Discharge Headlight Control Module Reuse

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge type

Scheme 55

1. Disconnect the negative battery cable.
2. Remove the coolant reserve tank. (RH only) (See «COOLANT RESERVE TANK REMOVAL/INSTALLATION [MZI-3.7]»(ref-663017-S32179853902014101600000) article.)
3. Rotate the cover in the direction of the arrow (1) shown in the figure and remove it from the front combination light in the direction of the arrow (2) shown in the figure.
4. Rotate the igniter in the direction of the arrow (3) shown in the figure and remove it from the front combination light in the direction of the arrow (4) shown in the figure.
5. Move section A of the bulb retaining wire in the direction of the arrow (5) shown in the figure, pull it in the direction of the arrow (6) shown in the figure, and detach the bulb retaining wire and hook.
6. Remove the HO/LO bulb. CAUTION: The discharge headlight bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
7. Install in the reverse order of removal.

HEADLIGHT AIMING

Note. The reflectors for the low and high beams are an integrated unit. Therefore, perform the headlight aiming adjustment on either the low or high beam.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the illustration below.
2. Make a screen as shown in the illustration below using double-weight, white paper.
3. Adjust the tire pressure to the specification.
4. Position the unloaded vehicle on a flat, level surface.
5. Seat one person in the driver's seat.
6. Line up the vehicle with the wall so that the center of the headlight is 3 m {9.8 ft} away from the wall.
7. Measure the height at the center of the headlight. NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
8. Align the center of the headlight with the center of the screen.
9. Block the light of the other headlight using a partition.
10. Start the engine and charge the battery.
11. Turn on the headlight low beams.
12. Set the headlight leveling switch to the 0 position, (vehicles with headlight leveling switch)
13. Verify that the elbow point of the headlight is in the position indicated on the screen. If the elbow point is not in the position indicated on the screen, perform the following adjustment: Insert a phillips driver into the position shown in the illustration below and adjust the headlights.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. Make a screen as shown in the illustration below using double-weight, white paper.
2. Adjust the tire pressure to the specification.
3. Position the unloaded vehicle on a flat, level surface.
4. Seat one person in the driver's seat.
5. Line up the vehicle with the wall so that the center of the headlight is 3 m {9.8 ft} away from the wall.
6. Measure the height at the center of the headlight. NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
7. Align the center of the headlight with the center of the screen.
8. Block the light of the other headlight using a partition.
9. Start the engine and charge the battery.
10. Turn on the headlight low beams.
11. Verify that the center of the hot zone (the bright part of high beam) is at the center of the headlight on the adjustment screen. If the center of the hot zone is not at the center of the headlight on the adjustment screen, turn the adjustment screw to adjust the center of the hot zone.

AUTO LIGHT ILLUMINATION LEVEL SETTING

1. Connect the M-MDS (IDS) to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "Exterior Lighting". Select "Autolamp On Setting".
4. Select "Standard (Other)" or "Low (Other)" on the M-MDS to set the illumination level. NOTE: When the M-MDS is set to Low (Other), the auto-light sensor sensitivity decreases, and the TNS and headlight illumination timing is slower.
5. Perform the procedure as indicated on the screen.
6. Perform the auto light/wiper control module configuration. (See «AUTO LIGHT/WIPER CONTROL MODULE CONFIGURATION»(ref-663026-S06086071672014101600000) .) CAUTION: Perform the auto light/wiper control module configuration after updating the auto light illumination level to assure that the auto light/wiper system operates correctly.

Scheme 66

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 67

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 68

Scheme 69

1. Verify that the continuity between the front map light terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace the front map light.

Scheme 70

Scheme 71

1. Disconnect the negative battery cable.
2. Install in the reverse order of removal.
3. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S20449993582014101600000) article.) Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S02482966052014101600000) article.) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-663022-S18589923242014101600000) article.) Front seat belt lower anchor installation bolt (Driver side) (See FRONT SEAT BELT REMOVAL/INSTALLATION article.) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-663022-S08382637232014101600000) article.) Front seat belt upper anchor installation bolt (See FRONT SEAT BELT REMOVAL/INSTALLATION article.) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-663022-S32370238852014101600000) article.) Trunk box (See «TRUNK BOX REMOVAL/INSTALLATION»(ref-663022-S31210991332014101600000) article.) Seat side box (See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-663022-S00169912002014101600000) article.) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-663022-S10346444022014101600000) article.) Third-row seat (See THIRD-ROW SEAT REMOVAL/INSTALLATION article.) Third-row seat belt lower anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION article.) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S12440623912014101600000) article) Roof side trim (See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-663022-S09102032652014101600000) article.) Second-row seat belt upper anchor installation bolt (See SECOND-ROW SEAT BELT REMOVAL/INSTALLATION article.) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S19555760622014101600000) article.) Third-row seat belt upper anchor installation bolt (See THIRD-ROW SEAT BELT REMOVAL/INSTALLATION article.) D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-663022-S08006295722014101600000) article.) Front map light (See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-663026-S24007146192014101600000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-663022-S41278714162014101600000) article.) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-663022-S08813033222014101600000) article.) RES unit cover (Vehicles with RES) (See «RES UNIT REMOVAL/INSTALLATION»(ref-663028-S23690488152014101600000) article.) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-663022-S13550715042014101600000) article.)
4. Detach the tab and remove the bulb housing. NOTE: The valve housing and the wiring harness have been integrated and attached to the headliner. When replacing the valve housing, remove the wiring harness which passes under the urethane by cutting the urethane.
5. Pull in the direction of the arrows and detach the tabs.
6. Remove the interior light.
7. Install in the reverse order of removal. NOTE: After installing the wiring harness, reinforce the urethane that was cut when removing the valve housing with vinyl tape.

Scheme 72

Scheme 73

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the rear interior light bulb.
4. Install in the reverse order of removal.

Scheme 74

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 75

Scheme 76

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Remove the cargo compartment light bulb.
4. Install in the reverse order of removal.

Scheme 77

Scheme 78

1. Verify that the continuity between the cargo compartment light terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace the cargo compartment light.

Scheme 79

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 80

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.

Scheme 81

1. Disconnect the negative battery cable.
2. Pull the upper column cover upward and detach the upper column cover from the lower column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) article.)
3. Put aside the upper column cover.
4. Remove the ignition key illumination bulb.
5. Install in the reverse order of removal.

Scheme 82

1. Disconnect the negative battery cable.
2. Remove the lower column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-663022-S36532790502014101600000) article.)
3. Remove the coil antenna. (See «COIL ANTENNA REMOVAL/INSTALLATION»(ref-663023-S39205024812014101600000) article.)
4. Remove in the order indicated in the illustration below.
5. Install in the reverse order of removal.

Scheme 83

1. Remove the socket by turning it in the direction shown by the arrow.

Scheme 84

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 85

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 86

1. Insert a tape-wrapped flathead screwdriver into the service hole, and pry it in the direction indicated by the arrow to remove the lens.

Scheme 87

Scheme 88

1. Remove the sunvisor. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-663022-S41278714162014101600000) article.)
2. Verify that the continuity between the vanity mirror illumination terminals is as indicated in the illustration below. If not as indicated in the illustration below, inspect the bulb. If there is no malfunction, replace the sunvisor.

Scheme 89

1. Disconnect the negative battery cable.
2. Remove the front map light. (See «FRONT MAP LIGHT REMOVAL/INSTALLATION»(ref-663026-S24007146192014101600000) .)
3. Remove in the order indicated in the illustration below.
4. Install in the reverse order of removal.

Scheme 90

1. Disconnect the negative battery cable.
2. Disassemble in the order indicated in the illustration below.
3. Install in the reverse order of removal.

Scheme 91

Scheme 92

1. Verify that the continuity between door switch terminal and the body ground is as indicated in the illustration below. If not as indicated in the illustration below, replace the door switch.
