WINDSHIELD WIPER AND WASHER DIAGNOSIS

The windshield wiper and washer are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SYMPTOM CHART .

Note. Even when the ETACS-ECU has failed, the windshield wipers can work at low speed as fail-safe mode. (Normally, the windshield wiper operates when the ignition switch is at the "ACC" position. But, if it enters the fail-safe mode, the wipers can operate only when the ignition switch is at the "ON" position).

REAR WIPER AND WASHER DIAGNOSIS

The rear wiper and washer are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SYMPTOM CHART .

TROUBLESHOOTING STRATEGY

Diagnosis should be carried out by the following procedures.

1. Gather the information from the customer.
2. Verify that the condition described by the customer exists.
3. Find the malfunction by the following Symptom Chart.
4. Verify the malfunction is eliminated.

SYMPTOM CHART

HEATED DOOR MIRROR DIAGNOSIS SYMPTOM CHART

TROUBLESHOOTING HINTS

1. Malfunction of the rear window defogger system
2. The wiring harness or connectors may have loose, corroded or damaged terminals, or terminals pushed back in the connector.

DIAGNOSIS

Required Special Tools

1. MB991223: Test Harness Set

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. STEP 1. Check the rear window defogger. Check that the rear window defogger works normally as follows. Turn the ignition switch to the "ON" position. Push the rear window defogger switch to operate the defogger. Q: Does the defogger work normally? YES : Go to Step 2. NO : Because of malfunction of the rear window defogger, carry out the troubleshooting. Refer to Manual A/C Diagnosis - «SYMPTOM CHART»(ref-308259-S19204901422009020200000) .
2. STEP 2. Check the remote controlled mirror (RH) connector E-01 and junction block connector C-215 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are the remote controlled mirror (RH) connector E-01 and junction block connector C-215 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Check if the door mirrors works normally.
3. STEP 3. Check the wiring harness between the remote controlled mirror (RH) connector E-01 (terminal 1) and junction block connector C-215 (terminal 3). NOTE: Also check intermediate connector C-09 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-09 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (RH) connector E-01 (terminal 1) and junction block connector C-215 (terminal 3) in good condition? YES : Go to step 4. NO : Repair the wiring harness as necessary. Check if all heated door mirrors work normally.
4. STEP 4. Check remote controlled mirror (LH) connector E-12. Q: Is remote controlled mirror (LH) connector E-12 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Check if all heated door mirrors work normally.
5. STEP 5. Check the wiring harness between remote controlled mirror (LH) connector E-12 (terminal 1) and junction block connector C-215 (terminal 3). NOTE: Also check intermediate connector C-25 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-25 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (RH) connector E-12 (terminal 1) and junction block connector C-215 (terminal 3) in good condition? YES : The procedure is complete. NO : Repair the wiring harness as necessary. Check if the all heated door mirrors work normally.

Scheme 21

Scheme 22

1. Malfunction of the heated door mirror circuit
2. Malfunction of the door mirror
3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. STEP 1. Verify the operation of each heated door mirror. Q: Which door mirror does not heat? Door mirror (LH) : Go to Step 2. Door mirror (RH) : Go to Step 8 .
2. STEP 2. Check remote controlled mirror (LH) connector E-12 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is remote controlled mirror (LH) connector E-12 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . And then check to see that the heater function of the door mirror (LH) operates normally.
3. STEP 3. Check the heater of the door mirror (LH). CAUTION: When relocating the car between locations of extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. Check to see that the resistance shown in the graph is almost satisfied when measuring the resistance between terminal 1 and 3 of the remote controlled mirror (LH) connector E-12. Q: Is the resistance normal? YES : Go to Step 4. NO : Replace the door mirror (LH). And then check to see that the heater function of the door mirror (LH) is operating normally.
4. STEP 4. Check the ground circuit between remote controlled mirror (LH) connector E-12 and ground for open circuit. Measure the resistance at remote controlled mirror (LH) connector E-12. Disconnect remote controlled mirror (LH) connector E-12 and check at the wiring harness side connector. Measure the resistance value between terminal 3 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 6 . NO : Go to Step 5.
5. STEP 5. Check the wiring harness between remote controlled mirror (LH) connector E-12 (terminal 3) and ground. NOTE: Also check intermediate connector C-25 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-25 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (LH) connector E-12 (terminal 3) and ground in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged. Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (LH) operates normally.
6. STEP 6. Check junction block C-215 for loose, corroded damaged terminal, or terminals pushed back in the connector. Q: Is junction block C-215 in good condition? YES : Go to Step 7. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . And then check to see that the heater function of the door mirror (LH) operates normally.
7. STEP 7. Check the wiring harness between remote controlled mirror (LH) connector E-12 (terminal 1) and junction block connector C-215 (terminal 3). NOTE: Also check intermediate connector C-25 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-25 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (LH) connector E-12 (terminal 1) and junction block connector C-215 (terminal 3) in good condition? YES : No action is necessary and testing is complete. NO : Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (LH) operates normally.
8. STEP 8. Check the remote controlled mirror (RH) connector E-01 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is the remote controlled mirror (RH) connector E-01 in good condition? YES : Go to Step 9. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . And then check to see that the heater function of the door mirror (RH) operates normally.
9. STEP 9. Check the heater function of the door mirror (RH). CAUTION: When relocating the car between locations of extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. Check to see that the resistance shown in the graph is almost satisfied when measuring the resistance between terminal 1 and 3 of the door mirror (RH) connector E-01. Q: Is the resistance normal? YES : Go to Step 10. NO : Replace the door mirror (RH). And then check to see that the heater function of the door mirror (RH) operates normally.
10. STEP 10. Check the ground circuit between remote controlled mirror (RH) connector E-01 and ground for open circuit. Measure the resistance at remote controlled mirror (RH) connector E-01. Disconnect remote controlled mirror (RH) connector E-01, and check at the wiring harness side connector. Measure the resistance value between terminal 3 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 12 . NO : Go to Step 11.
11. STEP 11. Check the wiring harness between remote controlled mirror (RH) connector E-01 (terminal 3) and ground. NOTE: Also check intermediate connector C-09 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-09 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (RH) connector E-01 (terminal 3) and ground in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged. Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (RH) operates normally.
12. STEP 12. Check junction block C-215 for loose, corroded damaged terminal, or terminals pushed back in the connector. Q: Is junction block C-215 in good condition? YES : Go to Step 13. NO : Repair or replace the damaged component(s). Refer «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . And then check to see that the heater function of the door mirror (RH) operates normally.
13. STEP 13. Check the wiring harness between remote controlled mirror (RH) connector E-01 (terminal 1) and junction block connector C-215 (terminal 3). NOTE: Also check intermediate connector C-09 for loose, corroded or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-09 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-308258-S34323851462009020200000) . Q: Is the wiring harness between remote controlled mirror (RH) connector E-01 (terminal 1) and junction block connector C-215 (terminal 3) in good condition? YES : No action is necessary and testing is complete. NO : Repair the wiring harness as necessary. And then check to see that the heater function of the door mirror (RH) operates normally.

Scheme 43
