Automatic Transmission - Service, Removal & Installation: Other Mazda MX-5 NB рестайлинг

Output speed sensor

Connecting terminal: AF (+)-AP (-)

Measuring device setting: 1V/DIV (Y) 5ms/DIV (X)

Measuring condition: Vehicle speed at 30 km/h {18.6 mph}

Scheme 377

Scheme 378

1. Connecting terminal: AG (+)-AP (-)
2. Measuring device setting: 2V/DIV (Y) 5 ms/DIV (X)
3. Measuring condition: Idle
