Lighting Systems: Overview Mazda MX-5 NB рестайлинг

Steering Column Switches 3 illustrations ~162 words

Scheme 1

Scheme 1: HEADLIGHT ADJUSTMENT
Scheme 1: HEADLIGHT ADJUSTMENT

Scheme 2

Scheme 2
Scheme 2
  1. Adjust the tire air pressure to the specification.
  2. Position the unloaded vehicle on a flat, level surface.
  3. Seat one person in the driver's seat.
  4. Position the vehicle straight ahead and perpendicularly to a wall.
  5. Set the headlights 3 m {10 ft} from the white screen.
  6. While adjusting one headlight, disconnect the connector of the other.
  7. Start the engine to charge the battery.
  8. Adjust the headlights by turning the adjusting screws as shown in the figure. Loosen the screws first, then tighten them. NOTE: If the adjusting screws are tightened first, then loosened, they will continue to loosen when the vehicle is in motion and may cause the headlights to become misaligned.

Scheme 3

Scheme 3: FRONT COMBINATION LIGHT REMOVAL/INSTALLATION
Scheme 3: FRONT COMBINATION LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION».)
  3. Remove in the order indicated in the figure.
  4. Install in the reverse order of removal.
  5. Adjust the headlight aiming. (See «HEADLIGHT ADJUSTMENT».)
