Entertainment System: Other Mazda CX-9 I

Entertainment Systems 25 illustrations ~1319 words

Standard Audio

CAUTIONBefore disassembling the audio unit, spread a cloth on the floor to put the disassembled parts on. This protects the surface of the panel from scratches or dirt.

Scheme 46

Scheme 46
Scheme 46
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Note. The action illumination* can be switched on and off by performing the following procedure.

  1. Turn the ignition switch to the ON position.
  2. Turn the audio on.
  3. Press the audio control dial 7 times.
  4. Turn the audio control dial to the left and right to switch the action illumination ON/OFF.

* : May or may not be equipped, depends on the vehicle.

Scheme 47

Scheme 47
Scheme 47

AUDIO AMPLIFIER CONFIGURATION

Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the AUDIO AMPLIFIER CONFIGURATION.

Scheme 48

Scheme 48: AUDIO AMPLIFIER CONFIGURATION
Scheme 48: AUDIO AMPLIFIER CONFIGURATION
  1. Connect the M-MDS to DLC-2.
  2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming".
  3. Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "AM".
  4. Perform the configuration according to the directions on the screen.
  5. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. See «DTC TABLE [AUDIO AMPLIFIER]»(ref-345334-S12109884392009102000000) .

Scheme 49

Scheme 49: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 49: FRONT DOOR SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the inner garnish. See «INNER GARNISH REMOVAL/INSTALLATION»(ref-345331-S15151510462009102000000) .
  3. Remove the front door trim. See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-345331-S18852454002009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 50

Scheme 50: Front Door Speaker Installation Note
Scheme 50: Front Door Speaker Installation Note
  1. Remove the speaker with the wiring harness passing through the groove of the front door module. CAUTION: If the speaker is installed with the wiring harness out of the groove, an open circuit in the wiring harness could occur.

Scheme 51

Scheme 51: FRONT DOOR SPEAKER INSPECTION
Scheme 51: FRONT DOOR SPEAKER INSPECTION
  1. Verify the resistance between front door speaker terminals. If the resistance is not within the specification, replace the front door speaker. Resistance Standard: 4 ohms Bose®: 2 ohms
  2. Connect a 1.5 V battery to the front door speaker and verify that noise is heard from the front door speaker. If no noise is heard, replace the front door speaker.

Scheme 52

Scheme 52: REAR DOOR SPEAKER REMOVAL/INSTALLATION
Scheme 52: REAR DOOR SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the inner sail garnish. See «INNER SAIL GARNISH REMOVAL/INSTALLATION»(ref-345331-S31911894022009102000000) .
  3. Remove the rear door trim. See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-345331-S20461355772009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 53

Scheme 53: Rear Door Speaker Installation Note
Scheme 53: Rear Door Speaker Installation Note
  1. Remove the speaker with the wiring harness passing through the groove of the rear door module. CAUTION: If the speaker is installed with the wiring harness out of the groove, an open circuit in the wiring harness could occur.

Scheme 54

Scheme 54: REAR DOOR SPEAKER INSPECTION
Scheme 54: REAR DOOR SPEAKER INSPECTION
  1. Verify the resistance between rear door speaker terminals. If the resistance is not within the specification, replace the rear door speaker. Resistance Standard: 4 ohms Bose®: 2 ohms
  2. Connect a 1.5 V battery to the rear door speaker and verify that noise is heard from the rear door speaker. If no noise is heard, replace the rear door speaker.

Scheme 55

Scheme 55: FRONT SPEAKER REMOVAL/INSTALLATION
Scheme 55: FRONT SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the cover from the dashboard using a flathead screwdriver wrapped with protective tape.
  3. Remove the solar radiation sensor. (LH). See «SOLAR RADIATION SENSOR REMOVAL/INSTALLATION»(ref-345335-S22050038542009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 56

Scheme 56: FRONT SPEAKER INSPECTION
Scheme 56: FRONT SPEAKER INSPECTION
  1. Verify the resistance between front speaker terminals. If the resistance is not within the specification, replace the front speaker. Resistance 3.6 ohms
  2. Connect a 1.5 V battery to the front speaker and verify that noise is heard from the front speaker. If no noise is heard, replace the front speaker.

Scheme 57

Scheme 57: CENTER SPEAKER REMOVAL/INSTALLATION
Scheme 57: CENTER SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION»(ref-345331-S24413902932009102000000) . Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) . Center panel. See «CENTER PANEL REMOVAL/INSTALLATION»(ref-345331-S22152336712009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 58

Scheme 58: CENTER SPEAKER INSPECTION
Scheme 58: CENTER SPEAKER INSPECTION
  1. Verify the resistance between center speaker terminals. If the resistance is not within the specification, replace the center speaker. Resistance 3.6 ohms
  2. Connect a 1.5 V battery to the center speaker and verify that noise is heard from the center speaker. If no noise is heard, replace the center speaker.

Scheme 59

Scheme 59: REAR SPEAKER REMOVAL/INSTALLATION
Scheme 59: REAR SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Trunk box. See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Third-row seat belt lower anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Rear scuff plate inner. See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Trunk side trim. See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) . Roof side trim. See «ROOF SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S09354378492009102000000) . Third-row seat belt upper anchor installation bolt. See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . D-pillar trim. See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-345331-S32867408392009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 60

Scheme 60: REAR SPEAKER INSPECTION
Scheme 60: REAR SPEAKER INSPECTION
  1. Verify the resistance between rear speaker terminals. If the resistance is not within the specification, replace the rear speaker. Resistance 3.6 ohms
  2. Connect a 1.5 V battery to the rear speaker and verify that noise is heard from the rear speaker. If no noise is heard, replace the rear speaker.

Scheme 61

Scheme 61: ROOF SPEAKER REMOVAL/INSTALLATION
Scheme 61: ROOF SPEAKER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the RES unit cover. See «RES UNIT REMOVAL/INSTALLATION»(ref-345330-S00335831252009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Terminal Voltage Table

TerminalSignal nameConnected toMeasured conditionVoltage (V)/ ContinuityInspection item (s)
A, BAC power supply outputPower supply socket (AC 115 V)Ignition switch is at ACC or ON positionAC 103-5-126.5Power supply socket (AC 115V) Related wiring harnesses
Ignition switch is at LOCK position1.0 or less
EACCMIRROR 7.5 A fuseIgnition switch is at ACC or ON positionB+MIRROR 7.5 A fuse Related wiring harnesses
Ignition switch is at LOCK position1.0 or less
MPower supplyAC PWR 15 A fuseUnder any conditionB+AC PWR 15 A fuse Related wiring harnesses
NGNDBody groundUnder any condition1.0 or lessRelated wiring harnesses

VOLTAGE SPECIFICATION

Scheme 62

Scheme 62: REAR MOUNT CAMERA REMOVAL/INSTALLATION
Scheme 62: REAR MOUNT CAMERA REMOVAL/INSTALLATION
  1. Remove the liftgate upper trim. See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-345331-S07737703532009102000000) .
  2. Remove the liftgate side trim. See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S36635637692009102000000) .
  3. Remove the liftgate lower trim. See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-345331-S30272720632009102000000) .
  4. Remove the rear finisher. See «REAR FINISHER REMOVAL/INSTALLATION»(ref-345340-S13070045192009102000000) .
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal.

Scheme 63

Scheme 63: HANDS-FREE TELEPHONE (HF/TEL) UNIT REMOVAL/INSTALLATION
Scheme 63: HANDS-FREE TELEPHONE (HF/TEL) UNIT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover (Passenger side). See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-345331-S05761886132009102000000) .
  3. Remove the glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-345331-S00629389742009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 64

Scheme 64: Front
Scheme 64: Front
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-345331-S31374414672009102000000) . Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION»(ref-345331-S10485313842009102000000) . Indicator panel. See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(ref-345341-S00995522882009102000000) . Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION»(ref-345331-S18733072432009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 65

Scheme 65: Center
Scheme 65: Center
  1. Disconnect the negative battery cable.
  2. Remove the console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-345331-S12921188482009102000000) .
  3. Remove the console. See «CONSOLE REMOVAL/INSTALLATION»(ref-345331-S33017209812009102000000) .
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 66

Scheme 66: Rear
Scheme 66: Rear
  1. Disconnect the negative battery cable.
  2. Remove the following parts: Trunk box See «TRUNK BOX REMOVAL/INSTALLATION»(ref-345331-S28817313762009102000000) . Seat side box. See «SEAT SIDE BOX REMOVAL/INSTALLATION»(ref-345331-S04400711882009102000000) . Trunk end trim. See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-345331-S25003096482009102000000) . Third-row seat. See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-345332-S37062980262009102000000) . Rear scuff plate inner (RH). See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-345331-S02668570962009102000000) . Third-row seat belt lower anchor installation bolt (RH). See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-345333-S30110355222009102000000) . Trunk side trim (Passenger side). See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-345331-S20889935252009102000000) .
  3. Remove the console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-345331-S12921188482009102000000) .
  4. Remove the console. See «CONSOLE REMOVAL/INSTALLATION»(ref-345331-S33017209812009102000000) .
  5. Remove in the order indicated in the table.
  6. Install in the reverse order of removal.

Scheme 67

Scheme 67: Accessory Socket Removal Note
Scheme 67: Accessory Socket Removal Note
  1. While pressing a tape-wrapped flathead screwdriver against the cap projection, pull the accessory socket outward.

Scheme 68

Scheme 68: Cap Removal Note
Scheme 68: Cap Removal Note
  1. While pressing the tabs, pull the cap outwards.

Scheme 69

Scheme 69: ACCESSORY SOCKET INSPECTION
Scheme 69: ACCESSORY SOCKET INSPECTION
  1. Connect a tester as shown in the figure and verify that there is continuity. If the continuity cannot be verified, replace the accessory socket.

Scheme 70

Scheme 70: AUXILIARY JACK REMOVAL/INSTALLATION
Scheme 70: AUXILIARY JACK REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the console cover. See «CONSOLE COVER REMOVAL/INSTALLATION»(ref-345331-S33051633072009102000000) .
  3. Disconnect the auxiliary jack connector.
  4. Squeeze the tabs of auxiliary jack and pull it outward to remove it.
  5. Install in the reverse order of removal.
