Diagnostic Trouble Code (DTC) Chart
Note. Most powertrain (P-code) DTCs are diagnosed in the Powertrain Control/Emissions Diagnosis (PC/ED) manual. If the P-code retrieved is not listed below, refer to the Introduction - Gasoline Engines to continue diagnostics.
| DTC | Description | Source | Action |
|---|---|---|---|
| B1003 | Mode Door Circuit Failure | Electronic Automatic Temperature Control (EATC) Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1031 | SDARS Satellite Antenna Open | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1032 | SDARS Satellite Antenna Short | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B103A | Thermoelectric Driver Overcurrent High | Climate Controlled Seat Module | REFER to SEATING . |
| B103B | Thermoelectric Driver Overcurrent Low | Climate Controlled Seat Module | REFER to SEATING . |
| B103C | Thermoelectric Driver Open Load | Climate Controlled Seat Module | REFER to SEATING . |
| B103D | Blower Driver Overtemperature | Climate Controlled Seat Module | REFER to SEATING . |
| B1111 | Driver Thermal Electric Device Control Overtemperature Fault | Climate Controlled Seat Module | REFER to SEATING . |
| B1113 | Passenger Thermal Electric Device Control Overtemperature Fault | Climate Controlled Seat Module | REFER to SEATING . |
| B1117 | Audio Steering Wheel Button Stuck | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1119 | Audio Disc DVD Player Thermal Shutdown | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B111A | Passenger Thermoelectric Driver Overcurrent High | Climate Controlled Seat Module | REFER to SEATING . |
| B111B | Passenger Thermoelectric Driver Overcurrent Low | Climate Controlled Seat Module | REFER to SEATING . |
| B111C | Passenger Thermoelectric Driver Open Load | Climate Controlled Seat Module | REFER to SEATING . |
| B111D | Passenger Blower Driver Overtemperature | Climate Controlled Seat Module | REFER to SEATING . |
| B1136 | Audio Steering Wheel Switch #2 Circuit Failure | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1137 | Data Not Programmed | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1138 | Memory Full | Instrument Cluster | The smart junction box (SJB) has 4 integrated key head transmitter (IKT) keys stored in memory and cannot program any more IKTs into the SJB memory. REFER to ANTI-THEFT - PATS . |
| B1138 | Memory Full | SJB | The smart junction box (SJB) has 4 integrated key head transmitter (IKT) keys stored in memory and cannot program any more IKTs into the SJB memory. REFER to ANTI-THEFT - PATS . |
| B1139 | Invalid Transmitter Identification Code | Instrument Cluster | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1139 | Invalid Transmitter Identification Code | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1140 | Map Disk Invalid | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1154 | Subwoofer #1 Short to Ground | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1155 | Subwoofer #1 Short to Battery | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1156 | Subwoofer #2 Short to Ground | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1157 | Subwoofer #2 Short to Battery | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1158 | Subwoofer #2 Open | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1200 | Climate Control Push-button Circuit Failure | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1202 | Fuel Sender Circuit Open | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1204 | Fuel Sender Circuit Short to Ground | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1205 | EIC Switch-1 Assembly Circuit Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1209 | EIC Switch-2 Assembly Circuit Failure | Instrument Cluster | REFER to INFORMATION AND MESSAGE CENTER . |
| B1213 | Anti-Theft Number of Programmed Keys Is Below Minimum | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1231 | Event Threshold Exceeded | Restraints Control Module (RCM) | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1231 | Event Threshold Exceeded | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1234 | Mirror Switch Invalid Code | Driver Door Module (DDM) | REFER to REAR VIEW MIRRORS . |
| B1247 | Panel Dim Switch Circuit Open | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B1251 | Air Temperature Internal Sensor Circuit Open | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1253 | Air Temperature Internal Sensor Circuit Short to Ground | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1255 | Air Temperature External Sensor Circuit Open | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1309 | Power Door Lock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1317 | Battery Voltage High | All Wheel Drive (AWD) Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | DDM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | Digital Signal Processor | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | Driver Seat Module (DSM) | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | Instrument Cluster | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1317 | Battery Voltage High | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1317 | Battery Voltage High | THX® Amplifier | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Audio Control Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | AWD Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | DDM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Digital Signal Processor | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | DSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Instrument Cluster | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1318 | Battery Voltage Low | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | Satellite Radio Receiver | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1318 | Battery Voltage Low | THX® Amplifier | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| B1320 | Driver Door Ajar Circuit Open | SJB | REFER to INTERIOR LIGHTING . |
| B1328 | Passenger Door Ajar Circuit Open | SJB | REFER to INTERIOR LIGHTING . |
| B1331 | Decklid Ajar Rear Door Circuit Failure | SJB | REFER to INTERIOR LIGHTING . |
| B1336 | Door Ajar RR Circuit Open | SJB | REFER to INTERIOR LIGHTING . |
| B1341 | Power Door Unlock Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1342 | ECU is Faulted | Anti-Lock Brake System (ABS) Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| B1342 | ECU is Faulted | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | AWD Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | Climate Controlled Seat Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS . |
| B1342 | ECU is Faulted | DDM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DDM. REFER to Driver Door Module (DDM) . TEST the system for normal operation. |
| B1342 | ECU is Faulted | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | DSM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DSM. REFER to Driver Seat Module (DSM) . TEST the system for normal operation. |
| B1342 | ECU is Faulted | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1342 | ECU is Faulted | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1342 | ECU is Faulted | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1342 | ECU is Faulted | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1342 | ECU is Faulted | Satellite Radio Receiver | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . TEST the system for normal operation. |
| B1342 | ECU is Faulted | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B1342 | ECU is Faulted | Transmission Control Module (TCM) - FNR5 Transaxle | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| B1345 | Heated Backlight Input Circuit Short to Ground | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1352 | Ignition Key-In Circuit Failure | Instrument Cluster | REFER to WARNING DEVICES . |
| B1360 | Ignition Run/ACC Circuit Open | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1432 | Wiper Brake/Run Relay Circuit Short to Battery | SJB | REFER to WIPERS AND WASHERS . |
| B1433 | Wiper Brake/Run Relay Circuit Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B1447 | Wiper Park Sense Circuit Open | SJB | REFER to WIPERS AND WASHERS . |
| B1472 | Lamp Headlamp Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1483 | Brake Pedal Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| B1485 | Brake Pedal Input Short to Battery | SJB | REFER to EXTERIOR LIGHTING . |
| B1510 | Flash to Pass Switch Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1520 | Hood Switch Circuit Open | SJB | REFER to ANTI-THEFT - PERIMETER . |
| B1530 | Memory Set Switch Circuit Short to Ground | DDM | REFER to SEATING . |
| B1534 | Memory 1 Switch Circuit Short to Ground | DDM | REFER to SEATING . |
| B1538 | Memory 2 Switch Circuit Short to Ground | DDM | REFER to SEATING . |
| B1554 | Decklid Release Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1570 | Lamp Headlamp High-Beam Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1572 | Door Ajar LR Circuit Open | SJB | REFER to INTERIOR LIGHTING . |
| B1578 | Lamp Park Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1600 | PATS Ignition Key Transponder Signal is Not Received | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1601 | PATS Received Incorrect Key-Code From Ignition Key Transponder | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1602 | PATS Received Invalid Format of Key-Code From Ignition Key Transponder | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1623 | Lamp Keypad Output Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1663 | Seat Driver Front Up/Down Motor Stalled | DSM | REFER to SEATING . |
| B1664 | Seat Driver Rear Up/Down Motor Stalled | DSM | REFER to SEATING . |
| B1665 | Seat Driver Forward/Backward Motor Stalled | DSM | REFER to SEATING . |
| B1666 | Seat Driver Recline Motor Stalled | DSM | REFER to SEATING . |
| B1667 | Mirror Driver Up/Down Motor Stalled | DDM | REFER to REAR VIEW MIRRORS . |
| B1667 | Mirror Driver Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1668 | Mirror Driver Right/Left Motor Stalled | DDM | REFER to REAR VIEW MIRRORS . |
| B1668 | Mirror Driver Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1669 | Mirror Passenger Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1670 | Mirror Passenger Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS . |
| B1676 | Battery Pack Voltage Out of Range | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| B1676 | Battery Pack Voltage Out of Range | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B1681 | PATS Transceiver Module Signal Is Not Received | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B1688 | Lamp Dome Input Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING . |
| B1692 | Autolamp Delay Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1703 | Seat Driver Recline Forward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1707 | Seat Driver Recline Rearward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1711 | Seat Driver Front Up Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1715 | Seat Driver Front Down Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1719 | Seat Driver Forward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1723 | Seat Driver Rearward Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1727 | Seat Driver Rear Up Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1731 | Seat Driver Rear Down Switch Circuit Short to Battery | DSM | REFER to SEATING . |
| B1791 | Autolamp Sensor Input Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B1793 | Autolamp Sensor Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1795 | Lamp Headlamp Low-Beam Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B1797 | Lamp Headlamp Low-Beam Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1799 | Lamp Turn Signal Front Output Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B1801 | Lamp Turn Signal Front Output Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B1868 | Lamp Air Bag Warning Indicator Circuit Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B1875 | Turn Signal / Hazard Switch Signal Circuit Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B1884 | PAD Warning Lamp Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1890 | PAD Warning Lamp Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B1952 | Seat Rear Up/Down Position Feedback Circuit Short to Battery | DSM | REFER to SEATING . |
| B1953 | Seat Rear Up/Down Position Feedback Circuit Short to Ground | DSM | REFER to SEATING . |
| B1956 | Seat Front Up/Down Position Feedback Circuit Short to Battery | DSM | REFER to SEATING . |
| B1957 | Seat Front Up/Down Position Feedback Circuit Short to Ground | DSM | REFER to SEATING . |
| B1960 | Seat Recline Forward/Backward Position Feedback Circuit Short to Battery | DSM | REFER to SEATING . |
| B1961 | Seat Recline Forward/Backward Position Feedback Circuit Short to Ground | DSM | REFER to SEATING . |
| B1964 | Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Battery | DSM | REFER to SEATING . |
| B1965 | Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Ground | DSM | REFER to SEATING . |
| B19A1 | Passenger Seat Cushion Blower Speed Short to Battery | Climate Controlled Seat Module | REFER to SEATING . |
| B19A2 | Passenger Seat Back Blower Speed Short to Battery | Climate Controlled Seat Module | REFER to SEATING . |
| B19A3 | Driver Seat Cushion Blower Speed Short to Battery | Climate Controlled Seat Module | REFER to SEATING . |
| B19A4 | Driver Seat Back Blower Speed Short to Battery | Climate Controlled Seat Module | REFER to SEATING . |
| B19A5 | Passenger Seat Cushion Blower Speed Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B19A6 | Passenger Seat Back Blower Speed Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B19A7 | Driver Seat Cushion Blower Speed Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B19A8 | Driver Seat Back Blower Speed Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B2026 | Incandescent Backlight Output Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2027 | LED Backlight Output Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2030 | Front Fog Lamp Relay CKT Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2044 | Left Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2045 | Left Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2046 | Right Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2047 | Right Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2048 | Left Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2049 | Left Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2050 | Right Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2051 | Right Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING . |
| B2084 | Memory Set Indicator Short to Ground | DDM | REFER to SEATING . |
| B2103 | Antenna Not Connected | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2103 | Antenna Not Connected | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B2108 | Trunk Key Cylinder Switch Failure | SJB | REFER to ANTI-THEFT - PERIMETER . |
| B2116 | Door Driver Reset Switch Stuck Failure | DDM | REFER to ANTI-THEFT - PERIMETER . |
| B2116 | Door Driver Reset Switch Stuck Failure | SJB | REFER to ANTI-THEFT - PERIMETER . |
| B2141 | NVM Configuration Failure | Instrument Cluster | CARRY OUT a parameter reset of the instrument cluster and the powertrain control module (PCM). REFER to ANTI-THEFT - PATS . |
| B2143 | NVM Memory Failure | DDM | INSTALL a new DDM. REFER to Driver Door Module (DDM) . REPEAT the self-test. |
| B2143 | NVM Memory Failure | DSM | INSTALL a new DSM. REFER to Driver Seat Module (DSM) . REPEAT the self-test. |
| B2143 | NVM Memory Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2179 | Front Wiper Select Switch "A" Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2180 | Front Wiper Select Switch "B" Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2181 | Front Wiper Select Switch "C" Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2183 | Front Wiper Select Switch "H" Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2184 | Front Wiper Select Switch "W" Short to Ground | SJB | REFER to WIPERS AND WASHERS . |
| B2204 | GPS Antenna Connection Open or Short | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2207 | ECU ROM Checksum Error | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2223 | Mirror Driver Drive Circuit Failure | DDM | REFER to REAR VIEW MIRRORS . |
| B2223 | Mirror Driver Drive Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2224 | Mirror Passenger Drive Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2254 | Front Fog Lamp Switch Failure | SJB | REFER to EXTERIOR LIGHTING . |
| B2266 | Left Side Blend Door Circuit Failure | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2267 | Right Side Blend Door Circuit Failure | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2268 | Steering Wheel Climate Control Circuit Open | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2269 | Steering Wheel Climate Control Circuit Short to Ground | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2274 | Phone Transceiver Active Circuit Failure | Audio Control Module | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2274 | Phone Transceiver Active Circuit Failure | Audio Control Module (with Navigation) | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2276 | Less Than 2 Transmitters Programmed | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2281 | Right Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2282 | Left Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING . |
| B2290 | Occupant Classification System Fault | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2290 | Occupant Classification System Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2292 | Restraint System - Seatbelt Pretensioner Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2293 | Restraint System - Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2294 | Restraint System - Curtain Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2295 | Restraint System - Side Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2296 | Restraint System - Impact Sensor Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B229A | Occupant Classification Sensor Contamination | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B229B | Occupant Classification System Obstruction | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2312 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2314 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2316 | Mirror Passenger Vertical Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS . |
| B2318 | Mirror Passenger Vertical Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS . |
| B2320 | Mirror Driver Horizontal Feedback Potentiometer Circuit Failure | DDM | REFER to REAR VIEW MIRRORS . |
| B2322 | Mirror Driver Horizontal Feedback Potentiometer Circuit Short to Battery | DDM | REFER to REAR VIEW MIRRORS . |
| B2324 | Mirror Driver Vertical Feedback Potentiometer Circuit Failure | DDM | REFER to REAR VIEW MIRRORS . |
| B2326 | Mirror Driver Vertical Feedback Potentiometer Circuit Short to Battery | DDM | REFER to REAR VIEW MIRRORS . |
| B2384 | Audio Reverse Aid Mute Input CKT. Failure | Audio Control Module | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2390 | Master/Slave Communication Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2401 | Audio Tape Deck Mechanism Fault | Audio Control Module | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2401 | Audio Tape Deck Mechanism Fault | Audio Control Module (with Navigation) | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2404 | Audio Steering Wheel Switch Circuit Fault | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2405 | Audio Disc CD Player Thermal Shutdown Fault | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2406 | Audio Disc CD Player Internal Fault | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2425 | Remote Keyless Entry Out of Synchronization | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2426 | Passenger Solar Radiation Sensor Circuit Open | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2427 | Passenger Solar Radiation Sensor Circuit Short to Ground | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2431 | Transponder Programming Failed | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| B2434 | Drivers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2435 | Drivers Seat Belt Buckle Switch Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2438 | Passengers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2439 | Passengers Seat Belt Buckle Switch Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2477 | Module Configuration Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| B2477 | Module Configuration Failure | Audio Control Module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Climate Controlled Seat Module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Digital Signal Processor | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | DSM | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Instrument Cluster | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Occupant Classification Sensor | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | RCM | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | Satellite Radio Receiver | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | SJB | CONFIGURE the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs and VERIFY successful module configuration. If DTC B2477 is retrieved again, INSTALL a new SJB module. REFER to Smart Junction Box (SJB) . REPEAT the self-test. |
| B2477 | Module Configuration Failure | THX® Amplifier | REFER to MODULE CONFIGURATION . |
| B2479 | Park Brake Switch Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER . |
| B2486 | Climate Control Seat Module Voltage Out of Range | Climate Controlled Seat Module | REFER to SEATING . |
| B2498 | Headlamp Switch Multiple Signals Input Active | SJB | REFER to EXTERIOR LIGHTING . |
| B2499 | Courtesy Lamp Output Failure | SJB | REFER to INTERIOR LIGHTING . |
| B2572 | Brake Shift Interlock Output Circuit Failure | SJB | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS . |
| B2574 | Drivers Door LOCK Switch Short to Ground | DDM | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2575 | Drivers Door UNLOCK Switch Short to Ground | DDM | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2607 | Harness/Configuration Mismatch | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2627 | Fuel Sender Circuit Open #2 | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2628 | Fuel Sender Circuit Short to Ground #2 | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2633 | Driver-Front Microphone Circuit Failure | Audio Control Module (with Navigation) | DISREGARD the DTC. It is not applicable to this vehicle. CLEAR the DTCs. REPEAT the self-test. |
| B2656 | DVD (Digital Versatile Disk) Error | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2691 | Seat Belt Buckle Switch Circuit Fault, Front Driver's side | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2692 | Front Passenger's Seat Belt Buckle Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2695 | Keypad_A Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2696 | Keypad_B Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2697 | Keypad_C Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2729 | Cushion Over-Temp Detected | Climate Controlled Seat Module | REFER to SEATING . |
| B272A | Passenger Cushion Over-Temp Detected | Climate Controlled Seat Module | REFER to SEATING . |
| B272B | Passenger Back Over-Temp Detected | Climate Controlled Seat Module | REFER to SEATING . |
| B272C | Driver Differential Temperature Fault | Climate Controlled Seat Module | REFER to SEATING . |
| B272D | Passenger Differential Temperature Fault | Climate Controlled Seat Module | REFER to SEATING . |
| B272E | Driver Blower Circuit Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B272F | Passenger Blower Circuit Short to Ground | Climate Controlled Seat Module | REFER to SEATING . |
| B2730 | Back-Over Temp Detected | Climate Controlled Seat Module | REFER to SEATING . |
| B2792 | Cross Link Between Firing Loops | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| B2795 | Driver Solar Radiation Sensor Circuit Short to Ground | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2796 | Driver Solar Radiation Sensor Circuit Open | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| B2844 | Ignition Fault | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2879 | Fuel Tank Jet Pump Fault | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| B2900 | VIN Mismatch | ABS Module | REFER to MODULE CONFIGURATION . |
| B2913 | Audio Subwoofer Not Connected | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2913 | Audio Subwoofer Not Connected | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2924 | Audio Button Stuck | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2925 | Subwoofer Speaker Short Circuit | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B292A | Subwoofer #2 Speaker Short Circuit | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2947 | Global Opening/Closing Circuit Open | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B2949 | Global Opening/Closing Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS . |
| B2965 | Audio System Speaker Circuit Fault | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| B2965 | Audio System Speaker Circuit Fault | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| C1093 | Traction Control Disable Switch Circuit Failure | Instrument Cluster | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1095 | ABS Hydraulic Pump Motor Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1125 | Brake Fluid Level Sensor Input Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER . |
| C1145 | Speed Wheel Sensor RF Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1155 | Speed Wheel Sensor LF Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1165 | Speed Wheel Sensor RR Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1175 | Speed Wheel Sensor LR Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1233 | Speed Wheel LF Input Signal Missing | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1234 | Speed Wheel RF Input Signal Missing | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1235 | Speed Wheel RR Input Signal Missing | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1236 | Speed Wheel LR Input Signal Missing | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1274 | Solenoid Relay #1 Circuit Failure | SJB | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS . |
| C1284 | Oil Pressure Switch Failure | SJB | REFER to INSTRUMENT CLUSTER . |
| C1414 | Incorrect Module Design Level | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1805 | Mismatched PCM and/or ABS-TC Module | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1941 | Zero Seat Weight Test Failure | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM |
| C1946 | Front Driver's Seat Track Position Switch Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1947 | Front Driver's Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1948 | Front Driver's Seat Track Position Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1981 | Front Driver's Seat Track Position Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| C1991 | Module Calibration Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| C1992 | Vehicle Speed Circuit Failure | Audio Control Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| C1992 | Vehicle Speed Circuit Failure | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| C2780 | ECU in Manufacturer Sub-state | SJB | CONFIGURE the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs, and verify successful module configuration. If DTC B2477 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . REPEAT the self-test. |
| C2784 | RAM Checksum Failure | Instrument Cluster | REFER to INSTRUMENT CLUSTER . |
| P0562 | System Voltage Low | Transmission Control Module (TCM) (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| P0563 | System Voltage High | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| P0601 | Internal Control Module Memory Check Sum Error | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| P0603 | Internal Control Module Keep Alive Memory (KAM) Error | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| P0604 | Internal Control Module Random Access Memory (RAM) Error | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0604 | Internal Control Module Random Access Memory (RAM) Error | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| P0605 | Internal Control Module Read Only Memory (ROM) Error | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0625 | Generator Field Terminal Circuit Low | Powertrain Control Module (PCM) | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| P0626 | Generator Field Terminal Circuit High | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION . |
| P0706 | Transmission Range Sensor A Circuit Range/Performance | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0706 | Transmission Range Sensor A Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0707 | Transmission Range Sensor A Circuit Low | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0707 | Transmission Range Sensor A Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0708 | Transmission Range Sensor A Circuit High | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0708 | Transmission Range Sensor A Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0711 | Transmission Fluid Temperature Sensor A Circuit Range/Performance | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0711 | Transmission Fluid Temperature Sensor A Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0712 | Transmission Fluid Temperature Sensor A Circuit Low | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0712 | Transmission Fluid Temperature Sensor A Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0713 | Transmission Fluid Temperature Sensor A Circuit High | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0713 | Transmission Fluid Temperature Sensor A Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0715 | Turbine/Input Shaft Speed Sensor A Circuit | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0717 | Turbine/Input Shaft Speed Sensor A Circuit No Signal | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0720 | Output Shaft Speed Sensor Circuit | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0721 | Output Shaft Speed Sensor Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0722 | Output Shaft Speed Sensor Circuit No Signal | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0729 | Gear 6 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0730 | Incorrect Gear Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0731 | Gear 1 Incorrect Ratio | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0731 | Gear 1 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0732 | Gear 2 Incorrect Ratio | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0732 | Gear 2 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0733 | Gear 3 Incorrect Ratio | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0733 | Gear 3 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0734 | Gear 4 Incorrect Ratio | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0734 | Gear 4 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0735 | Gear 5 Incorrect Ratio | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0735 | Gear 5 Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0736 | Reverse Incorrect Ratio | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0741 | Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0742 | Torque Converter Clutch Solenoid Circuit Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0744 | Torque Converter Clutch Solenoid Circuit Intermittent | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0745 | Pressure Control Solenoid A | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0751 | Shift Solenoid A Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0752 | Shift Solenoid A Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0753 | Shift Solenoid A Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0756 | Shift Solenoid B Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0757 | Shift Solenoid B Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0758 | Shift Solenoid B Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0761 | Shift Solenoid C Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0762 | Shift Solenoid C Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0763 | Shift Solenoid C Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0766 | Shift Solenoid D Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0767 | Shift Solenoid D Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0768 | Shift Solenoid D Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0771 | Shift Solenoid E Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0772 | Shift Solenoid E Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0773 | Shift Solenoid E Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0777 | Pressure Control Solenoid B Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0778 | Pressure Control Solenoid B Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0780 | Shift Malfunction | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0791 | Intermediate Shaft Speed Sensor A Circuit | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0812 | Reverse Input Circuit | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| P0817 | Starter Disable Circuit/Open | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0841 | Transmission Fluid Pressure Sensor/Switch A Circuit Range/Performance | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0882 | TCM Power Input Signal Low | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0894 | Transmission Component Slipping | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P0961 | Pressure Control Solenoid A Control Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0962 | Pressure Control Solenoid A Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0963 | Pressure Control Solenoid A Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0973 | Shift Solenoid A Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0974 | Shift Solenoid A Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0976 | Shift Solenoid B Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0977 | Shift Solenoid B Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0978 | Shift Solenoid C Control Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0979 | Shift Solenoid C Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0980 | Shift Solenoid C Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0981 | Shift Solenoid D Control Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0982 | Shift Solenoid D Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0983 | Shift Solenoid D Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0984 | Shift Solenoid E Control Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0985 | Shift Solenoid E Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0986 | Shift Solenoid E Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0997 | Shift Solenoid F Control Circuit Range/Performance | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0998 | Shift Solenoid F Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P0999 | Shift Solenoid F Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1260 | Theft Detected, Vehicle Immobilized | PCM | REFER to ANTI-THEFT - PATS . |
| P1573 | Throttle Position Not Available | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1635 | Tire/Axle Out of Acceptable Range | AWD Module | REFER to MODULE CONFIGURATION . |
| P1657 | CAN Link Chip Malfunction | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1700 | Transmission Indeterminate Failure (Failed to Neutral) | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1701 | Reverse Engagement Error | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1719 | Engine Torque Signal | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1783 | Transmission Fluid Pressure Sensor/Switch A Circuit Range/Performance | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P1824 | 4-Wheel Drive Clutch Relay Circuit Failure | AWD Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS . |
| P1825 | 4-Wheel Drive Clutch Relay Open Circuit | AWD Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS . |
| P1919 | Engine Coolant Temperature Signal | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P1920 | Engine Speed Signal | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2544 | Torque Management Request Input Signal A | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2707 | Shift Solenoid F Performance or Stuck Off | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P2708 | Shift Solenoid F Stuck On | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P2709 | Shift Solenoid F Electrical | TCM (FNR5 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| P2757 | Torque Converter Clutch Pressure Control Solenoid Control Circuit Perf or Stuck Off | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2758 | Torque Converter Clutch Pressure Control Solenoid Stuck On | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2762 | Torque Converter Clutch Pressure Control Solenoid Control Circuit Range / Perf | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2763 | Torque Converter Clutch Pressure Control Solenoid Control Circuit High | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| P2764 | Torque Converter Clutch Pressure Control Solenoid Control Circuit Low | TCM (6 Speed Transaxle) | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| PXXXX | All other DTCs | PCM | REFER to the Introduction - Gasoline Engines . |
| U0002 | High Speed CAN Communication Bus Performance | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0020 | Low Speed CAN Communication Bus Performance | Instrument Cluster | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus Off | Digital Signal Processor | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus A Off | EATC Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus A Off | SJB | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0073 | Control Module Communication Bus A Off | TCM (FNR5 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| U0073 | Control Module Communication Bus A Off | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| U0100 | Lost Communication With ECM/PCM | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0100 | Lost Communication With ECM/PCM | TCM (FNR5 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| U0100 | Lost Communication With ECM/PCM | TCM (6 Speed Transaxle) | REFER to the Introduction - Gasoline Engines . |
| U0101 | Lost Communication with TCM | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0121 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0121 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | TCM (6 Speed Transaxle) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0140 | Lost Communication With Body Control Module (GEM) | Audio Control Module (with Navigation) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0140 | Lost Communication With Body Control Module (GEM) | EATC Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | Audio Control Module (with Navigation) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | EATC Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0159 | Lost Communication With Parking Assist Control Module (PAM) | Audio Control Module (with Navigation) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0184 | Lost Communication With Radio (ACM) | Satellite Radio Receiver | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0184 | Lost Communication With Radio (ACM) | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0193 | Lost Communication With Digital Audio Control Module (SDARS) | Audio Control Module (with Navigation) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | Satellite Radio Receiver | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0197 | Lost Communication With Telephone Control Module | Satellite Radio Receiver | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0197 | Lost Communication With Telephone Control Module | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0238 | Lost Communication With Digital Audio Control Module "D" (DSP) | Audio Control Module (with Navigation) | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0246 | Lost Communication With Seat Control Module (DCSM) | EATC Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0249 | Lost Communication With Entertainment Control Module - Rear "B" (RCU) | Audio Control Module (with Navigation) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0249 | Lost Communication With Entertainment Control Module - Rear "B" (RCU) | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U0300 | Internal Control Module Software Incompatibility | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| U0401 | Invalid Data Received from ECM/PCM A | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0402 | Invalid Data Received from TCM | AWD Module | REFER to MODULE COMMUNICATIONS NETWORK . |
| U0415 | Invalid Data Received from Anti-Lock Brake System (ABS) Control Module | AWD Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| U0415 | Invalid Data Received from Anti-Lock Brake System (ABS) Control Module | TCM (6 Speed Transaxle) | RETRIEVE and FOLLOW DTCs from ABS module. REFER to VEHICLE DYNAMIC SYSTEMS . |
| U1020 | SCP (J1850) Invalid or Missing Data for Air Conditioning Clutch | EATC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| U1900 | CAN Communication Bus Fault - Receive Error | ABS Module | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | Audio Control Module | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | Digital Signal Processor | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | DSM | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | Instrument Cluster | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | Occupant Classification Sensor | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | RCM | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1900 | CAN Communication Bus Fault - Receive Error | SJB | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1900 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U1901 | CAN Network #2 Communication Bus Fault - Receive Error | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS . |
| U1901 | CAN Network #2 Communication Bus Fault - Receive Error | Instrument Cluster | REPAIR all other DTCs first. CLEAR the DTCs. CYCLE the key OFF then ON and wait 10 seconds. REPEAT the self-test. If DTC U1901 is still present, REFER to MODULE COMMUNICATIONS NETWORK . |
| U2013 | Compass Module is not Responding | Instrument Cluster | REFER to INFORMATION AND MESSAGE CENTER . |
| U2023 | Fault Received From External Node | ABS Module | RETRIEVE and FOLLOW non-network DTCs from other modules. |
| U2023 | Fault Received From External Node | Instrument Cluster | RETRIEVE and FOLLOW non-network DTCs from other modules. |
| U2050 | No Application Present | ABS Module | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | Audio Control Module | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | Climate Controlled Seat Module | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | DDM | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U2050 | No Application Present | DSM | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | EATC Module | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | Instrument Cluster | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | Occupant Classification Sensor | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | RCM | REFER to MODULE CONFIGURATION . |
| U2050 | No Application Present | SJB | CONFIGURE the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. RETRIEVE the DTCs and VERIFY successful module configuration. If DTC U2050 is retrieved again, INSTALL a new SJB module. REFER to Smart Junction Box (SJB) . REPEAT the self-test. |
| U2050 | No Application Present | Satellite Radio Receiver | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U2050 | No Application Present | TCM (FNR5 Speed Transaxle) | INSTALL a new TCM. REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - FNR5 . |
| U2050 | No Application Present | TCM (6 Speed Transaxle) | INSTALL a new TCM. REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6 SPEED . |
| U2050 | No Application Present | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U2051 | One or More Calibration Files Missing / Corrupt | Audio Control Module | REFER to MODULE CONFIGURATION . |
| U2051 | One or More Calibration Files Missing / Corrupt | AWD Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS . |
| U2051 | One or More Calibration Files Missing/Corrupt | Digital Signal Processor | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U2051 | One or More Calibration Files Missing / Corrupt | EATC Module | REFER to MODULE CONFIGURATION . |
| U2051 | One or More Calibration Files Missing / Corrupt | Instrument Cluster | REFER to MODULE CONFIGURATION . |
| U2051 | One or More Calibration Files Missing/Corrupt | Occupant Classification Sensor | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| U2051 | One or More Calibration Files Missing / Corrupt | RCM | REFER to MODULE CONFIGURATION . |
| U2051 | One or More Calibration Files Missing / Corrupt | THX® Amplifier | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| U2473 | Unexpected Vehicle Speed (VSS) | Audio Control Module (with Navigation) | REFER to the Introduction - Gasoline Engines . |
| U2510 | CAN-Invalid Data for Vehicle Security | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
| U2511 | CAN-Data Mis-Match (Receive Data Does Not Match Expected) | Instrument Cluster | REFER to ANTI-THEFT - PATS . |
DIAGNOSTIC TROUBLE CODE (DTC) CHART
Inspection and Verification
- Verify the customer concern.
- Visually inspect the following for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Smart junction box (SJB) fuse 20 (7.5A) Circuitry Driver door module (DDM)
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) , No Power to The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) to diagnose no response from the powertrain control module (PCM).
- Carry out the network test: If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the DDM.
- If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Chart»(ref-271107-S08198459192007110800000) .
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(ref-271107-S30385838232007111500000) .
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the driver door module (DDM) | Fuse Circuitry DDM | REFER to MODULE COMMUNICATIONS NETWORK . |
Symptom Chart
- Verify the customer concern.
- Visually inspect the following for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 15 (10A) Circuitry Driver seat module (DSM)
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) , No Power to The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) to diagnose no response from the powertrain control module (PCM).
- Carry out the network test: If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the DSM.
- If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Chart»(ref-271107-S08198459192007110800000) .
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(ref-271107-S19411116852007111500000) .
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the driver seat module (DSM) | Fuse Circuitry DSM | REFER to MODULE COMMUNICATIONS NETWORK . |
Symptom Chart
- Verify the customer concern.
- Visually inspect the following for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 19 (40A) Circuitry Smart junction box (SJB)
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) , No Power to The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) to diagnose no response from the powertrain control module (PCM).
- Carry out the network test: If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-271106) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the SJB.
- If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Chart»(ref-271107-S08198459192007110800000) .
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(ref-271107-S05054326682007111500000) .
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the smart junction box (SJB) | Fuse SJB Circuitry | REFER to MODULE COMMUNICATIONS NETWORK . |
Symptom Chart
Scheme 68
| Item | Part Number | Description |
|---|---|---|
| 1 | DDM nuts (2 required) | |
| 2 | DDM electrical connectors (part of 14631) | |
| 3 | 13C791 | DDM |
