Entertainment System: Removal & Installation Mazda MX-5 NC

AUDIOPILOT MICROPHONE REMOVAL/INSTALLATION

Note. "AudioPilot" is a registered trademark of Bose Corporation.

Scheme 12

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Remove in the order indicated in (Scheme 12).
4. Install in the reverse order of removal.

Scheme 13

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Remove the jack.
4. Remove in the order indicated in (Scheme 13).
5. Install in the reverse order of removal.

Scheme 14

1. Use snap-ring pliers to remove the mounting nut.

AUDIO CONTROL SWITCH REMOVAL/INSTALLATION

Note. For vehicles with the cruise control system, the audio control switch harness and the cruise control switch harness are united, therefore they cannot be separated.

Scheme 15

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244489-S36157782332006092400000).)
4. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-244476-S08528774112006092400000).)
5. Remove in the order indicated in (Scheme 15).
6. Install in the reverse order of removal.

Scheme 16

Scheme 17

1. Verify the resistance and continuity between the audio control switch terminals. If the resistance and continuity are not as indicated in the tables, replace the audio control switch.

AUDIO CONTROL SWITCH POSITION RESISTANCE

Scheme 18

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-244480-S13223079142006092400000).)
4. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244480-S26287572182006092400000).)
5. Remove the console panel. (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-244480-S42244014272006092400000).)
6. Remove in the order indicated in (Scheme 18).
7. Install in the reverse order of removal.

Scheme 19

1. While pressing a tape-wrapped flathead screwdriver against the cap projection, pull the accessory socket outward.

Scheme 20

1. While pressing the tabs, pull the cap outwards.

Scheme 21

1. Connect a tester (Scheme 21)and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.
