Thermostat
A new thermostat should be installed only after the following tests and checks have been carried out
- PINPOINT TEST 1: LOSS OF COOLANT 01-01A-454, PINPOINT TEST 2: THE ENGINE OVERHEATS 01-01A-456 or PINPOINT TEST 3: THE ENGINE DOES NOT REACH NORMAL OPERATING TEMPERATURE 01-01A-459. Located in «ENGINE»(ref-348627-S28849717802009112700000) article.
- Thermostat Visual Inspection
Filling and Bleeding
| CAUTION | Engine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle. When adding engine coolant, use a 50/50 mixture of engine coolant and distilled water. To maintain the integrity of the coolant and the cooling system: Vehicle cooling systems are filled with Mazda Premium Gold Engine Coolant. Do not mix coolant types. Do not add/mix orange-colored, extended life coolant such as Mazda Specialty Orange Engine Coolant, meeting Mazda specifications or green colored Mazda coolant. Mixing coolants may degrade the coolant's corrosion protection. Do not add alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating of freezing. Mazda does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Mazda Premium Gold Engine Coolant since a Mazda-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner. Follow your community's regulations and standards for recycling and disposing of automotive fluids. |
Note. The addition of Cooling System Stop Leak Pellets or equivalent meeting Mazda specification darkens Mazda Premium Engine Coolant from yellow to golden tan.
Scheme 16
- Open the degas bottle cap and bleed valve on the back of the engine water outlet. NOTE: Make sure the coolant flows from the radiator through the upper radiator hose and fills the engine. When full, coolant should flow from the bleed hole.
- Fill the degas bottle to the MAX fill line.
- Close the degas bottle cap and the bleed valve.
- Start the engine and let it idle for 30 minutes or until the engine reaches normal operating temperature. CAUTION: If the engine overheats or the fluid level drops below the minimum fill line, shut off the engine and add fluid to the degas bottle maximum fill line once the engine cools. Failure to follow these instructions may result in damage to the engine.
- Allow the engine to cool and repeat Step 2 if necessary.
- Start the engine and turn the heater to the MAX position.
- Run the engine at 2,500 rpm for 10 minutes. CAUTION: If the engine overheats or the fluid level drops below the minimum fill line, shut off the engine and add fluid to the degas bottle maximum fill line once the engine cools.
- Repeat Step 7 if necessary.
- Check the engine coolant level in the degas bottle and fill as necessary. WARNING: Always allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.
