Lighting System: Diagnosis Mazda CX-9 I рестайлинг

Inspection Procedure

DIAGNOSIS PROCEDURE

LIGHT SWITCH INSPECTION

1. Verify that the continuity between the light switch terminals is as indicated in the illustration below.

1. If not as indicated in the illustration below, replace the light switch.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Verify that continuity between the front fog light switch terminals is as indicated in the illustration below.

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-663022-S35013114172014101600000) article.) Front console box mat (See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-663022-S21869071382014101600000) article.) Indicator panel (See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-663022-S05956493772014101600000) article.) Front console box (See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-663022-S12692561512014101600000) article.) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-663022-S15432009222014101600000) article.)
3. Remove in hazard warning switch.
4. Install in the reverse order of removal.

Scheme 12

Scheme 13

1. Verify that the continuity between the hazard warning switch terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace the hazard warning switch.

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the dashboard under cover. (Driver side) (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) article.)
3. Remove the hood release lever. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-663023-S07470612692014101600000) article.)
4. Remove in the order indicated in the illustration below.
5. Install in the reverse order of removal.

Scheme 15

Scheme 16

1. Verify that continuity between the headlight leveling switch terminals is as indicated in the illustration below. If not as indicated in the illustration below, replace the headlight leveling switch.

Scheme 17

Scheme 18

1. Disconnect the negative battery cable.
2. Remove the dashboard under cover (Driver side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-663022-S31534965712014101600000) article.)
3. Remove in the order indicated in the illustration below.
4. Install in the reverse order of removal.

AUTO LIGHT-OFF CONTROL MODULE INSPECTION

1. Measure the voltage at the auto light-off control module terminals as indicated below.
2. Measure the voltage at each terminal is as indicated in the Terminal Voltage Tables. If the voltage is not as specified in the Terminal Voltage Table, inspect the parts under "Inspection item (s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the auto light-off control module.

Scheme 19

TERMINAL VOLTAGE REFERENCE CHART

AUTO LIGHT/WIPER CONTROL MODULE INSPECTION

1. Measure the voltage at the auto light/wiper control module terminals as indicated below.
2. Measure the voltage at each terminal is as indicated in the Terminal Voltage Tables. If the voltage is not as specified in the Terminal Voltage Table, inspect the parts under "Inspection item (s)". If the system does not work properly even though the parts or related wiring harnesses do not have any malfunction, replace the auto light/wiper control module.

Scheme 20

TERMINAL VOLTAGE REFERENCE CHART

Scheme 21

1. Connect the M-MDS (IDS) to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Module Programming".
3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "LCM".
4. Perform the configuration according to the directions on the screen.
5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. (See DTC TABLE [AUTO LIGHT/WIPER CONTROL MODULE] article.)
