Entertainment System: Overview Mazda MX-5 NC

Scheme 1

Scheme 2

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-244448-S25513985422006092400000).)
3. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-244480-S02909833382006092400000).)
4. Remove the knee bolster. (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-244480-S00266461682006092400000).)
5. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244480-S26287572182006092400000).)
6. Remove in the order indicated in (Scheme 2).
7. Install in the reverse order of removal. CAUTION: When installing the center panel unit, make sure that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the wiring harness or the antenna feeder is caught between the unit and dashboard, it may cause malfunctions.

Scheme 3

1. Pull the center panel unit outward, detach clip A from the dashboard, and then remove the center panel unit. CAUTION: Verify that bolt has been removed when pulling the center panel unit outward. If the center panel unit is pulled with bolt installed, stress will be applied to the connectors inside the panel which may cause a malfunction.
2. When removing the center panel unit, disconnect the audio unit connector (24-pin) first to aid in disconnecting other connectors and the antenna plug.
