TV tuner, location/task/design/function - GF82.60-P-3109TA
Model 211.0/2 up to 31.5.05 with CODE (527) COMAND APS (with navigation) with CODE (860) TV tuner
Shown on model 211.0
Scheme 262
| TV tuner location | The TV tuner (A2/10) on models 211.0/2 is located at the side wall behind the left, inner wheelhouse liner above the navigation processor (N41/1). | |
|---|---|---|
| TV tuner, task | Reception and processing of analog video and audio signals Forwarding of video and audio signals to the COMAND operating, display and control unit (A40/3) and the audio gateway control unit (N93/1) | |
| TV tuner, design | 4-fold antenna diversity, separated into video and audio signals TV-tuner module for audio and video reception Multistandard receiver Multistandard signal processing | |
| TV tuner, function | GF82.60-P-3109-02TA |
TV tuner, location/task/design/function - GF82.60-P-3109TB
Model 211.0/2 as of 1.6.05 with CODE (527) COMAND APS (with navigation) with CODE (863) Digital/analog TV tuner
Shown on model 211.0
Scheme 263
| TV tuner location | The TV combination tuner (analog/digital) (A90/1) on models 211.0/2 is located on the side wall behind the left, inner wheelhouse liner above the navigation processor (N41/1). | |
|---|---|---|
| TV tuner, task | Reception of analog and terrestrial digital TV signals Forwarding of video and audio signals to the COMAND operating, display and control unit (A40/3) and the audio gateway control unit (N93/1) | |
| TV tuner, design | 4-fold antenna diversity, separated into video and audio signals TV-tuner modules for audio and video reception Multistandard receiver Multistandard signal processing | |
| TV tuner, function | GF82.60-P-3109-02TB |
TV tuner, location/task/design/function - GF82.60-P-3109TJ
MODEL 211.0/2 with CODE (529) HIGH Class Japan
Shown on model 211.0
Scheme 264
| TV tuner location | The TV tuner is integrated in the COMAND operating, display and control unit (A40/3), which is installed in the center console between the operating module for interior AC (automatic air conditioning) and upper control panel. | |
|---|---|---|
| TV tuner, purpose | To receive and process video and audio signals as well as communication with other system components via the optical MOST bus. Video and sound are played back via the COMAND operating, display and control unit (A40/3) and the vehicle's speakers. | |
| TV tuner, design | 4-fold antenna diversity, divided into audio/video signals TV tuner module for audio and video Receiver Signal processing | |
| TV tuner, function | GF82.60-P-3109-02TJ |
Radio control panel, location/task/design/function - GF82.60-P-3115TC
MODEL 211.0/2 as of 1.3.03
Location of component
Scheme 265
| Radio control panel, location | The radio (A2) (Audio 20 CD) is installed in the 2-DIN recess in the center console between the interior air conditioning operating module and the upper control panel. | |
|---|---|---|
| Radio control panel, task | Central control of the following systems: Radio CD changer Sound system (Basic/Sound) Voice control system Telephone | |
| Radio control panel, design | GF82.60-P-3115-03TC | |
| Radio control panel, function | GF82.60-P-3115-04TC |
