REMOVAL AND INSTALLATION

WARNINGBefore removing the steering wheel, air bag module assembly and clock spring refer to SERVICE PRECAUTIONS and AIR BAG MODULE AND CLOCK SPRING . When removing and installing the steering wheel, do not let it bump against the air bag module.
CAUTIONWhen the steering lock cylinder is replaced, register the encrypted code. Refer to ENCRYPTED CODE REGISTRATION CRITERIA TABLE .

Scheme 213

Scheme 213

Scheme 214

Scheme 214: << A >> STEERING LOCK CYLINDER REMOVAL
  1. Insert the key in the steering lock cylinder and turn it to the "ACC" position.
  2. Using a small Phillips head screwdriver, depress lock pin and pull the steering lock cylinder toward you.
CAUTIONWhen the ETACS-ECU is replaced, register the encrypted code. Refer to HOW TO REGISTER SECRET CODE .

Scheme 215

Scheme 215

<< A >> HEADLIGHT ASSEMBLY REMOVAL

Remove the headlight assembly with the applicable side of the front bumper slid downward slightly.

<< A >> REAR COMBINATION LIGHT REMOVAL

Before removing the rear combination light, disengage the claw shown in the illustration using special tool MB990784.

Scheme 216

Scheme 216: << A >> REAR COMBINATION LIGHT REMOVAL

<< B >> SOCKET ASSEMBLY REMOVAL

Remove the socket assembly connector using a flat-tipped screwdriver as shown in illustration.

Scheme 217

Scheme 217: << B >> SOCKET ASSEMBLY REMOVAL

<< A >> COLUMN SWITCH CONNECTOR REMOVAL

Disconnect column switch connector C-309 shown in the illustration.

Scheme 218

Scheme 218: << A >> COLUMN SWITCH CONNECTOR REMOVAL

<< A >> ACCESSORY SOCKET (BATTERY) CASE B/ ACCESSORY SOCKET (BATTERY) COVER/ FLOOR CONSOLE PLATE BOX REMOVAL

Disengage the claw shown in the illustration and remove the accessory socket (BATTERY) case B and accessory socket (BATTERY) cover.

Scheme 219

Scheme 219: << A >> ACCESSORY SOCKET (BATTERY) CASE B/ ACCESSORY SOCKET (BATTERY) COVER/ FLOOR CONSOLE PLATE BOX

<< A >> REMOTE CONTROLLED RADIO SWITCH REMOVAL

Use a tool to hold the tabs on the remote controlled radio switch, and push out the switch with your finger.

Scheme 220

Scheme 220: << A >> REMOTE CONTROLLED RADIO SWITCH REMOVAL

>> A << HARNESS ASSEMBLY INSTALLATION

Attach the harness assembly to the position shown in the illustration.

Scheme 221

Scheme 221: >> A << HARNESS ASSEMBLY INSTALLATION

>> A << AUDIO AMPLIFIER INSTALLATION

Install while aligning with the amplifier mounting hole.

Scheme 222

Scheme 222: >> A << AUDIO AMPLIFIER INSTALLATION

Scheme 223

Scheme 223: REMOVAL AND INSTALLATION

Refer to HEATER CONTROL ASSEMBLY (INCORPORATED IN A/C-ECU) .

Panic alarm system component parts

  1. Headlight assembly (refer to «ENCRYPTED CODE REGISTRATION CRITERIA TABLE»(ref-241292-S39211918422006081100000) ).
  2. Horn (refer to «HORN»(ref-241292-S13854778442006081100000) ).
