Starter - 2.0L: Specifications Mitsubishi Eclipse II

Starter 6 illustrations

STARTER SPECIFICATIONS

ApplicationIn. (mm)
Commutator Maximum Runout.002 (.05)
Commutator Minimum Diameter1.16 (29.4)
Commutator Undercut Depth.020 (.51)
Pinion Gap.020-.079 (.51-2.01)

STARTER SPECIFICATIONS

Scheme 1

Scheme 1
Scheme 1

Starting System Wiring Diagram (2.0L - W/O Anti-Theft). Scheme 2

Scheme 2: Starting System Wiring Diagram (2.0L - W/O Anti-Theft)
Scheme 2: Starting System Wiring Diagram (2.0L - W/O Anti-Theft)

Starting System Wiring Diagram (2.0L - A/T W/Anti-Theft). Scheme 3

Scheme 3: Starting System Wiring Diagram (2.0L - A/T W/Anti-Theft)
Scheme 3: Starting System Wiring Diagram (2.0L - A/T W/Anti-Theft)

Starting System Wiring Diagram (2.0L - M/T W/Anti-Theft). Scheme 4

Scheme 4: Starting System Wiring Diagram (2.0L - M/T W/Anti-Theft)
Scheme 4: Starting System Wiring Diagram (2.0L - M/T W/Anti-Theft)

Starting System Wiring Diagram (Turbo - W/O Anti-Theft). Scheme 5

Scheme 5: Starting System Wiring Diagram (Turbo - W/O Anti-Theft)
Scheme 5: Starting System Wiring Diagram (Turbo - W/O Anti-Theft)

Starting System Wiring Diagram (Turbo - A/T W/Anti-Theft). Scheme 6

Scheme 6: Starting System Wiring Diagram (Turbo - A/T W/Anti-Theft)
Scheme 6: Starting System Wiring Diagram (Turbo - A/T W/Anti-Theft)
