Discharge Headlight Control Module Reuse

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge type

Scheme 51

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard.
3. Remove the cover. (Scheme 51): Discharge Headlight Cover And Connector
4. Remove the connector. (See «DISCHARGE HEADLIGHT REMOVAL NOTE»(ref-581620-S33352424182013101400000).)
5. Remove the discharge headlight. (See «DISCHARGE HEADLIGHT REMOVAL NOTE»(ref-581620-S33352424182013101400000).) CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
6. Install in the reverse order of removal.

Scheme 52

1. Rotate the connector in the direction of the arrow shown in the figure to remove it. (Scheme 52): Rotating Discharge Connector

Scheme 53

1. Press sections A to release the bulb retaining wire and remove the discharge headlight. (Scheme 53): Bulb Retaining Wire

Scheme 54

Scheme 55

1. Disconnect the negative battery cable.
2. Disconnect the connector. (Scheme 54): Discharge Headlight Connector
3. Rotate the headlight bulb in the direction of the arrow shown in the figure. (Scheme 55): Rotating Headlight Bulb
4. Remove the headlight bulb. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Install in the reverse order of removal.

HEADLIGHT AIMING

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the figure. (Scheme 56): Headlight Brightness Borderline (LH And RH)
2. Make a screen as shown in the figure using double-weight, white paper. (Scheme 57): Center Of Headlight And Brightness Borderline
3. Adjust the tire pressure to the specification.
4. Position the unloaded vehicle on a flat, level surface.
5. Seat one person in the driver's seat.
6. Line up the vehicle with the wall so that the center of the headlight is 3 m {9.8 ft} away from the wall. (Scheme 58): Line Up Vehicle Headlight With Center Of Wall
7. Measure the height at the center of the headlight. (Scheme 59): Measuring Height At Center Of Headlight NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
8. Align the center of the headlight with the center of the screen. (Scheme 60): Measuring Height Of Center Of Headlight Using Actual Vehicle
9. Block the light of the other headlight using a partition.
10. Start the engine and charge the battery.
11. Turn on the headlight low beams.
12. Set the headlight leveling switch to the 0 position. (vehicles with headlight leveling system)
13. Verify that the line at the bottom of the gradation zone is aligned with the H line. (Scheme 61): Identifying Center Of Headlight, Gradation Zone And Brightness Border Line If the line at the bottom of the gradation zone is not aligned with the H line, perform the following adjustment. Insert a phillips driver into the position shown in the figure and adjust the headlights. (Scheme 62): Inserting Phillips Driver Into Position

Discharge Headlight Control Module Connector Terminals And Headlight Fuses And Headlight Relay. Scheme 63

STEERING ANGLE SENSOR INITIALIZATION PROCEDURE

Note. The BCM stores the steering angle reference point using battery power supply. Therefore, if the following operations are performed and the power supply to the BCM is interrupted, the stored steering angle reference point will be erased. The negative battery cable is disconnected A fuse (ROOM) is removed The BCM connector is disconnected The steering angle sensor connector is disconnected Replace the steering angle sensor Replace the BCM

1. Inspect the wheel alignment, inflation pressure, and the installation condition of the steering wheel. If there is any malfunction, adjust the applicable part.
2. Connect the negative battery cable.
3. Switch the ignition to ON.
4. Confirm that the DSC indicator light illuminates and that the DSC OFF light flashes.
5. Turn the steering wheel to full right lock, then turn it to full left lock.
6. Confirm that the DSC OFF light and DSC indicator light goes out. If the DSC indicator light does not go out, disconnect the negative battery cable, and perform the procedure again starting from Step 3 shown above.

Scheme 64

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-581657-S04390956372013101400000).)
3. Rotate the parking/front turn light socket in the direction of the arrow (1) shown in the figure. (Scheme 64): Rotating Parking/Front Turn Light Socket
4. Pull the parking/front turn light socket in the direction of the arrow (2) shown in the figure and remove it.
5. Remove the parking/front turn light bulb.
6. Install in the reverse order of removal.

Scheme 65

Scheme 66

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-581657-S04390956372013101400000).)
3. Disconnect the front side marker light connector. (Scheme 65): Disconnecting Front Side Marker Light Connector And Tab A
4. Remove tab A by pressing it in the direction of the arrow shown in the figure.
5. Remove the front side marker light by pulling it in the direction of the arrow shown in the figure. (Scheme 66): Front Side Marker Light And Pin CAUTION: When remove the front side marker light, be careful not to damage the pin.
6. Install in the reverse order of removal.

Scheme 67

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-581657-S04390956372013101400000) )
3. Rotate the front side marker light socket in the direction of the arrow shown in the figure and remove it. (Scheme 67): Rotating Front Side Marker Light Socket
4. Remove the front side marker light bulb.
5. Install in the reverse order of removal.

Scheme 68

Scheme 69

Scheme 70

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-581621-S34011796882013101400000).)
3. Remove the screws A. (Scheme 68): Identifying Front Fog Light Component And Screws A
4. Remove the front fog light component.
5. Remove the screw B. (Scheme 69): Front Fog Light, Screw B And Adjustment Bolt With Torque Specification
6. Remove the adjustment bolt.
7. Pull the front fog light in the direction of the arrow shown in the figure and remove it from the front fog light bracket. (Scheme 70): Pulling Front Fog Light
8. Install in the reverse order of removal.
9. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-581620-S18397812602013101400000).)

Scheme 71

Scheme 72

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard. (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-581657-S04390956372013101400000).)
3. Disconnect the connector. (Scheme 71): Rotating Front Fog Light Bulb
4. Rotate the front fog light bulb in the direction of the arrow shown in the figure. CAUTION: A halogen bulb generates extremely high heat when it is used. If the surface of the bulb is soiled, excessive heat will build up and the light's life will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Remove the front fog light bulb. (Scheme 72): Front Fog Light Bulb
6. Install in the reverse order of removal.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Make a screen as shown in the figure using double-weight, white paper. (Scheme 73): Front Fog Light Aiming Dimension
2. Adjust the tire pressure to the specification.
3. Position the unloaded vehicle on a flat, level surface.
4. Seat one person in the driver's seat.
5. Line up the vehicle with the wall so that the center of the front fog light is 3 m {9.8 ft} away from the wall. (Scheme 74): Lining Up Vehicle With Wall Center Of Front Fog Light
6. Measure the height at the center of the front fog light. (Scheme 75): Measuring Height At Center Of Front Fog Light NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the front fog light using the actual vehicle.
7. Align the center of the front fog light with the center of the screen. (Scheme 76): Measuring Height Of Center Of Front Fog Light Using Actual Vehicle
8. Block the light of the other front fog light using a partition.
9. Start the engine so that the battery remains charged.
10. Turn the front fog lights on.
11. Verify that the brightness border line of the front fog light is at the position indicated on the adjustment screen. If the brightness border line is not at the position indicated on the adjustment screen, perform the following adjustment. Remove the adjustment bolt and cut the front fog light hole cover at the position shown in the figure. (Scheme 77): Front Fog Light Adjustment Bolt With Torque Specification Loosen the screw. Move the front fog light in the direction of the arrow shown in the figure to adjust the brightness border line to the position indicated on the adjustment screen. Install the adjusting bolt and tighten the screw.

Scheme 78

Scheme 79

1. Disconnect the negative battery cable.
2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-581623-S34743219682013101400000).) (See «OUTER MIRROR GLASS INSTALLATION»(ref-581623-S16661928022013101400000).)
3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL/INSTALLATION»(ref-581623-S37535537922013101400000).)
4. Remove the screw. (Scheme 78): Side Turn Light And Screw
5. Disconnect the connector. (Scheme 79): Side Turn Light And Connector
6. Remove the side turn light.
7. Install in the reverse order of removal.

Scheme 80

1. Disconnect the negative battery cable.
2. Remove the outer mirror glass. (See «OUTER MIRROR GLASS REMOVAL»(ref-581623-S34743219682013101400000).) (See «OUTER MIRROR GLASS INSTALLATION»(ref-581623-S16661928022013101400000).)
3. Remove the outer mirror garnish. (See «OUTER MIRROR GARNISH REMOVAL/INSTALLATION»(ref-581623-S37535537922013101400000).)
4. Remove the side turn light. (See «SIDE TURN LIGHT REMOVAL/INSTALLATION»(ref-581620-S41439623182013101400000).)
5. Connect the battery voltage as shown in the figure. (Scheme 80): Connecting Battery Voltage If the side turn light does illuminate, replace it. If the side turn light illuminate, inspect the short-code.

Scheme 81

Scheme 82

1. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
2. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
3. Disconnect the power outer mirror connector. (See «POWER OUTER MIRROR REMOVAL/INSTALLATION»(ref-581623-S09121098062013101400000).)
4. Verify that the continuity between side turn light terminals is as indicated in the table. (Scheme 81): Identifying Power Outer Mirror Connector Terminals
5. If not as indicated in the table, replace the power outer mirror. (Scheme 82): Power Outer Mirror Connector Terminals Continuity Chart

Scheme 83

Scheme 84

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000).)
3. Partially peel back the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000).)
4. Disconnect the connectors shown in the figure and remove the nuts. (Scheme 83): Rear Combination Light Connectors And Nuts With Torque Specification
5. Pull the rear combination light in the direction of the arrow to detach it from the tab. (Scheme 84): Pulling Rear Combination Light Of Tab
6. Remove the rear combination light.
7. Install in the reverse order of removal.

Scheme 85

Scheme 86

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000).)
3. Partially peel back the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000).)
4. Disconnect the connectors shown in the figure. (Scheme 85): Rear Turn Light Connectors
5. Rotate the rear turn light socket in the direction of the arrow shown in the figure and remove it. (Scheme 86): Rotating Rear Turn Light Socket
6. Remove the rear turn light bulb.
7. Install in the reverse order of removal.

Scheme 87

Scheme 88

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000).)
3. Partially peel back the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000).)
4. Disconnect the connectors shown in the figure. (Scheme 87): Brake/Taillight Bulb Connectors
5. Rotate the brake/taillight socket in the direction of the arrow shown in the figure and remove it. (Scheme 88): Rotating Brake/Taillight Socket
6. Remove the brake/taillight bulb.
7. Install in the reverse order of removal.

Scheme 89

Scheme 90

1. Disconnect the negative battery cable.
2. Remove the recess. (See «RECESS REMOVAL/INSTALLATION»(ref-581614-S17369187092013101400000).)
3. Partially peel back the trunk rid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-581614-S10051324362013101400000).)
4. Disconnect the inboard light connector, then remove the nuts and brackets. (Scheme 89): Inboard Light Connector And Nuts With Torque Specification
5. Remove the inboard light as shown in the figure. (Scheme 90): Trunk Lid Inboard Light
6. Install in the reverse order of removal. (See «INBOARD LIGHT INSTALLATION NOTE»(ref-581620-S34769982522013101400000).)

Scheme 91

Scheme 92

1. Insert the inboard light into the trunk lid as shown in the figure, then pivot it inward and fix in place. (Scheme 91): Inserting Inboard Light Into Trunk Lid
2. Push the bracket onto the trunk lid as shown in the figure and install. (Scheme 92): Pushing Bracket Onto Trunk Lid

Scheme 93

Scheme 94

1. Disconnect the negative battery cable.
2. Partially peel back the trunk rid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-581614-S10051324362013101400000).)
3. Disconnect the back-up light bulb connector. (Scheme 93): Back-Up Light Bulb Connector
4. Rotate the socket in the direction of the arrow as shown in the figure to remove it. (Scheme 94): Rotating Back-Up Light Socket
5. Remove the back-up light bulb.
6. Install in the reverse order of removal.

Scheme 95

Scheme 96

Scheme 97

1. Open the trunk lid.
2. Disconnect the negative battery cable.
3. Disconnect the high-mount brake light connector shown in the figure. (Scheme 95): Disconnecting High-Mount Brake Light Connector
4. Lift up the high-mount brake light in the direction of the arrow and detach the tabs. (Scheme 96): Lifting Up High-Mount Brake Light And Tabs
5. Pull the high-mount brake light in the direction of the arrow shown in the figure to detach the hooks and pin. (Scheme 97): Pulling High-Mount Brake Light
6. Remove the high-mount brake light.
7. Install in the reverse order of removal.

Scheme 98

1. Disconnect the negative battery cable.
2. Remove the following parts: Recess (See «RECESS REMOVAL/INSTALLATION»(ref-581614-S17369187092013101400000).) Trunk rid trim (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-581614-S10051324362013101400000).) Rear finisher (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-581657-S20520189782013101400000).) License plate light bulb (See «LICENSE PLATE LIGHT BULB REMOVAL/INSTALLATION»(ref-581620-S16737759512013101400000).)
3. Press tab A in the direction of the arrow (1) shown in the figure, press the license plate light in the direction of the arrow (2), and detach tab B. (Scheme 98): Pressing License Plate Light And Tab B
4. Remove the license plate light.
5. Install in the reverse order of removal.

Scheme 99

Scheme 100

1. Disconnect the negative battery cable.
2. Partially peel back the trunk rid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-581614-S10051324362013101400000).)
3. Disconnect the license plate light connector. (Scheme 99): License Plate Light Connector And Socket
4. Rotate the socket in the direction of the arrow shown in the figure to remove it. (Scheme 100): Rotating License Plate Light Bulb Socket
5. Remove the license plate light bulb.
6. Install in the reverse order of removal.

Scheme 101

Scheme 102

1. Disconnect the negative battery cable.
2. Remove the aerodynamic under cover No.2. (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-581657-S19487724012013101400000).)
3. Disconnect the back-up light switch connector. (See «BACK-UP LIGHT SWITCH REMOVAL/INSTALLATION [G66M-R]»(ref-581632-S26219591992013101400000).)
4. Verify that the continuity between the back-up light switch terminals is as indicated in the table. (Scheme 101): Identifying Back-Up Light Switch Connector Terminals If not as indicated in the table, replace the back-up light switch. (Scheme 102): Back-Up Light Switch Connector Terminals Continuity Chart

Room Light Control System/Turn Light System

1. For the room light control system / turn light system, refer to the control system personalization features setting. (See «CONTROL SYSTEM PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-581670-S08685963892013101400000) .)

Scheme 103

1. Disconnect the negative battery cable.
2. Open the overhead console.
3. Remove in the order indicated in the table. (Scheme 103): Map Light Components
4. Install in the reverse order of removal.

Scheme 104

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens. (Scheme 104): Inserting Tape-Wrapped Flathead Screwdriver Into Service Hole

Scheme 105

Scheme 106

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).)
3. Verify that the continuity between the map light terminals is as indicated in the table. (Scheme 105): Identifying Map Light Connector Terminals If not as indicated in the table, replace the map light. (Scheme 106): Map Light Connector Terminals Continuity Chart
4. Apply battery positive voltage to map light terminal C, and connect terminal F to ground.
5. Switch the room light switch to the DOOR position and verify that the map light illuminates. If the light does not illuminate, replace the map light.

Scheme 107

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
6. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
7. Remove the sunvisor. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).)
8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).)
9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).)
10. Remove the headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
11. Disconnect the interior light connector. (Scheme 107): Interior Light Connector And Tab
12. Detach the tab and remove the interior light.
13. Install in the reverse order of removal.

Scheme 108

Scheme 109

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens. (Scheme 108): Inserting Tape-Wrapped Flathead Screwdriver Into Service Hole
3. Remove the interior light bulb. (Scheme 109): Interior Light Bulb
4. Install in the reverse order of removal.

Scheme 110

1. Disconnect the negative battery cable.
2. Disengage the tabs by pressing both ends of the lens in the directions indicated by the arrows and remove the lens. (Scheme 110): Trunk Compartment Light Bulb, Lens And Tabs
3. Install in the reverse order of removal.

Scheme 111

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table. (Scheme 111): Courtesy Light Bulb And Lens
3. Install in the reverse order of removal.

Scheme 112

1. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens. (Scheme 112): Inserting Tape-Wrapped Flathead Screwdriver Into Service Hole
