SPECIAL TOOLS

SPECIAL TOOLS TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 MUT-III sub assembly Vehicle communication interface (V.C.I.) MUT-III USB cable MUT-III main harness A (Vehicles with CAN communication system) MUT-III main harness B (Vehicles without CAN communication system) MUT-III main harness C (for Daimler Chrysler models only) MUT-III measurement adapter MUT-III trigger harness MB991824-KIT NOTE: G: MB991826 MUT-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. Reading diagnostic trouble code CAUTION: For vehicles with CAN communication, use MUT-III main harness A to send simulated vehicle speed. If you connect MUT-III main harness B instead, the CAN communication does not function correctly. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adapter Probe General service tool (jumper) Making voltage and resistance measurements during troubleshooting Connect pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting

Scheme 224

Scheme 224: SPECIAL TOOLS

Scheme 225

Scheme 225

Scheme 226

Scheme 226

Scheme 227

Scheme 227

Scheme 228

Scheme 228

Scheme 229

Scheme 229

Scheme 230

Scheme 230

Scheme 231

Scheme 231

Scheme 232

Scheme 232

SPECIAL TOOLS TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 MUT-III Sub Assembly Vehicle communication interface (V.C.I.) MUT-III USB cable MUT-III main harness A (Vehicles with CAN communication system) MUT-III main harness B (Vehicles without CAN communication system) MUT-III main harness C (for Daimler Chrysler models only) MUT-III measurement adapter MUT-III trigger harness MB991824-KIT NOTE: G: MB991826 MUT-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. Reading diagnostic trouble code Estimated vehicle speed sent CAUTION: For vehicles with CAN communication, use MUT-III main harness A to send simulated vehicle speed. If you connect MUT-III main harness B instead, the CAN communication does not function correctly. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adapter Probe General service tool (jumper) Making voltage and resistance measurements during troubleshooting Connect pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe General service tool Making voltage and resistance measurement during troubleshooting

Scheme 233

Scheme 233: SPECIAL TOOLS

Scheme 234

Scheme 234

Scheme 235

Scheme 235

Scheme 236

Scheme 236

Scheme 237

Scheme 237

Scheme 238

Scheme 238

Scheme 239

Scheme 239

Scheme 240

Scheme 240

Scheme 241

Scheme 241: SPEEDOMETER CHECK

Scheme 242

Scheme 242
  1. Adjust the pressure of tires to the specified level (Refer to «ON-VEHICLE SERVICE»(ref-241323-S21355289532006081100000) ).
  2. Turn off the TCL switch. CAUTION: Since the diagnosis code may be stored in the ABS-ECU or the ABS/TCL-ECU when checking the speedometer with speedometer tester, erase the diagnosis code. Do not accelerate or decelerate suddenly during servicing work.
  3. Set the vehicle onto a speedometer tester and use wheel chocks to hold the rear wheels.
  4. To prevent the front wheel from moving from side to side, attach tension bars to the tie-down hook, and secure both ends to anchor plates.
  5. To prevent the vehicle from moving, attach a chain or wire to the rear retraction hook, and make sure the end of the chain or wire is secured.
  6. Check if the speedometer indicator range is within the standard values. ALLOWANCE RANGE CHART - STANDARD VALUE < EXCEPT VEHICLES FOR CANADA > STANDARD INDICATION mph (km/h) ALLOWANCE RANGE mph (km/h) 10 (16) 8.5 - 11.5 (13.6 - 18.4) 25 (40) 23.5 - 26.5 (37.6 - 42.4) 50 (80) 48.5 - 51.5 (77.6 - 82.4) 75 (120) 73.5 - 76.5 (117.6 - 122.4) 100 (161) 98.5 - 102.5 (158.5 - 165.0) ALLOWANCE RANGE CHART - STANDARD VALUE < VEHICLES FOR CANADA > STANDARD INDICATION km/h (mph) ALLOWANCE RANGE km/h (mph) 20 (12.4) 19 - 24 (11.8 - 14.9) 40 (24.8) 40 - 44 (24.8 - 27.3) 80 (49.7) 80 - 85 (49.7 - 52.8) 120 (74.6) 120.5 - 125.5 (74.9 - 78.0) 160 (99.4) 160.5 - 165.5 (99.7 - 102.8)
  7. If not within the standard value, check the tire size. If an incorrect size of tire is used, replace it and check again. If the tire size is correct, a defect may be present in components and circuit between the output shaft speed sensor and the combination meter. Check the following items. Output shaft speed sensor (refer to «DTC P1767 (P0720): OUTPUT SHAFT SPEED SENSOR SYSTEM (SHORT CIRCUIT/OPEN CIRCUIT)»(ref-241310-S30669797462006081100000) ). Combination meter (refer to «INSPECTION PROCEDURE 6: SPEEDOMETER DOES NOT WORK (OTHER METERS WORK); INSPECTION PROCEDURE 7: THE FUEL GAUGE NEEDLE MOVES EXCESSIVELY.»(ref-241292-S05768477342006081100000) .)

SPECIAL TOOL

SPECIAL TOOL TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB990784 Ornament remover General service tool Removal of rear combination light

Scheme 243

Scheme 243: SPECIAL TOOL

SPECIAL TOOL TOOL TOOL NUMBER AND NAME SUPER SESSION APPLICATION MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adapter Probe General service tool (jumper) Making voltage and resistance measurements during troubleshooting Connect pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting

Scheme 244

Scheme 244: SPECIAL TOOL

Scheme 245

Scheme 245

Scheme 246

Scheme 246: REMOVAL AND INSTALLATION

Scheme 247

Scheme 247: REMOVAL AND INSTALLATION

SPECIAL TOOLS TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adapter Probe General service tool (jumper) Making voltage and resistance measurements during troubleshooting Connect pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe General service tool Making voltage and resistance measurement during troubleshooting

Scheme 248

Scheme 248: SPECIAL TOOLS

Scheme 249

Scheme 249
