Glass/windows/mirrors: Overview Mazda CX-5 I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Perform the front door glass preparation. (See «FRONT DOOR GLASS PREPARATION»(ref-615391-S15977924972014051000000) ). NOTE: Before removing the front door glass, the removal procedure for the front door glass installation bolt can be facilitated by adjusting the top of the front door glass to the position approx. 90 mm {3.5 in} away from the upper part of the front beltline molding.
2. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-615455-S13279173212014051000000) ). Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S36547034772014051000000) ). Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S00203104652014051000000) ).
4. Remove the weather strip arrow (1) shown in the figure. (Scheme 1): Removing Front Door Weather Strip
5. Press the center of the service hole cover in the direction of arrow (2) shown in the figure.
6. Remove the service hole cover by holding its rib and partially peeling it back in the direction of arrow (3) shown in the figure.
7. Insert your hand through the front door speaker installation hole while supporting the front door glass and adjust the position of the front door glass so that the front door glass installation bolt is in a position in which it can be removed from the service hole cover opening. (Scheme 2): Removing Service Hole Cover
8. Remove bolts. CAUTION: If the bolts are removed without supporting the front door glass, the front door glass may fall off and be damaged. Remove the bolts while inserting your hand into the front door speaker installation hole to support the front door glass. (Scheme 3): Removing Front Door Glass Bolt With Torque Specifications
9. Lift up the front door glass, tilt it in the direction of arrow (1) shown in the figure, then remove it in the direction of arrow (2). (Scheme 4): Removing Front Door Glass
10. Install in the reverse order of removal.

Scheme 5

1. Perform the adjusting the top of the front door glass to the position approx. 90 mm {3.5 in} away from the upper part of the front door trim. (Scheme 5): Identifying Front Door Glass Adjustment Dimension With Torque Specifications

Scheme 6

Scheme 7

Scheme 8

1. Fully lower the rear door glass.
2. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Remove the following parts: Rear door trim (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ). Rear door quarter glass (See «REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION»(ref-615391-S21582338052014051000000) ). Rear door speaker (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-615447-S07587056722014051000000) ). Rear power window motor (See «POWER WINDOW MOTOR REMOVAL/INSTALLATION»(ref-615391-S00052507202014051000000) ).
4. Press the center of the service hole cover in the direction of arrow (1) shown in the figure.
5. Remove the service hole cover by holding its rib and partially peeling it back in the direction of arrow (2) shown in the figure.
6. Remove the bolt. CAUTION: If the bolts are removed without supporting the rear door glass, the rear door glass may fall off and be damaged. Remove the bolts while inserting your hand into the rear door speaker installation hole to support the rear door glass. (Scheme 6): Removing Service Hole Cover (Scheme 7): Removing Service Hole Cover Bolt With Torque Specifications
7. Lift the rear door glass up and remove while tilting it.
8. Lift up the rear door glass, tilt it in the direction of arrow (3) shown in the figure. (Scheme 8): Removing Rear Door Glass
9. Install in the reverse order of removal.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Fully lower the rear door glass.
2. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ).
4. Remove the rear door weather strip arrow (1) shown in the figure. (Scheme 9): Removing Rear Door Weather Strip
5. Remove the service hole cover No.1 arrow (2) shown in the figure. CAUTION: When removing service hole cover No.1, remove it while gradually stripping the butyl rubber. Otherwise service hole cover No.1 may be deformed. (Scheme 10): Removing Service Hole Cover No. 1
6. Remove the service hole cover No.2 arrow in the order of (3), (4) shown in the figure. (Scheme 11): Removing Service Hole Cover No. 2
7. Partially peel back rear door weather strip.
8. Remove screw B. (Scheme 12): Removing Rear Door Weather Strip Screw B
9. Remove bolts C.
10. Partially peel back the rear door glass run channel. (Scheme 13): Removing Rear Door Glass Run Channel Bolt C With Torque Specifications (Scheme 14): Identifying Rear Door Glass Run Channel And Glass Guide
11. Pull the glass guide in the direction of the arrow (5) shown in the figure, then remove the glass guide direction of the arrow (6) shown in the figure. (See «REAR DOOR GLASS RUN CHANNEL INSTALLATION NOTE»(ref-615391-S27992748252014051000000) ). (See «GLASS GUIDE INSTALLATION NOTE»(ref-615391-S42776115602014051000000) ). (Scheme 15): Removing Glass Guide
12. Pull the rear door glass run channel in the direction of the arrow in the order of (7),(8),(9) then remove the rear door glass run channel. (Scheme 16): Pulling Rear Door Glass Run Channel
13. Slide the rear door quarter glass and rear door quarter glass guide as a single unit in the direction of the arrow (10) shown in the figure. (Scheme 17): Sliding Rear Door Quarter Glass And Guide
14. Remove the rear door quarter glass and rear door quarter glass guide as a single unit in the direction of the arrow (11) shown in the figure.
15. Pull the rear door quarter glass guide in the direction of the arrow in the order of (12), (13), (14) and remove the rear door quarter glass. (Scheme 18): Removing Rear Door Quarter Glass
16. Install in the reverse order of removal.

Scheme 19

1. Install the rear door glass run channel so that the glass guide is aligned with the top of the rear door glass run channel. (Scheme 19): Identifying Rear Door Glass Run Channel And Guide

Scheme 20

Scheme 21

1. Set the glass guide in the direction shown in the figure, and insert the bolt installation hole in the direction of arrow (1) until it reaches area A. (Scheme 20): Installing Glass Guide
2. When the bolt installation hole of the glass guide reaches area A, rotate the glass guide in the direction of arrow (2) shown in the figure.
3. Move the glass guide in the direction of arrow (3) shown in the figure to adjust the position of the front door inner panel and the bolt installation holes of the glass guide.
4. Move the glass guide in the direction of arrow (4) shown in the figure and while aligning it to the screw installation hole in the rear door inner panel, set it to the rear door quarter glass and the rear door glass. (Scheme 21): Moving Glass Guide

Scheme 22

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S12815760182014051000000) ). Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-615433-S35529177272014051000000) ). Rain sensor (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-615468-S29801950972014051000000) ). Auto-dimming mirror (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL/INSTALLATION»(ref-615391-S21324351182014051000000) ). Rearview mirror (without auto-dimming mirror) (See «REARVIEW MIRROR REMOVAL/INSTALLATION»(ref-615391-S06487900792014051000000) ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S18284409542014051000000) ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-615455-S21135452612014051000000) ). Front map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-615452-S19821275172014051000000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-615455-S08116469212014051000000) ).
3. Set the headliner out of the way.
4. Apply protective tape along the edge of the body. NOTE: Overlap and adhere the protective tape to the corners to prevent damage.
5. Remove the windshield molding by pulling it outward. NOTE: If the windshield molding is difficult to remove, warm the windshield molding using a hot air blower. The windshield molding is a replacement part. (Scheme 22): Identifying Protective Tape Application Area
