TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Lower arm forward bolt | 185 |
| Lower arm rearward nuts | 99 |
| Lower ball joint nut | 150 |
| Stabilizer bar bracket bolts | 55 |
| Stabilizer bar link nuts | 55 |
| Steering gear nuts and bolts | 117 |
| Strut rod nut | 130 |
| Strut-to-wheel knuckle nut | 175 |
| Subframe bracket bolts | 55 |
| Subframe forward bolts | 200 |
| Subframe rearward bolts | 175 |
| Tie-rod end nut | 115 |
| Upper catalytic converter-to-exhaust manifold bolts | 40 |
| Upper strut mount nuts | 35 |
| Wheel bearing and wheel hub bolts | 110 |
| Wheel hub nut | 350 |
| Wheel speed sensor bolt | 8 |
TORQUE SPECIFICATIONS
The front suspension consists of the following components
- Wheel bearing and wheel hubs
- Wheel studs
- Lower arms
- Stabilizer bar
- Stabilizer bar links
- Struts
- Springs
- Wheel knuckles
The front suspension utilizes a MacPherson strut system.
This suspension system incorporates a strut assembly that takes the place of the upper arm and ball joint. The strut carries out the function of a shock absorber and is encompassed by a coil spring. The strut and spring assembly supports the weight of the vehicle and is also the pivot point for the steering knuckle. This system uses a lower control arm and ball joint for the lower (unloaded) pivot point of the steering knuckle.
Refer to SUSPENSION SYSTEM - GENERAL INFORMATION article.
Scheme 9
| Item | Part Number | Description |
|---|---|---|
| 1 | W705967 | Wheel hub nut |
| 2 | 2C300 | Wheel bearing and wheel hub |
| 3 | 1107 | Wheel stud (5 required) (also part of 1104) |
| 4 | 3K171 LH/ 3K170 RH | Wheel knuckle |
| 5 | W710015 | Tie-rod end nut |
| 6 | W714331 | Wheel bearing and wheel hub bolt (4 required) |
| 7 | W710015 | Strut-to-wheel knuckle nut |
| 8 | W710396 | Strut-to-wheel knuckle flag bolt |
| 9 | 3051 LH/ 3042 RH | Lower control arm |
| 10 | W710015 | Lower ball joint nut |
| 11 | W710174 | Lower arm forward bolt |
| 12 | W520515 | Lower arm rearward nuts (2 required) |
| 13 | W708848 | Lower arm rearward bolt (2 required) |
| 14 | 3C339 LH/ 3C403 RH | Lower arm rearward bushing |
Scheme 10
| Item | Part Number | Description |
|---|---|---|
| 1 | W713760 | Stabilizer bar link upper nut |
| 2 | 5B420 | Strut and spring assembly |
| 3 | W710015 | Strut-to-wheel knuckle nut |
| 4 | W704790 | Strut upper mount nut (4 required) |
| 5 | W710396 | Strut-to-wheel knuckle flag bolt |
| 6 | 3B439 LH/ 3B438 RH | Stabilizer bar link |
Scheme 11
| Item | Part Number | Description |
|---|---|---|
| 1 | W713692 | Stabilizer bar bracket bolts (4 required) |
| 2 | W520213 | Stabilizer bar link lower nut (2 required) |
| 3 | W520213 | Stabilizer bar link upper nut (2 required) |
| 4 | 5482 | Stabilizer bar assembly |
| 5 | 3B439 LH/ 3B438 RH | Stabilizer bar link (2 required) |
- For additional information, refer to the procedures in this article.
