Power Brake Unit Fluid Pressure
| Vacuum amount at o kPa {0 mmHg, 0 inHg} | |
|---|---|
| Pedal force (N {kgf, lbf}) | Fluid pressure (kPa {kgf/cm 2 , psi}) |
| 200 {20.4, 44.9} | 620 {6.33, 90.0} or more |
POWER BRAKE UNIT FLUID PRESSURE SPECIFICATIONS
| Vacuum amount at 66.7 kPa {500 mmHg, 19.7 inHg} | |
|---|---|
| Pedal force (N {kgf, lbf}) | Fluid pressure (kPa {kgf/cm 2 , psi}) |
| 200 {20.4, 44.9} | 6,340 {64.65, 919.6} or more |
POWER BRAKE UNIT FLUID PRESSURE SPECIFICATIONS
Scheme 34
Scheme 35
Scheme 36
- Remove the master cylinder. (See «MASTER CYLINDER REMOVAL/INSTALLATION»(ref-244464-S03412757792006092400000).)
- Remove the clutch pipe. (MT)
- Remove the nut (Scheme 37), then remove the cooler hose (LO) bracket from the vehicle.
- Remove in the order indicated in (Scheme 36).
- Install in the reverse order of removal.
- After installation, perform brake pedal inspection. (See «BRAKE PEDAL INSPECTION»(ref-244464-S11006378782006092400000).)
Scheme 37
- Connect the SSTs to the brake pipes (Scheme 38)
- Bleed the air from the brake system and the SSTs. (Bleed the air from the SSTs through air bleeding valve A.)
- Measure the fluid pressure of the master cylinder and the rear brake. If not within the specification, replace the dual proportioning valve.
Scheme 38
| MASTER CYLINDER PRESSURE (kPa {kgf/cm 2 , psi}) | REAR BRAKE PRESSURE (kPa {kgf/cm 2 , psi}) |
|---|---|
| A: 3,430 {34.98, 497.5} | A': 3,130 {31.92, 453.9} - 3,730 {38.04, 540.9} |
| B: 5,880 {59.96, 852.8} | B': 4,010 {40.9, 581.7} - 4,810 {49.05, 697.6} |
VALVE FLUID PRESSURE SPECIFICATIONS
Scheme 39
- Remove in the order indicated in (Scheme 40).
- Install in the reverse order of removal.
Scheme 40
- Place an alignment mark on the brake pipe and dual proportioning valve.
Scheme 41
- Install the dual proportioning valve so that the R marks faces the upper side of the vehicle.
Scheme 42
- Align the marks made before removal and install the brake pipe to the dual proportioning valve referring to see scheme 29.
