Lighting Systems: Removal & Installation Mazda MX-5 NB рестайлинг

HEADLIGHT BULB REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 26

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 27

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 28

Scheme 29

1. Adjust the tire air pressure to the specification.
2. Position the unloaded vehicle on a flat, level surface.
3. Seat one person in the driver's seat.
4. Position the vehicle straight ahead and perpendicularly to a wall.
5. Set the front fog light 3 m {10 ft} from the white screen.
6. While adjusting one front fog light, disconnect the connector of the other.
7. Start the engine to charge the battery.
8. Turn over the mud guard.
9. Adjust the front fog light by turning the adjusting screws as shown in the figure. Loosen the screws first, then tighten them. NOTE: If the adjusting screws are tightened first, then loosened, they will continue to loosen when the vehicle is in motion and may cause the front fog light to become misaligned.

Scheme 30

1. Disconnect the negative battery cable.
2. Turn over the mud guard.
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.
5. Adjust the front fog light. (See «FRONT FOG LIGHT ADJUSTMENT»(ref-194478-S02810520322005092800000) .)

Scheme 31

1. Disconnect the negative battery cable.
2. Turn over the mud guard.
3. Remove in the order indicated in the figure. CAUTION: A halogen bulb generates extremely high heat when it is used. If the surface of the bulb is soiled, excessive heat will build up and the light's life will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Install in the reverse order of removal.

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-194477-S12178783302005092800000) .)
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 34

Scheme 35

1. Insert a tape-wrapped flathead screwdriver into the left side opening.
2. Press the tab of the high-mount brake light with a tape-wrapped flathead screwdriver.
3. Pull the high-mount brake light out from the body.

Scheme 36

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 37

1. (1) Slide the license plate light to the arrow mark and (2) remove it.

Scheme 38

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 39

Scheme 40

1. Disconnect the back-up light switch connector.
2. Inspect for continuity between the back-up light switch terminals using an ohmmeter. If not as specified, replace the back-up light switch.

Scheme 41

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE»(ref-160474-S09599032302004021000000) .)
3. Remove the steering wheel. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-194455-S15680145342005092800000) .)
4. Remove the column cover.
5. Remove the clock spring. (See «CLOCKSPRING»(ref-160474-S33685584382004021000000) .)
6. Remove in the order indicated in the figure.
7. Install in the reverse order of removal.

Scheme 42

1. Disassemble in the order indicated in the figure.
2. Assemble in the reverse order of disassembly.

Scheme 43

1. Make sure the terminals of the harness assembly are connected to the terminals of the connector as shown in the figure.

Scheme 44

Scheme 45

1. Remove the combination switch. (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-194478-S32929465782005092800000) .)
2. Inspect for continuity between the combination switch terminals using an ohmmeter. If not as specified, replace the light unit or light lever.

Scheme 46

Scheme 47

1. Remove the combination switch. (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-194478-S32929465782005092800000) .)
2. Inspect for continuity between the combination switch terminals using an ohmmeter. If not as specified, replace the light unit or light lever.

Scheme 48

Scheme 49

1. Remove the combination switch. (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-194478-S32929465782005092800000) .)
2. Inspect for continuity between the combination switch terminals using an ohmmeter. If not as specified, replace the wiper unit or the wiper lever.

Scheme 50

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL»(ref-194481-S30241241982005092800000) .) (See «AUDIO UNIT INSTALLATION»(ref-194481-S21464162382005092800000) .)
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Hazard Warning Switch Removal Note

1. Insert your hand into the center panel opening.
2. Press the tabs of the hazard warning switch.
3. Pull the hazard warning switch out from the center panel.

Scheme 51

Scheme 52

1. Remove the hazard warning switch. (See «HAZARD WARNING SWITCH REMOVAL/INSTALLATION»(ref-194478-S41909395002005092800000) .)
2. Inspect for continuity between the hazard warning switch terminals using an ohmmeter. If not as specified, replace the hazard warning switch.

Panel Light Control Switch Removal Note

1. Insert your hand inside the dashboard.
2. Press the tabs of the panel light control switch.
3. Pull the panel light control switch out from the dashboard.
