Not Reusing Windshield

Note. If it is difficult to cut sealant, use piano wire and follow the procedure under "Reusing Windshield".

Scheme 106

1. Cut out the sealant all around the glass using a sealant remover.
2. Remove the windshield. (Scheme 106): Cutting Out Sealant Around Glass Using Sealant Remover

Reusing Windshield

Note. Before removing the windshield from the body, mark the position of the windshield by affixing tape to the windshield and body panel.

Scheme 107

Scheme 108

1. Avoiding the pin on the inside of the vehicle, insert piano wire which has been cut to sufficient length.
2. Wind each end of piano wire around a bar. NOTE: Use a long sawing action to spread the work over the whole length of piano wire to prevent it from breaking due to localized heating. (Scheme 107): Removing Windshield From Body Using Piano Wire
3. Secure one end of piano wire, and while pulling the other end, cut the sealant around the windshield.
4. Pinch the pin from the inside of the vehicle and detach it.
5. Remove the windshield.
6. If the pin is damaged, remove the pin. NOTE: Before removing the pin from the windshield glass, place an alignment mark on the windshield. (Scheme 108): Securing One End Of Piano Wire

Rear

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the rear door trim (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-615455-S14145382822014051000000) ).
3. Disconnect the power window motor connector.
4. Apply battery positive voltage and connect the ground to power window motor terminals E and F, and then inspect the power window motor operation. see scheme 66: Rear Power Window Motor Operation Diagram If the power window motor does not operate as indicated in the table, replace it. Operation Terminal E F Close B+ Ground Open Ground B+

Scheme 109

Scheme 110

Scheme 111

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the cover A.
3. Insert a tape-wrapped fastener remover shown in the figure and remove the tab B in the direction of arrow (1). (Scheme 109): Removing Power Window Main Switch Tab B Using Tape-Wrapped Fastener Remover (Scheme 110): Removing Tab C
4. Slide the power window main switch cover in the direction of the arrow (2) shown in the figure and remove the tab C.
5. Disconnect the power window main switch connector.
6. Pull the edge of power window main switch cover in the direction of arrow (3) and detach tabs D. (Scheme 111): Removing Power Window Main Switch
7. Remove the power window main switch in the direction of arrow (4) shown in the figure.
8. Install in the reverse order of removal.

POWER WINDOW SYSTEM INITIALIZATION PROCEDURE

Note. If the following operations have been performed, initial setting is reset, and auto up/down operation are disabled. Therefore, performing initial setting is necessary. Negative battery cable is disconnected. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0] ). Power window main switch connector is disconnected. Power window system power supply fuse is removed.

1. Switch the ignition ON (engine off).
2. Press the driver's seat switch to fully open the door glass.
3. Pull up the driver's seat switch to the manual-up position to fully close the door glass and keep holding the switch up at the position for approx. 2 s.
