STARTER RELAY
- Remove starter relay. See «STARTER RELAY LOCATION»(ref-59924-S17843375392001011800000) table. With no power supplied to any relay, continuity should exist between relay terminals No. 1 and No. 2 and between relay terminals No. 3 and No. 4. (Scheme 9)
- Connect a jumper wire from positive battery terminal to relay terminal No. 1 and another jumper wire from negative battery terminal to relay terminal No. 2. Continuity should exist between relay terminals No. 4 and No. 5. (Scheme 9)
| Application | Location |
|---|---|
| Eclipse | Front Of Center Console |
STARTER RELAY LOCATION
Scheme 9
PINION GAP MEASUREMENT
- Disconnect field coil wire from terminal "M" at starter solenoid. see scheme 3 Connect jumper wire between positive battery terminal of 12-volt battery and terminal "S" of starter solenoid.
- Connect a second jumper wire from negative battery terminal and touch terminal "M" of starter solenoid. Measure clearance between pinion and stopper. (Scheme 10)
- Clearance should be within specification. See «STARTER SPECIFICATIONS»(ref-59924-S23337164012001011800000) table. Adjust clearance by adding or removing gaskets between solenoid and front housing.
