when measuring the resistance of terminal 1 and 3 of the door mirror connectors.
If the resistance is not within the specified range, replace the door mirror.
Scheme 77
ADHESIVE
| ITEM | SPECIFICATION |
|---|---|
| Front three-diamond mark | Adhesive tape: Double-sided tape 0.8 mm (0.03 inch) thickness |
| Roof drip molding | Adhesive tape: Double-sided tape 10.0 mm (0.39 inch) width and 1.52 mm (0.06 inch) thickness |
ADHESIVE SPECIFICATION
