Chassis Electrical: Other Mitsubishi Eclipse IV

BATTERY CHECK

Scheme 250

Scheme 251

1. Ensure that the battery electrolyte level A within the range B shown in the figure. Add if the level is lower than the specified range.
2. Use a hydrometer and temperature gauge to check the specific gravity of the electrolyte. Standard value: 1.220 - 1.290 [at 20°C (68°F)] The specific gravity of electrolyte depends on its temperature. Use the formula below to determine the proper value. Conversion on centigrade D 20 =(t - 20) x 0.0007 + Dt Conversion on Fahrenheit D 20 =(t - 68) x 0.0007 + Dt D 20 : Specific gravity as if electrolyte temperature is 20°C (68°F) D t : Measured specific gravity t : Measured temperature

BATTERY CHARGING

Battery electrolyte temperature may temporarily be allowed to rise to 55°C (131°F). Increase of electrolyte temperature above 55°C (131°F) is harmful to the battery, causing deformation of battery cell, decrease in life of battery, etc.

CHARGE RATE

Recommended rate and time for fully discharged condition (flat discharged) is shown below. When the specific gravity of electrolyte keeps 1.22 - 1.29 for more than one hour, charging should be stopped.

Charge Rate Chart

CHARGE RATE CHART

IGNITION KEY REMINDER TONE ALARM

The ignition key reminder tone alarm will sound under the following condition, and warn the driver to remove the ignition key.

1. The driver's door is opened when the ignition switch is at "LOCK" (OFF) or "ACC" position without removing the ignition key. However, the light reminder tone alarm will take precedence over this function.

DOOR LOCK PREVENTION FUNCTION

If the key is left in the ignition switch while the driver's door opened or the assistant door opened, all doors are automatically unlocked to prevent locking the ignition key in the vehicle after the door is locked.

IGNITION SWITCH CONTINUITY CHECK

Disconnect ignition switch connector C-308 without removing the ignition switch and steering lock cylinder. Then check the continuity.

SWITCH POSITION AND SPECIFIED CONDITION

Scheme 252

ENCRYPTED CODE REGISTRATION CRITERIA TABLE

The ignition key contains a transponder (small transmitter), which retains an unique encrypted code. When replacing the parts of the immobilizer system, always register the encrypted code or VIN, or both of them according to the list below. The ETACS-ECU can retain a maximum of eight different encrypted codes. This means that a maximum of eight ignition keys can be registered.

ENCRYPTED CODE REGISTRATION CRITERIA CHART

Note. The engine does not start until the matching has been completed.

HOW TO READ DATA LIST

Required Special Tools

1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: V.C.I. MB991827: MUT-III USB Cable MB991910: MUT-III Main Harness A

1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to "ON" position.
3. Select "Interactive Diagnosis" from the start-up screen.
4. Select "System select."
5. Choose "IMMOBILIZER" from the "POWER TRAIN" tab.
6. Select "Data List."
7. Choose an appropriate item and select the "OK" button.

DATA LIST REFERENCE TABLE

DATA LIST REFERENCE CHART

Scheme 253

Note. *: The terminal No. 1 to 20 connectors cannot be measured as the ETACS-ECU is installed directly on the junction block. Therefore, this information is only for reference.

TERMINAL NO. AND INSPECTION CONDITION

ENCRYPTED CODE REGISTRATION PROCEDURE

If the ignition key is replaced or additional keys are requested, the encrypted codes of all ignition keys must be registered. (A maximum of eight ignition keys can be registered.)

Note. The encrypted codes can be registered using the ignition key and barcode No.

Scheme 254

Scheme 255

Scheme 256

PRECAUTIONS DURING SERVICE

If all functions do not work, check the diagnostic trouble code, and repair the system. Then, repeat the operation.

If a wrong password is entered consecutively five times by scan tool (MUT-III sub assembly), the immobilizer-ECU judges that the system is operated incorrectly. Then, the engine immobilization mode is set, and the ECU stops the engine and all special functions is stopped. In addition, when the ignition switch is held at the ON position for approximately 20 minutes with engine immobilization mode, "incorrect operation, engine immobilization mode" is cancelled.

ENCRYPTED CODE REGISTRATION USING IGNITION KEY < REGISTRATION USING IGNITION KEY ONLY >

When the ignition key is lost or additional keys are requested, the ignition key must be used to register encrypted codes.

Scheme 257

1. Turn the ignition switch to the "ON" position using the registered ignition key and keep it there for 5 seconds.
2. Turn the ignition switch to the "LOCK" (OFF) position, and remove the registered ignition key.
3. Within 30 seconds after the ignition key is removed, insert the other registered ignition key that has already been registered and turn the ignition switch to the "ON" position.
4. The immobilizer indicator light starts flashing in approximately 10 seconds after the ignition switch is turned to the "ON" position.
5. When the immobilizer indicator light starts flashing, turn the ignition switch to the "LOCK" (OFF) position and remove the ignition key. NOTE: When an error occurs while the immobilizer indicator light is flashing, the immobilizer indicator light extinguishes.
6. Within 30 seconds after the immobilizer indicator light flashes in Step 5 , insert the ignition key to be added and turn the ignition switch to the "ON" position.
7. When registering another ignition key, repeat the procedure from the beginning. NOTE: < When the additional ignition key cannot be registered > When the immobilizer indicator is not illuminated during registration When the immobilizer indicator light does not change in 3 seconds after carrying out Step 6 < When the additional registration of the ignition key terminates automatically > When 30 seconds have passed before inserting the ignition key in Step 3 after the ignition key is removed in Step 2 . When 30 seconds have passed after the immobilizer indicator light flashed

ENCRYPTED CODE REGISTRATION USING BARCODE NO.

When the ignition key that starts the engine is replaced due to the replacement of the ignition key set, the ignition key cylinder, etc., the barcode No. must be used to register encrypted codes.

Scheme 258

Required Special Tools

1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: V.C.I. MB991827: MUT-III USB Cable MB991910: MUT-III Main Harness A

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to the "ON" position.
3. Choose "IMMOBILIZER" from the "POWER TRAIN" tab.
4. Enter the VIN code of the vehicle that is registered. Then, press "OK" button.
5. Select "Special Function."
6. Select "Key Registration (Barcode No.)."
7. Enter the password of the vehicle, and press the OK button.
8. Enter the ID on the barcode plate which is attached to the ignition key, and press the OK button.
9. When the execution confirmation menu of the key registration (Barcode No.) is displayed, press the OK button.
10. When the key registration completion menu is displayed, press the OK button.

Scheme 270

Scheme 271

1. Disconnect key reminder switch connector C-310 without removing the key reminder switch and steering lock cylinder.
2. Check for continuity between terminal 4 and terminal 6. TESTER CONNECTION AND SPECIFIED CONDITION STATUS OF IGNITION KEY TESTER CONNECTION SPECIFIED CONDITION Removed 4--6 Less than 2 ohms Inserted 4--6 Open circuit

POSSIBLE CAUSES

1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector.
2. Malfunction of ETACS-ECU
3. Malfunction of combination meter

1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
2. Malfunction of the combination meter

The following items of the ECU input data can be read using scan tool MUT-III.

DATA LIST REFERENCE TABLE

COMBINATION METER TERMINAL CHECK

Measure the voltage between terminals using a voltmeter.

Scheme 272

Note. The combination meter connector is fixed on the instrument panel directly, so you cannot take measurement by backprobing.

TERMINAL NO. AND NORMAL CONDITION

TACHOMETER CHECK

Required Special Tools

1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: V.C.I. MB991827: MUT-III USB Cable MB991910: MUT-III Main Harness A

1. Connect scan tool MB991958 to the data link connector.
2. A/T select lever: "P" position or M/T shift lever: "N" position.
3. Turn the ignition switch to "ON" position.
4. Start the engine.
5. Run the engine.
6. Select MFI system data list and take a reading of the engine speed. Item 22: CKP SENSOR
7. Compare the engine speed shown in the scan tool with that shown on the tachometer. The engine speeds shown on the tachometer should correspond to the table below. NOTE: The following standard value assumes that battery voltage is 13.5 volts. ALLOWANCE RANGE CHART - STANDARD VALUE ENGINE SPEED (r/min) INDICATION ALLOWANCE OF TACHOMETER (r/min) 1,000 900 - 1,100 2,000 1,900 - 2,100 3,000 2,900 - 3,100 4,000 3,900 - 4,100 5,000 4,900 - 5,100 6,000 5,900 - 6,100

Scheme 273

1. Remove the rear seat cushion assembly. (Refer to «REAR SEAT ASSEMBLY»(ref-241332-S40040027152006081100000) .)
2. Remove hole cover, grommet and remove the fuel pump module and fuel level sensor (sub).

Scheme 274

1. Check the resistances between fuel level sensor main terminals 1 and 2 as well as sub terminals 1 and 2 of the fuel pump module, respectively. ITEM AND FUEL LEVEL CHART - STANDARD VALUE ITEM FUEL LEVEL SENSOR (main) FUEL LEVEL SENSOR (sub) Resistance ohms Point "F" (highest) 6.5 6.5 +/- 1.0 Point "E" (lowest) 45.1 74.9 +/- 1.0
2. Check that resistance value changes smoothly when the float moves slowly between points.
3. If all checks are correct, go to fuel unit height check. If any check is not correct, replace the fuel pump module or fuel level sensor (sub).

Scheme 275

Scheme 276

1. Move the float and measure height A at point "F" (highest) and B at point "E" (lowest). ITEM AND FUEL LEVEL CHART - STANDARD VALUE ITEM FUEL LEVEL SENSOR (main) FUEL LEVEL SENSOR (sub) Height mm (in) A at point "F" 131.5 (5.1) 24.9 +/- 3.0 (0.9 +/- 0.1) B at point "E" 34.5 (1.3) 172.7 +/- 3.0 (6.7 +/- 0.1)
2. If any check is not correct, replace the fuel pump module or fuel level sensor (sub).

Scheme 277

Scheme 278

LUMINOUS INTENSITY MEASUREMENT

1. Set the headlights to high-beam
2. Using a photometer, and following its manufacturer's instruction manual, measure the headlight center intensity and check to be sure that the limit value is satisfied. Limit: 40,000 cd or more {When a screen is set 18.3m (60 feet) ahead of the vehicle}

Note. When measuring the intensity, maintain an engine speed of 2,000 r/min, with the battery fully charged.

There may be special local regulations pertaining to headlight intensity. Be sure to make any adjustments necessary to satisfy such regulations.

If an illuminometer is used to make the measurements, convert its values to photometer values by using the following formula.

I =E x r 2 Where

1. I = intensity (cd)
2. E = illumination (lux)
3. r = distance (m) from headlights to illuminometer

Scheme 279

1. Disconnect the headlight connector.
2. Remove the headlight bulb by turning it counterclockwise as shown in illustration. CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may fail after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
3. Install the headlight bulb to the headlight by pushing it in and twisting it clockwise.

Scheme 280

1. Disconnect the front side-marker, front turn-signal light and parking light connector.
2. Remove the socket with the bulb by turning it counterclockwise as shown in illustration. CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may fail after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
3. Pull out the bulb from the socket, and then replace the bulb.
4. Install the socket to the headlight by pushing it in and twisting it clockwise.

Scheme 281

Scheme 282

FRONT FOG LIGHT SWITCH CONTINUITY CHECK

SWITCH POSITION AND SPECIFIED CONDITION

Scheme 283

FRONT FOG LIGHT RELAY CHECK

TESTER CONNECTION AND SPECIFIED CONDITION

Scheme 284

HAZARD WARNING LIGHT SWITCH CONTINUITY CHECK

SWITCH POSITION AND SPECIFIED CONDITION

Scheme 285

Scheme 286

HORN RELAY CONTINUITY CHECK

TESTER CONNECTION AND SPECIFIED CONDITION

Scheme 287

Scheme 288

RADIO AND CD PLAYER

There are 2 types of audio system as follows.

< STANDARD AUDIO SYSTEM >

1. 1-disk CD player for MP3/CD-R/CD-RW
2. AM/FM electronic tuning radio
3. MAX output: 140W

< PREMIUM AUDIO SYSTEM >

1. Rockford Fosgate audio system.
2. CD player (with 6-disk CD changer incorporated) for MP3/CD-R/CD-RW with sound quality adjustment functions by digital signal processor (DSP)
3. AM/FM electronic tuning radio
4. Audio amplifier
5. MAX output: 650W
6. Steering wheel with remote control radio switches

SPEAKER

LOCATION AND STANDARD AUDIO SYSTEM CHART

AUDIO ERROR CODES

If the radio and CD player or radio and CD player with CD changer detects any malfunction in itself or the inserted CD, the error codes below will be shown on the multi-center display.

PROBLEM SYMPTOM CHART

REMOTE CONTROLLED RADIO SWITCH CONTINUITY CHECK

Use an ohmmeter to measure the resistance value between the terminals.

SWITCH POSITION AND MEASUREMENT VALUE

Scheme 289

Scheme 290

Scheme 291

Scheme 292

DEFOGGER RELAY CONTINUITY CHECK

BATTERY VOLTAGE AND SPECIFIED CONDITION

Scheme 293

ONE TURN MAGNETIC COMPENSATION

The compass is self-calibrating under normal driving conditions. It is not necessary to manually calibrate the compass. If manual calibration is desired, follow these instructions.

Scheme 294

Scheme 295

1. Engine started.
2. Display the compass on the multi-center display.
3. Press and hold the "H" switch and "M" switch until "-- --" appears in the display.
4. Release the switch to enter the calibration mode.
5. Drive very slowly in a circle until "-- --" disappears.

AMBIENT AIR TEMPERATURE SENSOR (EXCLUSIVE TO MULTI-CENTER DISPLAY) CHECK

Measure the resistance between the sensor terminals under at least two temperatures. The resistance values should meet the values shown in illustration.

Note. The temperature should be within the range shown in illustration.

Scheme 296

< BATTERY >

SERVICE SPECIFICATIONS

< COMBINATION METER >

COMBINATION METER SPECIFICATIONS

< HEADLIGHT >

HEADLIGHT SPECIFICATIONS

< FRONT FOG LIGHT >

FRONT FOG LIGHT SPECIFICATIONS
