THERMOSTAT HOUSING REMOVAL/INSTALLATION - 2.5L

Note. The thermostat and thermostat housing are serviced as an assembly.

Scheme 3

1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
2. Drain the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .
3. Remove the accessory drive belt. See «ACCESSORY DRIVE BELT REMOVAL/INSTALLATION - 2.5L»(ref-348658-S27114047842009112700000) .
4. Remove the 3 bolts and reposition the thermostat housing to gain access to the hose clamps. Remove and discard the gasket. To install, tighten to 10 N.m {1.0 kgf.m, 89 in.lbf}.
5. Disconnect the heater hose at the thermostat housing.
6. Disconnect the lower radiator hose at the thermostat housing.
7. To install, reverse the removal procedure. Install a new gasket.
8. Fill and bleed the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .

Scheme 4

1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
2. Drain the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .
3. Remove the accessory drive belt. See «ACCESSORY DRIVE BELT REMOVAL/INSTALLATION - 2.5L»(ref-348658-S27114047842009112700000) .
4. Remove the 3 bolts and the water pump pulley. To install, tighten to 20 N.m {2.0 kgf.m, 177 in.lbf}.
5. Remove the 3 bolts and the water pump. Remove and discard the water pump O-ring seal. To install, tighten to 10 N.m {1.0 kgf.m, 89 in.lbf}. CAUTION: Make sure the coolant pump is correctly seated to the engine block before installing and tightening the fasteners, or damage to the coolant pump may occur.
6. To install, reverse the removal procedure. Lubricate the new O-ring seal with clean engine coolant.
7. Fill and bleed the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .

Scheme 5

Scheme 6

1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
2. Drain the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .
3. Remove the front bumper cover. See «FRONT BUMPER COVER REMOVAL/INSTALLATION»(ref-348676-S20817421802009112700000) .
4. Remove the front impact severity sensor. See «FRONT IMPACT SEVERITY SENSOR REMOVAL/INSTALLATION»(ref-348640-S42590226102009112700000) .
5. Remove the 2 pin-type retainers.
6. Remove the 4 bolts and the 2 radiator brackets. To install, tighten to 10 N.m {1.0 kgf.m, 89 in.lbf}.
7. Loosen the nut, remove the 2 bolts and position aside the hood latch. To install, tighten to 9 N.m {0.9 kgf.m, 80 in.lbf}. NOTE: Mark the hood latch position prior to removal of the bolts.
8. Remove the 2 wiring harness retainers from the front bumper bracket.
9. Remove the center support bolt. To install, tighten to 10 N.m {1.0 kgf.m, 89 in.lbf}.
10. Disconnect the cooling fan resistor electrical connector.
11. Disconnect the coolant recovery hose from the radiator and position it aside.
12. Disconnect the 2 cooling fan electrical connectors and the wire harness retainers.
13. Remove the 2 cooling fan bolts and the cooling fan motor and shroud. To install, tighten to 10 N.m {1.0 kgf.m, 89 in.lbf}.
14. To install, reverse the removal procedure.
15. Fill and bleed the cooling system. See «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .

CYLINDER BLOCK - CORE PLUG REPLACEMENT - 2.5L

Note. Cylinder block core plug shown in figure, cylinder head core plug similar.

Scheme 7

1. Use a slide hammer or tools suitable to remove the cylinder block core plug.
2. Inspect the cylinder block plug bore for any damage that would interfere with the correct sealing of the plug. If the cylinder block plug bore is damaged, bore for the next oversize plug. NOTE: Oversize plugs are identified by the OS stamped in the flat located on the cup side of the plug.

Scheme 8

1. Coat the cup-type core plug and bore lightly with sealant and install the core plug. Use a suitable tool to seat the cup-type core plug. CAUTION: Use care during this procedure so as not to disturb or distort the cup sealing surface. CAUTION: When installed, the flanged edge must be below the chamfered edge of the bore to effectively seal the bore.

Scheme 9

1. Coat the expansion-type core plug and bore lightly with sealant and install the core plug. Use a suitable tool to seat the expansion-type core plug. CAUTION: Do not contact the crown when installing an expansion-type cylinder block core plug. This could expand the plug before seating and result in leakage.

Scheme 10

1. With the vehicle in NEUTRAL, position it on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
2. Drain the cooling system. See COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L01-12A-7.
3. Disconnect the block heater electrical connector. CAUTION: Make sure that the block heater wiring is routed and secured away from rotating or hot components or damage to the wiring may occur.
4. Remove the block heater. To install, tighten to 21 N.m {2.1 kgf.m, 15 ft.lbf}.
5. To install, reverse the removal procedure.
6. Fill and bleed the cooling system. For additional information, see «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - 2.5L»(ref-348664-S29598792362009112700000) .
