AIR BLEEDING

CAUTIONBrake fluid will damage painted surfaces. Be careful not to spill any on painted surfaces. If it is spilled, wipe it off immediately.

Note. Keep the fluid level in the reserve tank at 3/4 full or more during the air bleeding. Begin air bleeding with the master cylinder and then continue with the brake caliper that is furthest away from the master cylinder. Finish by bleeding air from the master cylinder again.

Brake fluid type

SAE J1703, FMVSS 116 DOT-3

Scheme 48

Scheme 48
  1. Remove the bleeder cap from the brake caliper, and connect a vinyl tube to the bleeder screw.
  2. Place the other end of the vinyl tube in a clear container, and fill the container with fluid during air bleeding.
  3. Working with two people, one should depress the brake pedal a few times and then depress and hold the pedal down.
  4. While the brake pedal is being held down, the other person should loosen the bleeder screw using the SST , and bleed any fluid containing air bubbles. Once completed, tighten the bleeder screw. Tightening torque Front: 6.9-9.8 N.m {71-99 Kgf.cm, 62-86 in.lbf} Rear: 6.0-8.0 N.m {62-81 Kgf.cm, 54-70 in.lbf}
  5. Repeat Steps 3 and 4 until no air bubbles are seen.
  6. Perform air bleeding as described in the above procedures for all brake calipers.
  7. After air bleeding, inspect the following: Brake operation Fluid leakage Fluid level

Scheme 49

Scheme 49: VACUUM LINE INSPECTION
  1. Remove the vacuum hose between the power brake unit and the intake manifold using pliers.
  2. Verify that air can be blown from the power brake unit side of the vacuum hose towards the intake manifold side, and that air cannot be blown in the opposite direction. If there is any malfunction of the inner check valve, replace it together with the vacuum hose as a single unit.

Scheme 50

Scheme 50: Brake Pedal Height Inspection
  1. Measure the distance from the center of the upper surface of the pedal pad to the insulator and verify that it is as specified. If not within the specification, adjust the pedal height. Brake pedal height (reference value) 167 mm {6.57 in}

Checking For Vacuum Loss (Loaded Condition)

  1. Start the engine.
  2. Depress the brake pedal with a force of 200 N {20.4 kgf, 44.9 lbf} .
  3. With the brake pedal depressed, turn off the engine when the vacuum gauge reaches 68 kPa {510 mmHg, 20.1 inHg} .
  4. Within 15 s right after stopping the engine, measure the lowest amount of vacuum.
  5. If the lowest amount is 3.3 kPa {25 mmHg, 1.0 inHg} or less, the system is normal.
