HEADLIGHT ADJUSTMENT
Note. When adjusting headlight, disconnect the other headlight harness.
Scheme 3
Scheme 4
- The low beam headlight will project on the screen upper edge of the beam (cut-off).
- Turn the adjusting screws to achieve the specified low-beam cut-off location on the aiming screen.
Standard value
(Vertical direction) Horizontal line (H) +/- 50.5 mm (+/- 2.0 inches) (0.38 degrees angle)
(Horizontal direction): +/- 126.4 mm (+/- 5.0 inches) (+/- 0.95 degrees angle) from the axis, which is 266.1 mm (10.5 inches) (2 degrees angle) rightward from the vertical line (V)
| CAUTION | Do not cover a headlight for more than three minutes to prevent the plastic headlight lens deformation. |
Note. High-beam pattern should be correct when the low-beams are adjusted properly.
Scheme 5
COMPASS CALIBRATION
Under certain circumstances, as during a long distance cross country trip, it will be necessary to adjust for compass variance. Compass variance is the difference between earth's magnetic north and true geographic north. If not adjusted to account for compass variance, compass could give false readings.
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
- With the compass displayed, keep pressing "M" switch for two second or more. The current zone number will appear upon release.
- Find current location and variance zone number on the zone map.
- Press the "H" switch repeatedly until the correct zone number is displayed.
- Pressing the "M" switch will exit zone entry mode. This area code number should remain in the battery off. If the compass deviates from the correct indication soon after repeated adjustment, have the compass checked at refer to «INSPECTION PROCEDURE 5: THE COMPASS CAN NOT BE CALIBRATED MANUALLY, OR GOES OUT OF CALIBRATION EASILY. < VEHICLES WITH TYPE 1 >»(ref-241292-S36049889582006081100000) . NOTE: Do not install a ski rack, antenna, etc., which are attached to the vehicle by means of a magnet. They affect the operation of the compass. NOTE: The compass may not indicate the correct compass direction when in the places shown below: Tunnels Railroads Underpass/Overpass Transforming station Large metal structures Area over the subway NOTE: The compass returns to the correct compass direction vehicle moves to an area where the geomagnetism is stabilized.
Scheme 11
Scheme 12
- Demagnetize the body using a commercial demagnetizer.
- While keeping the distance between the tip of demagnetizer and the roof panel to approximately 5 cm (2.0 inches), move the demagnetizer slowly with a sweeping manner on the rear-half surface of roof panel. CAUTION: If the tip of demagnetizer touches the roof panel, the magnetizing condition of body becomes worse to the opposite. Absolutely avoid this.
- Slowly draw the demagnetizer apart from the body. Turn off the switch of demagnetizer when it is apart from the body more than 5 cm (2.0 inches). CAUTION: If the demagnetizer is turned off near the body or it is suddenly separated from the body, the magnetizing condition of body becomes worse to the opposite. Absolutely avoid these.
