Conventional Brake System: Adjustments Mazda MX-5 NC

Mechanical - Hydraulic 1 illustration

Brake Pedal Height Adjustment

CAUTIONThe brake switch may not operate normally after adjusting the pedal height. Whenever adjusting the pedal height, replace the brake switch with a new one. The interlock cable may not operate normally after adjusting the pedal height. Whenever adjusting the pedal height, refer to the interlock cable installation note. (See INTERLOCK CABLE INSTALLATION NOTE .)

Scheme 2

Scheme 2
Scheme 2
  1. Loosen the locknut and turn the push rod to adjust the pedal height.
  2. Tighten the locknut. Tightening torque 20.4-30.6 N.m {2.09-3.12 Kgf.m, 15.0-22.5 ft.lbf}
  3. After adjustment, inspect the pedal play.
