Lighting System: Removal & Installation Mazda CX-9 I рестайлинг

Steering Column Switches 31 illustrations ~1544 words

FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)

Note. Fogging or condensation on the inside of the front combination lights may occur due to a natural phenomenon occurring as a result of a temperature difference between the interior and exterior of the front combination lights rises after illuminating the headlights or a period of time has elapsed.

Scheme 22

Scheme 22
Scheme 22
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-663033-S00861607052014101600000) article.)
  3. Disconnect the connector.
  4. While pressing the clip tab in the direction of the arrows (1) shown in the figure, press the clip in the direction of the arrow (2) shown in the figure to detach the clip tab and front combination light.
  5. Remove the clip.
  6. Remove the bolts.
  7. Remove the protector.
  8. Remove the bolts.
  9. Remove the fastener.
  10. Pull the front combination light in the direction of the arrow shown in the figure and pull out the front combination light pin from the body.
  11. Remove the front combination light.
  12. Install in the reverse order of removal.
  13. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-663026-S39999584422014101600000) .)

Scheme 23

Scheme 23: Low Beam
Scheme 23: Low Beam
  1. Disconnect the negative battery cable.
  2. Remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) article.)
  3. Remove in the order indicated in the illustration below. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  4. Install in the reverse order of removal.

Scheme 24

Scheme 24: High-beam
Scheme 24: High-beam
  1. Disconnect the negative battery cable.
  2. Remove in the order indicated in the illustration below. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  3. Install in the reverse order of removal.

IGNITER REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlight could result in electrical shock. Before servicing the discharge headlights, always refer to the service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)
  1. Disconnect the negative battery cable.
  2. When removing the igniter on the right side, remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) .)
  3. Rotate the cover in the direction of the arrow (1) shown in the figure and remove it from the front combination light in the direction of the arrow (2) shown in the figure.
  4. Rotate the igniter in the direction of the arrow (3) shown in the figure and remove it from the front combination light in the direction of the arrow (4) shown in the figure.
  5. Insert the flathead screwdriver into the gap between the igniter and connector shown in the figure.
  6. Move the flathead screwdriver in the direction of the arrow (5) shown in the figure, lift up the connector, and disconnect it.
  7. Install in the reverse order of removal.

Scheme 25

Scheme 25: Discharge Headlight Inoperative
Scheme 25: Discharge Headlight Inoperative

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS .)

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-663033-S00861607052014101600000) article.)
  3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-663026-S15124769582014101600000) .)
  4. Remove in the order indicated in the illustration below.
  5. Install in the reverse order of removal.

Scheme 27

Scheme 27: STEERING ANGLE SENSOR INSPECTION
Scheme 27: STEERING ANGLE SENSOR INSPECTION
  1. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) article.)
  2. Turn the steering wheel to the right and left, and verify that the voltage and pulses at the terminals are as shown in the illustration below. If not as indicated in the illustration below, replace the combination switch body.

Scheme 28

Scheme 28: PARKING LIGHT BULB REMOVAL/INSTALLATION
Scheme 28: PARKING LIGHT BULB REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 29

Scheme 29: FRONT SIDE MARKER LIGHT BULB REMOVAL/INSTALLATION
Scheme 29: FRONT SIDE MARKER LIGHT BULB REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 30

Scheme 30: FRONT TURN LIGHT BULB REMOVAL/INSTALLATION
Scheme 30: FRONT TURN LIGHT BULB REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 31

Scheme 31: FRONT FOG LIGHT REMOVAL/INSTALLATION
Scheme 31: FRONT FOG LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the front undercover B. (See FRONT UNDER COVER REMOVAL/INSTALLATION article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.
  5. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-663026-S35995690882014101600000) .)

Scheme 32

Scheme 32: FRONT FOG LIGHT BULB REMOVAL/INSTALLATION
Scheme 32: FRONT FOG LIGHT BULB REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the front under cover B. (See FRONT UNDER COVER REMOVAL/INSTALLATION article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 33

Scheme 33: Front Fog Light Bulb Removal Note
Scheme 33: Front Fog Light Bulb Removal Note
  1. Remove the front fog light bulb by turning it in the direction shown by the arrow. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When handling the bulb, hold the flange, not the glass.

Scheme 34

Scheme 34: FRONT FOG LIGHT AIMING
Scheme 34: FRONT FOG LIGHT AIMING

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Make a screen as shown in the illustration below using double-weight, white paper.
  2. Adjust the tire pressure to the specification.
  3. Position the unloaded vehicle on a flat, level surface.
  4. Seat one person in the driver's seat.
  5. Line up the vehicle with the wall so that the center of the front fog light is 3 m {9.8 ft} away from the wall.
  6. Measure the height at the center of the front fog light. NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
  7. Align the center of the front fog light with the center of the screen.
  8. Block the light of the other front fog light using a partition.
  9. Start the engine so that the battery remains charged.
  10. Turn the front fog lights on.
  11. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment. Remove the front under cover B. (See FRONT UNDER COVER REMOVAL/INSTALLATION article.) Loosen the adjustment bolt. Loosen the screw. Move the front fog light in the direction of the arrow shown in the illustration below to adjust the brightness border line to the position indicated on the adjustment screen. Tighten the screw and adjustment bolt.

Scheme 39

Scheme 39: SIDE TURN LIGHT REMOVAL/INSTALLATION
Scheme 39: SIDE TURN LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-663062-S24624344762014101600000) article.) (See «OUTER MIRROR GLASS INSTALLATION»(ref-663062-S41069538852014101600000) article.)
  3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL»(ref-663062-S35318058812014101600000) article.) (See «OUTER MIRROR GARNISH REMOVAL»(ref-663062-S35318058812014101600000) article.)
  4. Remove the screws.
  5. Disconnect the connector.
  6. Install in the reverse order of removal

Scheme 40

Scheme 40: REAR COMBINATION LIGHT REMOVAL/INSTALLATION
Scheme 40: REAR COMBINATION LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove in the order indicated in the illustration below.
  3. Install in the reverse order of removal.

Scheme 41

Scheme 41: INBOARD LIGHT REMOVAL/INSTALLATION
Scheme 41: INBOARD LIGHT REMOVAL/INSTALLATION

Scheme 42

Scheme 42
Scheme 42
  1. Disconnect the negative battery cable.
  2. Remove the service hole cover.
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 43

Scheme 43: Inboard Light Installation Note
Scheme 43: Inboard Light Installation Note

Scheme 44

Scheme 44
Scheme 44
  1. Insert the inboard light into the liftgate as shown in the illustration below, pivot it inward and then fix in place.
  2. Push the bracket onto the liftgate as shown in the illustration below and install.

Scheme 45

Scheme 45: INBOARD LIGHT BULB REMOVAL/INSTALLATION
Scheme 45: INBOARD LIGHT BULB REMOVAL/INSTALLATION

Scheme 46

Scheme 46
Scheme 46
  1. Disconnect the negative battery cable.
  2. Remove the service hole cover.
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.

Scheme 47

Scheme 47: HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION
Scheme 47: HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S35774143582014101600000) article.)
  3. Remove the rear spoiler. (See REAR SPOILER REMOVAL/INSTALLATION article.)
  4. Remove in the order indicated in the illustration below.
  5. Install in the reverse order of removal.

Scheme 48

Scheme 48: License Plate Light
Scheme 48: License Plate Light
  1. Disconnect the negative battery cable.
  2. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S35774143582014101600000) article.)
  3. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S37890998892014101600000) article.)
  4. Remove the liftgate lower trim. (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S38516252682014101600000) article.)
  5. Remove in the order indicated in the illustration below.
  6. Install in the reverse order of removal.

Scheme 49

Scheme 49: License Plate Light Bulb
Scheme 49: License Plate Light Bulb
  1. Disconnect the negative battery cable.
  2. Remove in the order indicated in the illustration below.
  3. Install in the reverse order of removal.

Scheme 50

Scheme 50: Lens Removal Note
Scheme 50: Lens Removal Note
  1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

COMBINATION SWITCH REMOVAL/INSTALLATION

WARNINGIf the negative battery cable or the steering angle sensor connector is disconnected, the stored initial position of the steering angle sensor will be cleared and the DSC will not operate properly, making the vehicle unsafe to drive. Perform the steering angle sensor initialization procedure after connecting the negative battery cable.

Scheme 51

Scheme 51
Scheme 51
  1. Turn the ignition switch to the LOCK position.
  2. Disconnect the negative battery cable and wait for 1 min or more.
  3. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S32454083042014101600000) article.) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-663024-S42363955022014101600000) article.) Steering wheel (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION article.) Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) article.)
  4. Put aside the upper column cover.
  5. Remove in the order indicated in the illustration below.
  6. Disconnect the steering angle sensor connector.
  7. Install in the reverse order of removal.

AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION

Note. Auto light-off system are integrated with the auto light/wiper control module.

Scheme 52

Scheme 52: AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION
Scheme 52: AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) article.)
  3. Remove in the order indicated in the illustration below.
  4. Install in the reverse order of removal.
