DTC C1093 POSSIBLE CAUSE DTC C1093 DSC OFF switch system DETECTION CONDITION Continuous ON signal from the DSC OFF switch for 5 s or more is detected. POSSIBLE CAUSE The driver pressed and held the DSC OFF switch for 5 s or more. Short to ground in the wiring harness between the DSC HU/CM terminal P and the DSC OFF switch terminal A DSC OFF switch malfunction
