Wiring Harness
- To remove the wiring harness from the clip in the engine room, pry up the hook of the clip using a flathead screwdriver.
Scheme 16
| CAUTION | Do not remove the harness protective tape. Otherwise, the wires could rub against the body, which could result in water penetration and electrical shorting. |
Scheme 17
Scheme 18
- When disconnecting connector, grasp the connectors, not the wires.
- Connectors can be disconnected by pressing or pulling the lock lever see scheme 32
Scheme 19
Wiring Color Codes
- Two-color wires are indicated by a two-color code symbol.
- The first letter indicates the base color of the wire and the second the color of the stripe.
| CODE | COLOR | CODE | COLOR |
|---|---|---|---|
| B | Black | O | Orange |
| BR | Brown | P | Pink |
| G | Green | R | Red |
| GY | Gray | V | Violet |
| L | Blue | W | White |
| LB | Light Blue | Y | Yellow |
| LG | Light Green |
WIRING COLOR CODES REFERENCE
Scheme 20
Scheme 21
Scheme 22
- When replacing a fuse, be sure to replace it with one of the same capacity. If a fuse fails again, the circuit probably has a short and the wiring should be inspected.
- Be sure the negative battery terminal is disconnected before replacing a main fuse.
- When replacing a pullout fuse, use the fuse puller.
Vehicle Harness-Side Connector
The viewing direction of vehicle harness-side connectors is from the harness side.
*: Part names are shown only when there are multiple connector drawings.
