Lighting Systems: Other Mazda MX-5 NB рестайлинг

With Cruise Control System

Note. The front fog light switch and the cruise control main switch are integrated.

1. See «CRUISE CONTROL SWITCH REMOVAL/INSTALLATION»(ref-194428-S31718511892005092800000) .

Scheme 53

1. Disconnect the negative battery cable.
2. Remove the fuse block cover.
3. Remove the panel light control switch. (See «PANEL LIGHT CONTROL SWITCH REMOVAL/INSTALLATION»(ref-194478-S06861471692005092800000) .)
4. Push the tabs of the cruise control main switch and pull the switch out from inside of the dashboard.
5. Disconnect the cruise control main switch connector to remove the cruise control main switch.
6. Install in the reverse order of removal.

Note. The front fog light switch and the cruise control main switch are integrated.

1. See «CRUISE CONTROL MAIN SWITCH REMOVAL/INSTALLATION»(ref-194428-S17837320542005092800000) .

Scheme 54

Scheme 55

1. Remove the front fog light switch. (See «FRONT FOG LIGHT SWITCH REMOVAL/INSTALLATION»(ref-194478-S04731978962005092800000) .)
2. Inspect for continuity between the front fog light switch terminals using an ohmmeter. If not as specified, replace the front fog light switch.

Scheme 56

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 57

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 58

1. Disconnect the negative battery cable.
2. Remove the lower panel.
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.
