TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Air cleaner assembly bolt | 11 |
| Air cleaner assembly outlet pipe clamp | 5 |
| Selector lever bolts | 11 |
| Selector lever cable grommet nuts | 7 |
TORQUE SPECIFICATIONS
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 7A257 | Manual lever |
| 2 | Adjuster locking tab (part of 7E395) | |
| 3 | 7E395 | Selector lever cable |
| 4 | 57809 | Selector lever cable grommet |
| 5 | 7K004 | Selector lever assembly |
| 6 | 7L010 | Selector lever knob |
| 7 | Transmission control switch (TCS) (part of 7L010) | |
| 8 | 7E034 | Selector lever bezel |
The transaxle shift control linkage consists of
- a selector lever cable that connects the transaxle manual lever to the selector lever assembly.
- a brake shift interlock actuator that is integral to the selector lever assembly.
- a transmission control switch (TCS) that turns off the operation of 6th gear.
The selector lever assembly
- locks the transaxle selector lever in the PARK position when the ignition switch is in the LOCK position.
- requires the transaxle selector lever to be in the PARK position to turn the ignition switch to the LOCK position.
